Aimmer technology AMI-I845GV-ISA User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

http://www.aimmertech.com
AMI-I845GV-ISA
Mainboard
User's Manual
Rev：1.1
2007.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMI-I845GV-ISA and is the answer not in the manual?

Questions and answers

Summary of Contents for Aimmer technology AMI-I845GV-ISA

  • Page 1 AMI-I845GV-ISA Mainboard User’s Manual Rev：1.1 2007.1...

  • Page 2: Table Of Contents

    http://www.aimmertech.com CONTENTS Chapter 1 Package Contents ....................3 Chapter 2 Introduction......................4 Chapter 3 Mainboard Locations....................6 Chapter 4 Installation........................7 Jumper Setting and Slot ....................7 CPU Installation......................8 Memory installation ....................10 IDE Devices Installation .....................10 Other Device Installation ....................10 Chapter 5 Driver Installation....................13 Installation Directory ....................13 Intel Chipset Software Setup..................13 Sound Driver Setup.....................16 5.4 USB 2.0 driver Setup .....................18...

  • Page 3: Chapter 1 Package Contents

    http://www.aimmertech.com Chapter 1 Package Contents Your mainboard package contains the following items: 1 One mainboard 2 One 80-Pin Ultra DMA 66/100 IDE drive ribbon cable 3 Software install CD 4 One I/O Backboard...

  • Page 4: Chapter 2 Introduction

    http://www.aimmertech.com Chapter 2 Introduction This mainboard has the Intel 845 chipset that contains Intel 82845GV Memory Controller Hub and Intel 82801DB I/O Controller Hub. This mainboard has a Socket-478 support for Intel Pentium4 processors with front-side bus(FSB)speeds up to 400/533,supports DDR200/DDR266 memory bus,...
  • Page 5 http://www.aimmertech.com One floppy port support format 360K/720K/1.2M/1.44M/2.88M disk driver One serial ports One parallel port maximum four extra ports) One PS/2 Keyboard port One PS/2 Mouse One MIDI port One IrDA port support 115.2KB/S transfers data. -Onboard AC’97 2.0 specification compliant Support 16bit stereo codec Multiple stereo input mixer Provides onboard Line-in jack, Line-out jack, Microphone-in jack...

  • Page 6: Chapter 3 Mainboard Locations

    http://www.aimmertech.com Chapter 3 Mainboard Locations...

  • Page 7: Chapter 4 Installation

    http://www.aimmertech.com Chapter 4 Installation Jumper Setting and Slot FSB CPU Frequency Jumper Setting JUPER AUTO （Default） OPEN JP3：Clear CMOS Jumper Setting 1-2（Default） Normal Clear CMOS Audio：Front panel Jumper setting Function Function MIC+ Ground Vbias AuD_Vcc(AVCC) AuD_R_Out AuD_R_Out Back N.C. AuD_L_Out AuD_L_Out Back USB: Expansion Connector Function...

  • Page 8: Cpu Installation

    http://www.aimmertech.com PCI1/PCI2 32 bit PCI BUS Expansion Slots AGP Expansion Slots ISA Expansion Slots Connectors PS/2（Bottom） PS/2 Keyboard(Down Purple) PS/2（Top） PS/2 Mouse Header(Up Green) USB1/2 USB1/2 Connector Port USB3 USB3 Connector Port Printer Connector Port VGA Display Connector Port COM1 Serial Ports COM1 Connector Port MIDI MIDI Port...
  • Page 9 http://www.aimmertech.com Unhook the CPU socket’s locking lever by pulling it away from socket and raising it to the upright position. Match the pin 1 corner of CPU socket to the one of processor, and insert the processor into the socket. Do not use force. Push the locking lever down and hook it under the latch on the edge of socket.

  • Page 10: Memory Installation

    http://www.aimmertech.com Memory installation This mainboard supports DDR200/DDR266 DDR memory ， you may install 64/128/256/512MB 184 pin DDR memory。DDR SDRAM uses additional power and ground lines and requires 184-pin 2.5V unbuffered DIMM module rather than the 168-pin 3.3V unbuffered DIMM used by SDRAM. Follow these instructions to install the Memory: 1.
  • Page 11 http://www.aimmertech.com The mainboard ships with a floppy disk drive cable that can support one or two drives. Drives can be 3.5” or 5.25” wide, with capacities of 360K, 720K, 1.2MB, 1.44MB, or 2.88MB. Install your drives and connect power from the system power supply. Use the cable provided to connect the drives to the floppy disk drive connector floppy.
  • Page 12 http://www.aimmertech.com system may become unstable and may experience difficulty powering up if the power supply is inadequate. Note2: Do not forget to connect the 20-pin ATXPWR1 and 4-pin ATX12V1 power plugs. Failure to do so may cause severe damage to the CPU or motherboard!

  • Page 13: Chapter 5 Driver Installation

    http://www.aimmertech.com Chapter 5 Driver Installation 5.1 Installation Directory The utility CD is supplied with that mainboard the connects contained in it are showed as below: Directory Driver Windows 9x INTEL\INF\XXX Intel chipset software Windows 2000/XP Windows NT4.0 Windows 9x SOUND\REALT Realtek AC’97 Audio Windows 2000/XP EK\XXX...
  • Page 14 http://www.aimmertech.com Click“NEXT”to continue Select“YES” to continue...
  • Page 15 http://www.aimmertech.com Select“NEXT” to continue Select“FINISH” to complete the installation.

