7.1 Channel PCI Express Sound Card
RC-703
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RC-703 and is the answer not in the manual?

Questions and answers

Related Manuals for Rosewill RC-703

Summary of Contents for Rosewill RC-703

  • Page 1 7.1 Channel PCI Express Sound Card RC-703 User Manual...

  • Page 2: System Requirements

     Windows® 2000, XP/2003/Vista/7 (32/64 bit)  DirectX 8.1 above is required Package Contents  1 x RC-703 7.1 Channel PCIe Sound Card  1 x Driver CD  1 x User Manual  1 x Mini-DIN to 3.5mm fan-out cable...

  • Page 3: Hardware Installation

    For Windows® 2000, XP/2003/Vista/7 (32/64 bit) Start your PC, place the Driver CD into the CD-ROM drive. Click the Start button on the taskbar and click Run. Type “D:\RC-703\Setup.exe”. (Assuming you have placed the CD in CD-ROM drive labeled as D).
  • Page 4 7.1 Channel PCI Express Sound Card RC-703 User Manual Physical Connections The rear panel of this 7.1 Channel PCIe Sound Card has the following jacks: Line In (blue): Connect to tape/CD/DVD player, or other audio sources for output mixing and/or recording MIC In (pink): Connect to microphone Line Out (green): Connect to headphone or amplifying speakers.
  • Page 5 In addition to the rear panel jacks, this 7.1 Channel PCIe Sound Card also has the following internal connection: The Function Analog CD/IN Port(Signals: L-G-G-R) Analog CD/IN Port(Signals: G-R-G-L) Thank you for purchasing a quality Rosewill Product. Please register your product at : www.rosewill.com for complete warranty information and future support for your product.
