Summary of Contents for Compex LinkPort ENET-C
- Page 1 Compex LinkPort PCMCIA Ethernet Card ENET-C User’s Manual Version 1.1C...
- Page 2 Compex LinkPort PCMCIA Ethernet Card ENET- User’s Manual Version 1.1C M-0270-V1.1C Manual Number: September 2000 Manual Release Date: Printed in the Republic of Singapore...
-
Page 3: Important Information
Compex, Inc. will not be liable for any technical inaccuracies or typographical errors found in this guide. Changes are periodically made to the information contained herein and will be incorporated into later versions of the guide. -
Page 4: Declaration Of Conformity
DECLARATION OF CONFORMITY Manufacturer’s Name: Compex, Inc Manufacturer’s Address: 4051 E. La Palma, Unit A Anaheim, CA 92807 U S A Compex, Inc. declares that the product: Product Name: Compex LinkPort, PCMCIA Ethernet Card Model Number: ENET-C conforms to the following Product Standards:... -
Page 5: Fcc Notice
FCC Notice This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 6: Table Of Contents
Contents Coverage Page Page I Disclaimer Page II Declaration of Conformity Page III FCC Notice Page IV English Version Page 1-10 Chapter 1 : Introduction Page 1 Features Page 1 Hardware Description Page 2 Diagrams Page 3 Chapter 2 : Installing the Adapter Page 4 Procedure... -
Page 7: Features
International Association) Ethernet card [ENET-C] is a credit card sized network adapter that can be used for PCMCIA compliant personal computers. The Compex LinkPort PCMCIA Ethernet card plugs into a Type II PCMCIA slot, providing a 16-bit bus interface. The card is switchless, software configurable, and provides full support for the PCMCIA Card Information Structure (CIS). -
Page 8: Hardware Description
Hardware Description v PCMCIA card The Compex LinkPort PCMCIA Ethernet card’s main PCB board is encased in a stainless compact frame. It has a 68-pin connector that fits into a PCMCIA socket,. and a 15-pin flat connector that connects to the media coupler. -
Page 9: Diagrams
Diagrams Figure 1-1: Compex LinkPort PCMCIA Ethernet Card LINK LED ACT LED Figure 1-2: Media Coupler with UTP connectors English Compex LinkPort PCMCIA Ethernet Card... -
Page 10: Installing The Adapter
Power ON the PC. Hardware installation is now complete. Switch ON the PC. The Compex LinkPort PCMCIA Ethernet Card receives its power from the PC. Warning: To avoid accidents, do not connect or disconnect cables, or perform installation or maintenance of the card during an electrical storm. -
Page 11: Removing The Card
Removing the Card: Procedure: To remove the Compex LinkPort PCMCIA Ethernet Card from the PC, do as follows: Power OFF the machine. Remove from the coupler the UTP cable from the RJ-45 socket. Remove the media coupler from the Compex LinkPort PCMCIA Ethernet Card. -
Page 12: Diagrams
Figure 2-1: Inserting the Card into the Type II PCMCIA socket Compex LinkPort PCMCIA Ethernet Card 15-Pin Flat Connector Ethernet Hub (10Mbps) UTP (RJ-45) Connector UTP Cable UTP (RJ-45) Figure 2-2: Plug the 15-pin connector to the 15-pin mating connector English Compex LinkPort PCMCIA Ethernet Card... -
Page 13: Introduction
Chapter 3 :Software Installation Introduction: Enabler program: ECARD.EXE ECARD enabler is provided to configure Compex LinkPort / ENET-C in DOS environment. Before any driver (either loaded from Config.sys or Autoexec.bat or any batch file) can initialize the adapter, ECARD must be run first to configure it. -
Page 14: Ecard.exe Utility
As new and updated Network Operating Systems become available, update drivers and new release disk will be made available in the Compex Website, FTP site and BBS servers. For details, refer to Appendix B. Compex LinkPort PCMCIA Ethernet Card... - Page 15 Appendix A Technical Information Compex LinkPort PCMCIA Ethernet Card System Configuration PCMCIA compliant computers IEEE 802.3 standard, PCMCIA release Standard Conformance 2.1 Type II, JEDIA 4.1 16-bit Bus-Width I/O Base Address 200H to 3E0H in steps of 20H; Default IOP: *300H Interrupt 3, 4, 5*, 7, 9, 10, 11, 12, 15.
-
Page 16: Technical Support
Appendix B Technical Support If you encounter a specific problem and need our assistance, this appendix explains how you can get Technical Support worldwide from Compex. When you have a problem When you encounter a problem, please do the following: Ensure that you have sent in the product’s Warranty Registration Card. - Page 17 NOTES...
- Page 18 135, Joo Seng Road #08-01, PM Industrial Building Singapore 368363 Tel: (65) 286-1805 (8 a.m.-5 p.m. local time) Call Fax: (65) 283-8337 BBS: (65) 282-8854 (24-hour access) support@compex.com.sg E-mail: Internet ftp.compex.com.sg access/ FTPsite: http://www.cpx.com Website: http://www.compex.com.sg English Compex LinkPort PCMCIA Ethernet Card...
- Page 19 Quick Install Guide “ ” E. La Palma, Unit A Compex, Inc. Anaheim, CA 4051 92807 USA (714) 630-7302 2000 by Compex, Inc. All rights reserved. Printed in Singapore Compex 16 – Port All 10/100 Switch (DS1216) Manual Number: M-0272-V1.1C Version 1.1C...
