- Page 1 ARROW 50T and Portable audio link USER MANUAL ED 07/06...
-
Page 2: Table Of Contents
BASIC USER’S MANUAL AEQ ARROW 50T FRONT VIEW DESCRIPTION OF THE UNIT GENERAL CHARACTERISTICS TECHNICAL SPECIFICATIONS STARTING TO WORK POSSIBLE PROBLEMS AND SOLUTIONS ASSOCIATED EQUIPMENTS CHANNEL FREQUENCIES LIST AUDIO SIGNAL INPUT/OUTPUT CODES BASIC USER’S MANUAL AEQ ARROW 50R FRONT VIEW... -
Page 3: Front View
ARROW 50T FRONT VIEW ARROW 50 T and 50R PORTABLE AUDIO LINK... -
Page 4: Description Of The Unit
ARROW 50T DESCRIPTION OF THE UNIT The system AEQ ARROW 50T base transmitter is a long range radio link with broadcast quality audio, designed for easy handling and high reliability. This device is implemented using the latest electronic and manufacturing technologies (SMT) and high quality components. -
Page 5: General Characteristics
ARROW 50T GENERAL CHARACTERISTICS • To be used for radio-diffusion link. • Multi-channel system (synthesized by PLL) • Select mic/line audio input • Compressor/limiter • High quality audio • FM bandwidth emission • Power 115/220 VAC internally selectable • In rear panel optionally is equipped a BNC connector, used to activate RF... -
Page 6: Technical Specifications
ARROW 50T TECHNICAL SPECIFICATIONS RADIO Frequency range: 174−500 MHz, window of 20 MHz dependin g on version (a,B,C) Power: 30W, 100%, duty cycle, delayed ON Channels: 16, PLL digital. Ch selector: 2 digit decimal encoder, delayed. Modulation: +/− 30 Khz pre−enphasis 50/75us... - Page 7 ARROW 50T STARTING Please check that you are using the appropriate antenna and it is correctly connect, because the equipment have a high RF power. After this, you must do the following: If you use 115/220 VAC, connect the cable, checking that the ON/OFF switch is in OFF.
-
Page 8: Possible Problems And Solutions
ARROW 50T POSSIBLE PROBLEMS AND SOLUTIONS 1. SWITCH ON the 12V indicator is not lighting: Check that the cable is correctly connected. Check that the DC bridge is correctly placed. Check fuse status. 2. SWR indicator is lighting: Check the antenna position and connection are correct. -
Page 9: Associated Equipments
ARROW 50T ASSOCIATED EQUIPMENT • AEQ ARROW 50R base receiver • 3 Elements standard Yagi antenna, 9,5 dBi • Magnetic base antenna, usually mounted over the top of moving vehicles. ARROW 50 T and 50R PORTABLE AUDIO LINK... -
Page 10: Audio Signal Input/Output Codes
ARROW 50T CHANNEL TX FREQUENCIES LIST ARROW 50T AUDIO SIGNAL INPUT/OUTPUT CODES: One XLR3 F to audio input mic/line UHF Tx: Phase + Phase - XLR4 F 12 V DC: ARROW 50 T and 50R PORTABLE AUDIO LINK... -
Page 11: Front View
ARROW 50R FRONT VIEW ARROW 50 T and 50R PORTABLE AUDIO LINK... -
Page 12: Description Of The Unit
ARROW 50R DESCRIPTION OF THE UNIT The Base receiver AEQ ARROW 50R has been designed to cover a lot of applications together with the mobile transmitter AEQ ARROW 50T or with the compact mobile transmitter AEQ ARROW MIXER, with the main following characteristics: •... -
Page 13: Controls, Indicators And Accesories
ARROW 50R CONTROLS, INDICATORS AND ACCESORIES FRONT PANEL: 1.- ON/OFF switch 2.- RSSI Indicator 3.- VU-METER 4.- Phones output jack ¼” 5.- Headphones volume control 6.- Channel selectors 7.- Channel indicator 8.- Squelch potentiometer 9.- Power indicator REAR PANEL: 1.- Input RF (N-F connector) 2.- Output line (XLR3 connector) 3.- Input power (Powercom connector) 4.- Input 12V DC (XLR4 connector) -
Page 14: Technical Specifications
ARROW 50R TECHNICAL SPECIFICATIONS RADIO Frequency range: 174−500 MHz, window of 20MHz depending on versions (A,B,C) Sensitivity: −112dBm / 12dB SINAD Channels: 16, PLL digital Ch selector: 2 digit decimal encoder, delayed Demodulation: +/− 30 KHz de−emphasis 50/75us (other standar ds upon request) imput impedance: 50 ohms... - Page 15 ARROW 50R STARTING 1. Connect the cable with Powercom In/Out connector and the “bridge” if you use 12V DC 2. Connect the antenna 3. Choose the channel 4. Connect the receiver at the minimum volume 5. Check the status in the front panel indicators. ARROW 50 T and 50R PORTABLE AUDIO LINK...
-
Page 16: Possible Problems And Solutions
ARROW 50R POSSIBLE PROBLEMS AND SOLUTIONS 1. If the receiver is connected and there is not audio: Check the power connection Check that Tx and Rx are in the same channel. Check the volume Check the antennas. 2. If you use several systems and you obtain interferences: Check the channels to prevent intermodulations Check that you don’t have two equipments working in the same frequency 3. -
Page 17: Audio Signal Input/Output Codes
ARROW 50R CHANNEL RX FREQUENCIES LIST ARROW 50R AUDIO SIGNAL INPUT/OUTPUT CODES: One XLR3 F to audio input mic/line VHF Tx: Phase + Phase - One Jack stereo ¼” output signal from UHF Rx XLR4 F 12 V DC: ARROW 50 T and 50R PORTABLE AUDIO LINK...
