5V-16V Linear Power Supply Kit User's Guide
Overview
This kit is designed to fill the need for a power supply which can be connected to the mains
electrical supply of your house and which can provide the range of DC voltages that are
required for basic electronic projects. The circuit is basic but it will satisfy the requirements
of most electronic kit users especially when starting out. Two DC voltage outputs are
available. One is a fixed regulated 5V for TTL use. The other output is variable from 5V
upwards. The maximum output voltage depends on the input voltage. The specified
maximum input DC voltage to the regulator is 16V. The minimum input voltage must be 2V
higher than the regulated output voltage.
Item
Electrolytic Capacitor C1
Voltage Regulator IC U1,U2
LED D1
R1
Resistor
R2
C2, C3,
Monoblock
C4, C5
Input Jack J2
Bridge Rectifier W02
Terminal Block J3, J4
Printed Circuit Board
Potentiometer
Heat Sink
Screw
Nut
Application
Provide DC voltages for basic electronic projects
Description
1000uF/35V
LM7805
5mm
390R, carbon 5% (orange, white, brown)
250R
100nF(104)
-
W02
2 pole
79.40(L) × 50.20(W) × 1.60(H) ±0.2mm
500R, linear
HS-103
M3mm×6mm
M3mm
