Summary of Contents for Miu-Audio MKTP-2

  • Page 1 MKTP-2 Class-T stereo Headamp, Preamp and power amplifier www.miu-tech.com USER MANUAL 1 - 15...

  • Page 2: Table Of Contents

    Table of Contents 1. INTRODUCTION 2. FEATURES. 3. OVERVIEW. 3.1 Connection 3.2 Operation 4. SPECIFICATIONS 4.1 Specification of the Amplifier Unit 4.2 Specification of the Headphone Amplifier Unit 4.3 Specification of the Pre Amplifier Unit 4.4 Specification of the AC Adaptor 5.

  • Page 3: Introduction

    1. Introduction Safety Guidelines Thank you for your purchase of Miu-Audio MKTP-2 Class-T stereo Headamp, Important safety instructions Preamp and power amplifier. This product is designed and manufactured to meet strict quality and safety Miu-Audio introduces the mini-size Class-T stereo amplifier MKTP-2 providing standards.
  • Page 4 7 Climate 15. Damage requiring service The equipment has been designed for use in moderate climates and in The equipment should be serviced by qualified service personnel when: domestic situations. the power-supply cord or the plug has been damaged, or objects have fallen, or liquid has spilled into the equipment, or 8.

  • Page 5: Overview

    3. Overview 4. Audio signal line output. 5. Audio input. The audio signal input (LEFT/RIGHT) connects from audio source (e.g. CD player) to the amplifier by the RCA audio cable. 1. Volume Controller and Pre-Amp Power On/Off. 6. Power ON/OFF switches; pull up to power off the amplifier and pull 2.

  • Page 6: Connection

    3.1 Connection 4. Specifications The mini series is easy to use product. Simply connect your source (CD 4.1 Specification of the Power Amplifier Unit player, MP3 player, etc..) and speakers following below steps, you can enjoy the high quality music in a second: T-Amp IC Tripath TA2024 Connect “Line Out”...

  • Page 7: Specification Of The Pre Amplifier Unit

    5. Technical Notes (for professional user only) Vacuum Tube 6DJ8/6922 series or 12AU7 series Miu-Audio has already pre-set the jumpers and fine-tuned the DC bias voltage (exchangeable) of each MKTP-2 with the packaged vacuum tube before shipping. However, Signal-to-Noise Ratio (SNR)

  • Page 8: Dc Bias Voltage Tuning

    6. Troubleshooting 5.1 DC Bias Voltage Tuning If your machine is out of order, it may not be very serious. Before you call your Since each tube might derivate a bit in parameters, especially from different local distributor or us to repair, you are suggested to check the following: series, it needs to re-tune the DC bias voltages to guarantee the machine is working in the best point and performing the best sound quality.

  • Page 9: Accessories

    7. Accessories . 3.5MM jumper cable x 1 . RJ45 to speaker binding post adaptor x 1 . 2.1MM Power bifurcation line x 1 . Tube x1 . +12V power supply x 1 Website: www.miu-tech.com Email: info@miu-tech.com - END - - 15 -...
