Thank you for choosing the AubeTH115 a programmable
thermostat that provides both energy savings and comfort
TH115 Description
Buttons and symbols
On/Stand By Switch
Use this switch to put the thermostat in sleep mode
when its use is no longer required (e.g. summer).
This will not affect the clock programming.
GFCI Warning Light and Test Button
Day & Clock Settings
Programming Mode
Mode Selection/Exit Programming
Floor/Ambient (Amb. only with B)
Current Mode Auto, Manual, Vacation
Current Program Number
Increase/Decrease Temperature
24/7 Installation Support • Lifetime Technical Assistance • Free Design Service • www.WarmlyYours.com • (800) 875-5285
F
Control Module Installation
Align the bracket tabs on the control module with the
holes located on top of the power base.
Control module
Power base
NOTE:
Keep the thermostat's air vents clean and free
from obstructions.
NOTE:
The screw cannot be removed completely.
First Power ON
When power is applied for the first
time, the LCD dispays: 0:00, MO
(Monday),
and temperature of the
floor .
Press HOUR - MIN to set the
current time.
Press DAY to set current day.
For AF and F models:
following messages may be displayed
if the installation is incorrect:
LO: The floor temperature is below
32ºF (0ºC), or the temperature
sensor is defective, or not con-
nected.
The heating indicator
played and the relay is closed
(energized).
HI: The floor temperature is above
140°F (60°C), or the tempea-
ture sensor is defective.
TH115 -F-120GA
Owners Guide
Correct
one of the two
Incorrect
i is dis-
10103-A 04/08
