Photoelectric smoke alarms are generally more effective at detecting smoldering fires which smolder for hours before bursting
into flame. Sources of these fires may include cigarettes burning in couches or bedding.
MAIN FEATURES
AC/DC operated photoelectric type smoke alarm
•
Photoelectric sensor
•
Hush / Test Feature
•
High and stable sensitivity
•
With quick fix mounting bracket and simple AC connector
•
Easy installation
•
Fitting and battery tamper-resist feature
•
Inter-connectable up to 40 units
•
2 color LED indicator (Alarm and AC power indicator)
•
Extra loud alarm sound over 85dB
•
Low-battery and battery missing warning indicator
•
Auto-reset when smoke clears
•
SPECIFICATION
•
Model Number:
•
Operation Temperature:
•
Power Source:
•
Battery Back-life:
•
Standby Current (9V battery):
•
Alarm Current (9V battery) :
•
Alarm Sound Level:
•
Humidity Rating:
•
Interconnect Quantities:
•
Sensitivity to Smoke:
•
Compact size:
•
Note: This smoke alarm can only be interconnected with other Channel Safety Systems alarms as specified.
IMPORTANT SAFETY INFORMATION
1 . This smoke alarm requires constant 220-240V AC 50Hz mains power supply to operate properly. .Backup 9V DC battery will offer
additional protection in the event of power failure. This smoke alarm WILL NOT work if AC power is not connected or has failed or been
interrupted for any reason, AND if the backup battery is removed, drained or improperly connected, the alarm will not work during a
power failure. DO NOT use any other kind of battery except as specified.
ISSUE 2 02-2012
Smoke Alarm User's Manual
MODEL: F/CDA/OPT
OPTICAL SMOKE ALARM
CDA/OPT
5 to 45
220-240V AC 50Hz and 9V DC Battery back-up
In the event of a break in the mains supply
the battery will give detector operation for 1 year minimum
15u A max
20m A max
85 decibels at 3m(10 feet)
10%-90%
20 smoke detectors and/or heat detectors
3.0-6.0 %Obs /m
110mm diameter
Advertisement
Table of Contents
Summary of Contents for RESitech F
- Page 1 Smoke Alarm User’s Manual MODEL: F/CDA/OPT OPTICAL SMOKE ALARM Photoelectric smoke alarms are generally more effective at detecting smoldering fires which smolder for hours before bursting into flame. Sources of these fires may include cigarettes burning in couches or bedding.
- Page 2 2 . The push-to-test button accurately tests all smoke alarm functions. Do not use any other test method. Test smoke alarm weekly to ensure proper operation. 3 . DO NOT cut off AC power supply or remove or disconnect backup battery to silence unwanted alarms. This will remove your protection.
- Page 3 INSTALL SMOKE ALARMS 300mm) CEILING MINIMUM BEST HERE NEVER HERE Within 600mm of apex SIDEWALL Do not install smoke alarms 1. Near appliances or areas where normal combustion regularly occurs (kitchens, near furnaces, hot water heaters). Use specialized smoke alarm with unwanted alarm control for this areas. 2.
- Page 4 If interconnection is required, connect yellow wire from connector to interconnect wire between smoke alarms. See section interconnecting smoke alarms. If this detector is to be used as a single-station detector, ensure the yellow wire is insulated correctly. Open the battery compartment. Connect new 9-volt battery to battery connector inside battery compartment.
-
Page 5: Battery Replacement
2. Use a proprietary artificial smoke dispenser tool DO NOT USE A HAND HELD SMOKE AEROSOL. USE OF HAND HELD SMOKE AEROSOLS WILL DAMAGE THE UNIT AND INVALIDATE THE WARRANTY 3. The push-to-test button accurately tests functions. 4. Test smoke alarms weekly. 5. - Page 6 Note: If the unit fails to operate when being tested, Please refer to “TROUBLESHOOTING”. CHOOSING A REPLACEMENT BATTERY: The unit requires one standard 9V battery. The following batteries are acceptable as replacements: Duracell, Eveready, Powersonic. CLEANING Clean the smoke alarm at least once a month to remove dust, dirt, or debris. Using the soft brush or wand attachment to a vacuum cleaner, vacuum all sides and cover of smoke alarm.
