  • Page 1 REAR TINE TILLER Owner's Manual Models 90102800 17" REAR TINE TILLER 21547000 427490 Rev. 1 03.18.09 Printed in USA...
  • Page 2 REAR TINE TILLER - MODEL NUMBER 90102800 (MFG. ID. NO. 96096000100) HANDLE ASSEMBLY handle_assy_101...
  • Page 3 REAR TINE TILLER - MODEL NUMBER 90102800 (MFG. ID. NO. 96096000100) HANDLE ASSEMBLY ITEM MFG. ARIENS PART NO. DESCRIPTION 165787 21546171 Grip, Handle 425577 21546735 Console Control 8206H 21546825 Handle, Grip 4497H 21546739 Retainer Spring 81328 21546824 Bolt, Shoulder 187497...
  • Page 4 REAR TINE TILLER - MODEL NUMBER 90102800 (MFG. ID. NO. 96096000100) MAINFRAME, LEFT SIDE...
  • Page 5 REAR TINE TILLER - MODEL NUMBER 90102800 (MFG. ID. NO. 96096000100) MAINFRAME, LEFT SIDE ITEM MFG. ARIENS PART NO. DESCRIPTION 73220600 21546776 Nut, Hex 3/8-16 170127 21546184 Shield, Inner Belt Guard 164329 21546166 Pin, Shift Lever 162756 21546161 Lever, Shift...
  • Page 6 REAR TINE TILLER - MODEL NUMBER 90102800 (MFG. ID. NO. 96096000100) MAINFRAME, RIGHT SIDE mainframe_right_Subaru_1...
  • Page 7 REAR TINE TILLER - MODEL NUMBER 90102800 (MFG. ID. NO. 96096000100) MAINFRAME, RIGHT SIDE ITEM MFG. ARIENS PART NO. DESCRIPTION 185190 21546231 Bumper 73970500 21546796 Nut, Hex, Flangelock 19111116 21546279 Washer 11/32 x 11/16 x 16 Ga. 74760512 21546804 Bolt, Hex Head 5/16-18 x 3/4...
  • Page 8 REAR TINE TILLER - MODEL NUMBER 90102800 (MFG. ID. NO. 96096000100) TRANSMISSION 13 15 transmission_7...
  • Page 9 REAR TINE TILLER - MODEL NUMBER 90102800 (MFG. ID. NO. 96096000100) TRANSMISSION ITEM MFG. ARIENS PART NO. DESCRIPTION 188240 21546259 Transmission Assembly (Includes Key Nos. 2-52) 188220 21546257 Gearcase, LH w/Bearing (Includes Key No. 4) 161963 21546160 Gasket, Gearcase 5020J...
  • Page 10 REAR TINE TILLER - MODEL NUMBER 90102800 (MFG. ID. NO. 96096000100) TINE SHIELD tine_shield_17_in_1...
  • Page 11 REAR TINE TILLER - MODEL NUMBER 90102800 (MFG. ID. NO. 96096000100) TINE SHIELD ITEM MFG. ARIENS PART NO. DESCRIPTION 73900500 21546789 Nut, Lock Hex Flange 5/16-18 unc 161415X422 21546147 Shield, Side, Outer L. H. 8393J 21546828 Pin, Stake, Depth 12000035...
  • Page 12 REAR TINE TILLER - MODEL NUMBER 90102800 (MFG. ID. NO. 96096000100) TINE ASSEMBLY...
  • Page 13 REAR TINE TILLER - MODEL NUMBER 90102800 (MFG. ID. NO. 96096000100) TINE ASSEMBLY ITEM MFG. ARIENS PART NO. DESCRIPTION 132673 21546083 Pin, Shear 3146R 21546548 Retainer, Spring 188845 21546270 Tine Assembly 73610600 21546783 Nut, Hex 3/8-24 10040600 21546003 Washer, Lock 3/8...
  • Page 14 REAR TINE TILLER - MODEL NUMBER 90102800 (MFG. ID. NO. 96096000100) DECALS...
  • Page 15 REAR TINE TILLER - MODEL NUMBER 90102800 (MFG. ID. NO. 96096000100) DECALS ITEM MFG. ARIENS PART NO. DESCRIPTION 423701 21546713 Decal, Subaru Tine Shield 423700 21546712 Decal, Belt Guard 401384 21546573 Decal, Tine Shield Forward 110614X 21546048 Decal, Hand Placement...
