How to Use Your Control Panel

The Control Panel interface consists of 3 columns of buttons. They are: HOME SECURITY, CODE, and HOME CONTROL.
There is a non-medical EMERGENCY button located on the far right.
HOME SECURITY
ARM Doors & Windows.
rity system protection on for all protected doors and windows.
If a door or window is open when you arm the system, it will
be bypassed, meaning not protected. The SYSTEM STATUS
light will be lit.
Press twice to eliminate the preprogrammed entry delay. The
ARM Doors & Windows button blinks when No Entry Delay is
on.
ARM Motion Sensors.
for all intrusion Motion Sensors. Use when no one is home.
This is usually used in combination with ARM Doors & Win-
dows.
Press twice to activate Latchkey. Latchkey is used to notify
parents if children do not arrive home at a predetermined time
and disarm the system. The ARM Motion Sensors button
blinks when Latchkey is on.
DISARM.
Press once and enter your access code using
the CODE buttons to turn security protection off. Some sen-
sors, for example smoke detectors and panic devices, are still
active even when the system is disarmed.
HOME
SECURITY
Press once to turn the secu-
Press once to turn protection on
CODE
HOME
1 - 2 CONTROL
ARM
Doors &
Windows
3 - 4
ARM
Motion
Sensors
5 - 6
DISARM
7 - 8
SYSTEM
STATUS
9 -
Test Weekly
SYSTEM STATUS.
about your system. If the button is lit, there is a problem with
the system. If the button is blinking, an alarm has occurred.
Press the button to hear what is wrong with the system. See
"System Tests & Trouble Beeps" on page 14.
CODE
There are 5 CODE buttons located on the left side of the Con-
trol Panel. Each button represents 2 numbers. The top CODE
button is 1 - 2 which means that this button is pressed when
entering either 1 or 2. For example, if your access code is 1-
2-3-4 you must press the 1 - 2 button twice and the 3 - 4 button
twice.
If your system includes 24-hour protection sensors on items
such as gun or jewelry cases, you must subdisarm the Control
Panel before accessing these areas to avoid causing an
alarm. To subdisarm the system when it is already disarmed,
enter the master access code. The DISARM button will flash
when the Control Panel is subdisarmed.
CHIME
Doors
CHIME
Special
Motion
EMERGENCY
LIGHTS
Time
Activated
LIGHTS
Sensor
Activated
Press twice to hear information
