ATG Electronics® QDriver™ 18W LED Power Supply
USER GUIDE
Part Number
HPS-12018-Z00000-AM
HPS-12018-Z00000-EU
NOTE:
This user guide is to explain the steps necessary to use the specified and assure peak performance. Its
intended use is for reference only, by a fully qualified electrician or technician. This document should
never be considered a substitute for any provision of a regulation or state and/or local code.
Please read this entire manual to fully understand and safely use this product.
Specifications are subject to change without notice. Please visit
user guide versions.
GETTING STARTED
ATG Electronics® QDriver™ 18W LED Power Supply is a universal device that operates on input voltage
ranging from 90VAC-250VAC, and provides 1.5A amperes of
(nominal) to LED lighting fixtures, controllers or decoders etc.
QDriver™ 18W comes with a 1.5 meter (4.92 feet) long power cord with American plug or European plug
to suit different interface. It also has a 1.5 meter (4.92 feet) long cable, which can directly attach to ATG
Electronics products or via power adaptor board.
QDriver™ 18W is contained in a compact plastic housing and rated as IP67 degree (applicable for dry,
wet and damp environment). The slim profile makes it suitable for most confined spaces; and mounting
brackets at both ends of the power supply can enable customers to install it easily.
QDriver™ 18W is the ideal and cost effective solution for driving a small quantity of 12VDC LED lighting
fixtures, controllers or decoders etc. It has successfully been installed with thousands of LED lighting
systems in the world.
Included in this Box
QDriver™ 18W LED Power Supply, 1 PCs
User Guide, 1 Set
Unpacking
1) Unpack and carefully examine the product.
2) Report any damage and save all packing materials if any part is damaged during transport.
3) Do not attempt to use this apparatus if it is damaged.
www.atgelectronics.com
for most recent
filtered and regulated
12VDC power
ATG
Electronics Corp.
Light your world
Color your life!
Advertisement
Table of Contents
Related Manuals for ATG Electronics QDriver HPS-12018-Z00000-AM
Summary of Contents for ATG Electronics QDriver HPS-12018-Z00000-AM
- Page 1 GETTING STARTED ATG Electronics® QDriver™ 18W LED Power Supply is a universal device that operates on input voltage ranging from 90VAC-250VAC, and provides 1.5A amperes of filtered and regulated 12VDC power (nominal) to LED lighting fixtures, controllers or decoders etc.
- Page 2 Note: The instructions and precautions set forth in this user guide are not necessarily all-inclusive, all conceivable, or relevant to all applications as ATG Electronics cannot anticipate all conceivable or unique situations. PLANNING THE INSTALLATION This device installation requires planning to ensure timely, successful installation with minimal complications and down time.
- Page 3 * Detailed specifications please refer to the product catalog of QDriver™ 18W LED Power Supply. QUALITY WARRANTY This product is sold pursuant to ATG Electronics Standard Terms and Conditions which can be found at www.atgelectronics.com/warranty and which contain important provisions, including, among others, the Quality Warranty, exclusions and limitations on ATG Electronics liability for damages, and restrictions on available remedial actions.
