Install the JTAGjet USB driver for Linux from the jtagjetdrv_<version>-2.deb package:
dpkg --install
jtagjetdrv_README.txt file.
 Install USBDiag from the USBDiag_<version>.tar archive. Detailed instructions are in the
USBDiag_README.txt file.
In a directory of your choice, unpack SigGdbServer for Linux from the
2.
SigGdbServer-1.07.03.tar.gz tarball.
First Time Run
Make sure that your emulator is connected to a USB port. Execute the USBDiag program to
verify that the JTAGjet USB driver has been installed correctly:
./USBDiag -t
License Installation
A new JTAGjet emulator for Linux comes with a license already installed in the hardware. When
converting (upgrading) a JTAGjet emulator to work with the GDB Server, Signum provides an
appropriate *.lic license file. Copy this file to either the $HOME/Signum/Licenses or
/etc/Signum/Licenses directory. This will make the license available to all your Signum
applications. To make the license available exclusively to the Signum GDB server, put the license
file in the directory where you installed SigGdbServer.

Configuring the Server

Usage

SigGdbServer.exe displays usage information if executed with the –help option, or
without any options:
SigGdbServer Version 1.07 (C) Signum Systems Corp. 2006-2010
Usage:
Options:
-help
-q [<file>]
-s
-reg <file>
Target connection options:
-connect
-connect <sn>
-cpu <cputype>
-nocpu
-emu <file> ...
-emu <n>=<v> ...
-init <file> ...
-term <file> ...
Flash programming options:
-flash <flash-type>[@<address>]
-ram <RAM-size>@<address>
G D B S E R V E R F O R
.
jtagjetdrv_1.2-2.deb
SigGdbServer [options]
- Display help.
- Quiet. Suppress messages or redirect to a file.
- Use in pipe.
- Load peripherals definition file.
- Specify connection via a dialog box.
- Connect to the JTAGjet with serial number <sn>.
- The CPU core type: ARM7TDMI, ARM926EJ-S, C166 etc.
The <cputype>.par file will be used if it exists.
- Ignore any CPU connection errors and continue.
- Set emulation parameters from <file>. CPU dependent.
- Set emulation parameter <n> to <v>. CPU dependent.
- The initialization script file. Board dependent.
- The termination script file. Board dependent.
- Flash type and base address, cfi@0x10_0000.
A R M , X S C A L E A N D
U S E R
Detailed instructions
C O R T E X
M A N U A L
sudo
are in the
