Aritronix Scorpio User Manual

Fm 2-way transceiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version

Important Information

Save this information for future use.
Date of purchase _____/_____/_____
Place of purchase ______________________
______________________
Invoice/Receipt # _________________
Model Number
_________________
Production Code _________________
Notes:
SPECIAL NOTE ON RANGE
The average reception range is approximately ½ mile (800 meters). The actual reception
range could be greater or less depending on the location and/or the presence of obstacles
between the vehicle and the receiver. The reception range can also be affected by the
presence of strong electromagnetic interference from outside sources.
a3
FCC Notice
This device complies with Part 15 of FCC rules.
Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) This device must
accept any interference that may cause
undesired operation.
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user's authority to
operate this device.
FCC ID: MKARI60
Installation
User's Guide
Tranceiver Information
Optional Accessories
Appendix

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Scorpio and is the answer not in the manual?

Questions and answers

Summary of Contents for Aritronix Scorpio

  • Page 1: Important Information

    Important Information FCC Notice Save this information for future use. Installation Date of purchase _____/_____/_____ This device complies with Part 15 of FCC rules. Operation is subject to the following two Place of purchase ______________________ conditions: (1) This device may not cause harmful interference, and (2) This device must User’s Guide ______________________...

  • Page 2: Table Of Contents

    Operating Instructions Motorcycle battery safeguard after assistance from our trained staff it is determined that the Aritronix product may be faulty then you will Auto Arm be provided with detailed information on processing a warranty claim and instructions on how to send the Activate Perimeter Sensor product into our repair office.

  • Page 3: Troubleshooting Guide

    Troubleshooting guide Manual Override Procedure Programming Personal Problem Possible Cause Solution Override Code Enter Programming Mode Will not arm Verify connection from MCM to RFID Select number of flashes for Code RFID antenna not connected antenna Using Code in case of lost remote Verify connection to power lead and Power or ground not connected ground connection...

  • Page 4: Installation

    Installation Components Component Check List TRS-9 MCM-9 RFID antenna Appendix AC Adapter GEN-1 TRS-9 Adapter GEN-1(Bag) Transceiver T-taps x4 ACC-1(Bag) Velcro Pieces x2 ACC-1 Zip Ties x4 Dust Cap x1 HAR-1 (Bag) MCM-9 RFID HAR-1 antenna Planning the Installation Check that your motorcycle battery is fully charged. Check the layout of the motorcycle for placement of components.

  • Page 5: Installation Diagram

    --------------------- Installation Diagram --------------------...

  • Page 6: Installation Warnings And Notes

    Installation Warnings and Notes Ignition / Engine Control Wire Options: Option #1: Positive lead wire on fuel pump : Connect the (HAR-1) harness to the MCM only after installation is completed. Option #2: Positive lead wire on fuel injection system Option #3: Positive wire that goes to the ignition fuse in fuse box.

  • Page 7: Color Code Chart

    Attempt to start bike to test if correct wire is selected. If bike starts the wrong wire is selected. Honda Green Brown Orange Blue (contact Aritronix for assistance) If bike does not start, correct wire was selected continue to Kawasaki Black Green Grey step 3.

  • Page 8: User's Guide

    Trigger Alert Indicator Note: If the system chirps only 2 times and it has been correctly connected for more the 12 hours, the battery needs replacement. (Contact Aritronix for replacement options) 24 hour Clock / Text display If motorcycle battery drops below 11 volts the screen will display CyCLE bAtt LO.

  • Page 9: Operating Instructions

    Perimeter Sensor (SN-5) Operating Instructions The SR-i900, by default, will be in auto arm mode and will activate with the perimeter sensor off and the siren on, five seconds after turning the ignition key off. Mounting the SN-5 The Perimeter sensor uses high frequency microwave technology to detect mass density movement Auto Arm Auto Disarm around the motorcycle.

  • Page 10: Programming And Customizing Instructions

    Programming and Customizing Instructions Entering Programming Mode Programmable Press button 2 Press button 2 options will be again to scroll Twice quickly displayed. through to enter The selected programmable Optional Accessories: programming icon will flash options mode Perimeter Sensor (SN-5) Press button 1 Back-up Battery (BAT-5) to select icon...

  • Page 11: Selecting Transceiver Alert Type

    Selecting Transceiver Alert Type (Audible/Silent/Vibrate) Transceiver Battery Information Enter programming mode. Scroll to the the icon, press button 1 to select. The LCD will display The receiver consists of two functions RFID functions and Two-way FM communication. the current settings. To program follow these steps: –...

  • Page 12: Selecting Siren Default

    Selecting Siren Default RCS (Range Confirmation Signal) If the transceiver is within range of the MCM and the alarm is activated, the LCD will display icon. Enter programming mode. Scroll to the icon and press button 1 to enter the siren menu. The If the transceiver does not receive the RCS;...

  • Page 13: Encoding The Transceiver

    Encoding a Transceiver Transceiver Information Note: The transceivers are programmed from the factory. Encoding is only necessary should Alarm Triggers the transceiver lose its code and will not arm or disarm the security system or if a second or replacement remote is obtained. When the system is triggered, the siren will sound and the turn signal lights will flash.

  • Page 14: Additional Information

    Additional Information Manual Override Procedure Sensor Memory Display Programming Personal Override code When the system is disarmed the turn signals will flash to indicate if there has been an alarm trigger. A personal override code will be a sequence of left – right - left turn signal flashes that can be used if The lights will flash once to indicate that the system has been disarmed, additional flashes indicate the remote is lost to disable the alarm: that the following trigger has occurred:...
