Summary of Contents for TrekStor i.Beat 300

  • Page 1 User Manual ��� ���������������...
  • Page 2 Trekstor GmbH & Co. KG. i.Beat 300 is a registered trademark of Trekstor GmbH & Co. KG.

  • Page 3: Table Of Contents

    3. Preset status Beginning 4. Record broadcasting Package Contents Recording mode Name of parts Navigator mode LCD display IMAGE viewer mode Using i.Beat 300 TEXT viewer mode Basic function Games 1. Power on/off Using MENU 2. Volume Control 3. Hold MENU To change mode 1.
  • Page 4 Connecting and Disconnecting USB connection Driver setup File download/upload USB disconnection Managing Charging Firmware upgrade Trouble Shooting Specification Limited warranty INDEX...

  • Page 5: Safety Precautions

    Pay attention to the direction when you connect USB cable to a PC and tools, >> It can cause the damage to a PC and tools, Beware of sitting down with the unit in your pocket. i.Beat 300 / Safety Precautions...
  • Page 6 Safety Precautions 2. Copyright All rights reserved. Distributing music files without permission of the author against the copyright. TrekStor GmbH & Co. KG does not have responsibilities for this act. 3. Earphones/Headphones Do not use earphones with loud sound Do not use earphones when you are driving vehicles or for a long time.

  • Page 7: Features

    9 kinds of various sound effect including Normal, Rock, Jazz, Classical, Pop, User EQ (5 bands), SRS, TruBASS, WOW 8. Navigator It manages file folders like window exploring for example Pop-music, Documents, Images, etc. 9. Image Viewer It shows image files such as JPEG format. i.Beat 300 / Features...

  • Page 8: Firmware Upgrades

    - 8 line, 65,000 colored LCD. From now on, watch with the colorful LCD. 15. Multi-language support - For using easily anywhere in the world, it supports multi-language. 16. Firmware upgrades - Elevation of efficiency with easy upgrades 17. Play list (coming soon) 18. Lyrics scrolling during playback(coming soon) i.Beat 300 Features /...

  • Page 9: Beginning

    Beginning ��� Package Contents Name of Parts LCD Display...
  • Page 10 Package Contents It changes options at will for product feature improvement. It can be different with the actual object. i.Beat 300 User Manual USB extension cable Earphones Line-in cable Mini B Driver CD Hand strap Carrying case i.Beat 300 Package Contents/...
  • Page 11 Name of Parts / 각 부의 명칭 i.Beat 300 / Name of Parts...
  • Page 12 Earphone Jack FF (>>) Button LCD Display Play/Pause Button Volume (+) Button USB Connector Volume (-) Button Reset Button 2. Left side 3. Right side Microphone MENU Button REC Button A-B Button HOLD Button MODE Button i.Beat 300 Name of Parts/...
  • Page 13 Play/Pause icon Hold icon Volume Mark of playing back Bitrate/Sample rate selected segment Played time Repeat icon Current Track number Battery icon Total number of tracks File name and ID3 Tag information File format Visualization i.Beat 300 / LCD Display...
  • Page 14 LCD Display 2. FM Radio mode FM Radio mode display Mute icon Stereo/Mono icon Frequency Manual/Preset mode icon Preset channel i.Beat 300 LCD Display/...
  • Page 15 LCD Display 3. Recording mode Line in recording Voice recording FM recording Recording mode display Possible time to record Recording File name Recording bitrate/Sample rate Recording time i.Beat 300 / LCD Display...

  • Page 16: Using I.beat 300

    Using i.Beat 300 ��� Basic Function To change mode Player mode FM Radio mode Record mode Navigator mode IMAGE viewer TEXT viewer Games...
  • Page 17 When you press the button briefly, volume changes step by step. If you press the button continuously, volume changes sequentially. Volume level: 00(min) ~ 40(max) 3. Hold If you slide up Hold button on , all buttons will be locked. icon appears at LCD. HOLD i.Beat 300 / Basic Function...
  • Page 18 There are 7 modes (Player, FM Radio, Record, Navigator, Image viewer, Text viewer, Game). 1) Press the MODE button long enough to go other mode. 2) Select the mode by using button and press button. MODE i.Beat 300 To change mode /...
  • Page 19 Auto preset Press A-B button long enough, the player finds frequencies able to receive and saves each frequency to 10 preset channels automatically. If you press button, it stops the Auto preset function. i.Beat 300 / FM Radio mode...
  • Page 20 2 seconds for recording FM Radio at the FM Radio mode. If you press REC button for a long time when you stand by on the stop position, sound recording starts. Press the REC button long enough to stop recording. i.Beat 300 FM Radio mode /...
  • Page 21 Voice recording mode. You can setup the bit rate depending on the device of recording. (For more details about EQ setup, refer to the Record Quality setup Menu details p.31) i.Beat 300 / Record mode...
  • Page 22 Cursor moves up Cursor moves down Move up level folder or Return to the player mode in Root folder Open folder or play a specific file Open folder or play a specific file File delete MENU MODE i.Beat 300 Navigator mode /...
  • Page 23 Select the IMAGE viewer mode by using button and press button MODE -Cursor moves up -Cursor moves down -Full size image or return to the image list -Open backward or forward image directly i.Beat 300 / IMAGE viewer...

