Summary of Contents for NetComm Profile SureFit
-
Page 1: User Guide
PROFILE ™ SureFit User Guide 405-SF 405-FLEX-SF 405-UNC-SF Profile Mobile... -
Page 2: Table Of Contents
Profile SureFit Components ........ -
Page 3: Introduction
Wearing styles can be easily changed by fitting the headset with appropriate snap-on/snap-off components. If after reviewing this guide you have any questions concerning the Profile SureFit headset, please call your distributor or contact GN Netcom, Inc. Customer Service at 800-826-4656. -
Page 4: Surefit Flexible Earhook
SureFit Flexible Earhook The Profile SureFit headset comes out of the box with the SureFit flexible earhook installed (see Figure 2). The earhook is worn on the ear and can be reshaped for a comfortable and secure fit. SureFit Flexible Earhook Wearing Use your fingers to grasp and reshape the gray area of the earhook. - Page 5 Changing Ears Rotate the microphone boom 180° and swing the earhook around to the other side of the speaker (see Figure 4). Removal 1. Position the receiver assembly with the speaker side up and the microphone boom at 12 o’clock (see Figure 5). Figure 4 2.
-
Page 6: Earloop
Earloop The Profile SureFit headset can be fitted with a choice of earloop sizes. An earloop completely encircles the ear and positions the speaker directly over the ear canal. Four earloops are supplied, each marked as follows: X (Extra Small), S (Small), M (Medium) and L (Large). The size mark appears near the thinnest portion of the earloop. - Page 7 Changing Ears No adjustments are necessary. Simply turn the headset over to wear on the opposite ear. Earloop Wearing 1. Swing the earloop away from the receiver to form a “V” (see Figure 9). 2. Position the back of the earloop behind the ear and gently pull forward until the speaker rests on the ear.
-
Page 8: Headband
Headband The Profile headset can also be equipped with a fully adjustable, lightweight headband. Installation 1. Remove the earhook or earloop. 2. Align the mounting post on the receiver over the headband mounting ring (covered by a foam cushion). The mounting post fits into a notch on the headband mounting ring (see Figure 10). - Page 9 Changing Ears To accommodate left or right ear wearing styles, rotate the microphone boom over the headband (see Figure 12). Do not force the microphone boom beyond the built in stops! Figure 12 Changing Ears Headband Wearing Position the headset lightly on your head (see Figure 13). The Stay-Put™ click-stop headband lengthens and shortens to the desired length for a custom fit (pull to lengthen, push to shorten).
-
Page 10: Microphone Positioning
Microphone Positioning For all Profile SureFit headsets, the microphone boom should be adjusted so that the microphone is approximately one half inch (12 mm) below and away from your lower lip (see Figure 14). The 405-FLEX-SF and Profile Mobile are equipped with a noise-canceling microphone, and the 405-UNC-SF is equipped with an ultra-noise-canceling microphone. -
Page 11: Connecting To Your Telephone
Connecting to Your Telephone An amplifier is often needed to connect the headset to the telephone or telephone system. For these applications, the headset is equipped with a Quick Disconnect plug which mates to a Quick Disconnect jack on the amplifier. Follow the instructions supplied with the amplifier to connect the headset and amplifier to your telephone or telephone system (see Figure 18). -
Page 12: Cautionary Notes To Computer Users
Cautionary Notes to Computer Users When using any headset with a computer, care should be taken in dry or low humidity environments to protect the user from electrostatic discharge from the monitor (CRT). Computer monitors can induce a substantial electrostatic charge when turned on or off, or when there is a power failure, and the resulting electrostatic discharge can be passed through the headset to ground. -
Page 13: To Obtain Service
• The responsibility of GN Netcom, Inc. under this warranty shall be limited to the repair or replacement of the product at the sole discretion of GN Netcom, Inc. • Any implied warranty on GN Netcom, Inc. products is limited to two years from the date of purchase on all parts, including the cords and connectors. - Page 14 77 Northeastern Blvd. • Nashua, NH 03062 USA 1-800-826-4656 • www.gnnetcom.com 406850-A Printed in USA December 1998...