  • Page 16: Sound Driver Setup

    http://www.aimmertech.com Select“Finish”to complete the installation Sound Driver Setup 5.3.1 Sound driver setup Insert the driver CD, running driver software CD, choose the directory:\CD-ROM:\SOUND\REALTEK\Setup.exe Select“Next”to continue...
  • Page 17 http://www.aimmertech.com Continue Select“YES” to continue Select“Finish”to complete the installation -Channel Sound Output Support peration（optional） ： Please follow the steps below for o 1.After install sound driver，click “Sound effect”， “AC9 7 Audio configuration”options；...

  • Page 18: Usb 2.0 Driver Setup

    http://www.aimmertech.com 2.Click “Sound configuration”，select “6 Channel mode for 5.1 speakers output” options。 3.Click “So und effect” menu “Environment”，you must choose one Sound effect realization 6-Channel sound output。 .3.2 Uninstalltion Sound Driver (For Realtek of WIN98 operation system) Startup to WINDOWS desktop， select“Setup”/“Control Panel”， select“Add/Delete” menu select“Avance AC’97 Audio Driver and Applications”...
  • Page 19 http://www.aimmertech.com Select“YES” to continue Select“Finish”to complete the installation...

  • Page 20: Chapter 6 Bios Setup

    http://www.aimmertech.com Chapter 6 BIOS Setup The BIOS Setup Utility record settings and information of your computer, such as date and time, the type of hardware installed, and various configuration settings. Your computer applies those information to initialize all the components when booting up and basic function of coordination between system components.

  • Page 21: Standard Cmos Features

    http://www.aimmertech.com require your answer Yes or No by hitting the Y or N keys. If you have already changed the setup utility, press F10 to save those changes and exit the utility. Standard CMOS Features Setup date、time、floppy type Advanced BIOS Features Setup BIOS provides function，for example virus、boot-strap induct Advanced Chipset Features Setup mainboard chipset parameter，for example DRAM Timing...

  • Page 22: Advanced Bios Features

    http://www.aimmertech.com These items set up system date Time（hh：mm：ss） These items set up system time Pri/Sec Master/Slave These items configure devices connected to the Primary and Secondary IDE channels. To configure an IDE hard disk drive, choose Auto. If the Auto setting fails to find a hard disk drive, set it to User, and then fill in the hard disk characteristics manually.
  • Page 23 http://www.aimmertech.com Quick Power On Self Test Default：Enabled Swap Floppy Drive If you have two diskette drives installed and you enable this item, drive A becomes drive B and drive B becomes drive A. Boot Up Floppy Seek Default：Disabled Boot Up NumLock Status Default：On Gate A20 Option Default：Fast...

  • Page 24: Advanced Chipset Features

    http://www.aimmertech.com Advanced Chipset Features DRAM Timing Selectable Default: By SPD X CAS Latency Time X Active to Precharge Delay X DRAM RAS# to CAS# Delay X DRAM RAS# Precharge Memory Frequency For Default：DDR266 Memory frequecce enabled select DDR200/DDR266 System BIOS Cacheable Default：Enabled If enable system BIOS read cache Video BIOS Cacheable...

  • Page 25: Integrated Peripherals

    http://www.aimmertech.com Integrated Peripherals IDE DMA transfer access Default：Enabled On-Chip Primary/ Secondary PCI IDE Default：Enabled Chipset inside the first/second channel of PCI IDE interface IDE Primary/Secondary Master/Slave PIO Default：Auto The first/second IDE primary master/primary slave control PIO mode IDE Primary/ Secondary Master/Slave UDMA Default：Auto USB Controller Default：Enabled...

  • Page 26: Power Management Setup

    http://www.aimmertech.com Onboard Parallel Port Default：378/IRQ7 Setup select paralled port Parallel Port Mode Default：SPP Setup paralled port mode X EPP Mode Select Default：EPP1.7 X ECP Mode Use DMA Default：3 Power Management Setup ACPI Function Setup if use ACPI function Default：Enabled Power Management Default：User Define Video off Method Setup video off method...

  • Page 27: Pnp/Pci Configurations

    http://www.aimmertech.com X Resume Time (hh:mm:ss) Default：0:0:0 **Reload Global Timer Events** Primary/ Secondary IDE 0/1 Default：Disabled FDD,COM,LPT Port Default：Disabled PCI PIRQ [A-D] # Default：Disabled PnP/PCI Configurations Reset Configuration Data When select Enabled the BIOS restart write system configuration data Default： Disabled Resources Controlled By System resources parameter setup Default：Auto(ESCD)

  • Page 28: Load Optimized Defaults

    http://www.aimmertech.com If you select this item and press enter a dialog box appears. If you press Y, and then Enter, the setup utility loads a set of fail-safe default values. These default values are not very demanding and they should allow your system to function with most kinds of hardware and memory chips.

  • Page 29: Change Password

    http://www.aimmertech.com 6.10 Change Password If you highlight this item and press Enter, a dialog box appears that you can enter a supervisor password. You can enter no more than six letters or numbers. Press Enter after you have typed in the password. There will be the second dialog box asking you to retype the password for confirmation.
  • Page 30 http://www.aimmertech.com Highlight this item and press Enter to save the changes that you have made in the setup utility configuration and exit the program. When the save and exit dialog box appears, press Y to save and exit, or press N to exit without saving.