  • Page 24: Text Viewer

    Select the TEXT viewer mode by using button and press button MODE -Cursor moves up, text page up -Cursor moves down, text page down -Full size image or return to the text file list -Open backward or forward text file i.Beat 300 TEXT viewer /...
  • Page 25 Games Bejeweled Building over three blocks in a row with exchanging neighboring blocks and eliminating them. << move left select the block >> move right hint move up menu board MENU move down i.Beat 300 / Games...

  • Page 26: Menu

    MENU ���...

  • Page 27: Menu List

    Scroll Speed Repeat folder LCD Pwr mode Shuffle folder Effect set Preset set Record Quality Microphone SRS set Record FM USER EQ set Line in Effect set Record Quality Shutdown set Sleep timer Auto shutdown Shutdown set i.Beat 300 / MENU...

  • Page 28: Menu Details

    Select Menu By pressing the button, select a menu. And press button. Basic set Language Setup the language display. (English, Korean, Japanese, French, German) Initialize Initialize all menu details Information Display firmware version and system information. i.Beat 300 MENU /...
  • Page 29 You can control Text Scroll speed within the level between 00~08. LCD Power mode After backlight setup time goes by, LCD is definitely out. Therefore, power saving mode spares the consumption of battery. In case of key input during LCD is off, LCD screen appears. i.Beat 300 / MENU...
  • Page 30 Normal folder : Play all tracks in a specific folder once in order. Repeat folder : Play all tracks in a specific folder repeatedly in order. Shuffle folder : Play all tracks in a specific folder without the order. i.Beat 300 MENU /...
  • Page 31 Sleep Timer has 6 modes, 15, 30, 45, 90, 120, disable. After being chosen time, power the unit off even if you listen music or radio. Auto shutdown When music is paused or stopped, System turns off power after 1, 2, 5, 10min automatically. Disable mode does not apply to Auto Power saving. i.Beat 300 / MENU...
  • Page 32 Connecting and Disconnecting ��� USB connection Driver setup File download/upload USB disconnection...

  • Page 33: Usb Connection

    When you connect this player into PC, you have to use the USB extension cable or Mini B included in package contents. Foreign USB extension or Mini B may cause a wrong operation and a shock may lead to a defect. i.Beat 300 / USB Connection...
  • Page 34 PC recognizes as a "Local disk" directly. 2. Driver setup guide 1. Insert the 'Driver installation CD' in the CD-Rom of your PC. 2. When you connect your player to your Click! 3. You can see 'New Hardware Found' message. i.Beat 300 Driver setup /...
  • Page 35 2. Driver setup guide 4. Check the menu 'Search for the best driver for your device. (Recommended)' and then click Next. Click! 5. Check the menu 'Specify a location' and then click the button [Browse]. Click! i.Beat 300 / Driver setup...
  • Page 36 6. At the window of 'Browse for Folder', choose the [MS_mass_storage_601] in the drive which has CD driver. Click! 7. At the window of 'Add New Hardware Wizard', 'USB Storage Adapter AT2(CY)' appears then click Next. Click! i.Beat 300 Driver setup /...
  • Page 37 Device Manager. And separate the unit from the computer and reconnect the unit again. If the message 'New Hardware Found' shows up, start from 4. 'driver setup' which you can see above and set up completely. i.Beat 300 / Driver setup...
  • Page 38 You do the previous process in reverse when you want to upload files from the unit to PC PC recognizes as a "Local disk" which is a subordinate of "My computer" when the unit is connected to PC. i.Beat 300 File download/upload /...
  • Page 39 You can't remove the local disk device when the local disk window opened. 1) Click "Stop USB Mass Storage Device-Driver", where your PC screen's bottom taskbar. 2) Click OK as shown below then disconnect the player from your PC. i.Beat 300 / USB Disconnection...
  • Page 40 Managing ��� Charging Firmware upgrade Trouble Shooting Specification Limited warranty...
  • Page 41 2. Button up the left side of direction. 3. Start charging through the connection to an adaptor. However, playback is available during charging with an adaptor. HOLD i.Beat 300 / Charging...

  • Page 42: Firmware Upgrade

    You can improve the function of the unit and correct bugs by firmware upgrade. 2. Firmware download and upgrade guide www.trekstor.de Go to TrekStor website and download latest F/W version. 1) Connect the player into the USB port. 2) Copy and paste the Firmware file (filename.rom) as Root folder in local disk.

  • Page 43: Trouble Shooting

    This unit shares hard drive about 150MB for the System territory. Therefore excluding the essential system Even it is empty, the full territory, the full using capacity is smaller than the actual capacity. capacity is not 1.5GB. i.Beat 300 / Trouble Shooting...
  • Page 44 Over 200 Hours (MP3, 16Kbps, 1.5GB) Battery Rechargeable Li-Polymer Battery built-in Power Playtime 10 hours (Continuous) Recharging time 3~5 hours Windows 98 SE/Me/2000/XP Computer Interface Mac OS X Mac OS 9.x Linux USB Version 2.0 Transmission speed 28Mbps (Download)/37Mbps (Upload) i.Beat 300 Specification /...

  • Page 45: Limited Warranty

    One (1) year. Contents of Product Guarantee If the product should fail during normal operation within the guarantee term, TrekStor GmbH & Co. KG will repair the product free of charge or provide compensations in accordance with the compensation rule for consumer damages.
  • Page 46 MEMO...
  • Page 47 ��������������� TrekStor GmbH & Co. KG Kastanienallee 8-10 64653 Lorsch www.trekstor.de...
