Lindy 51541 User Manual

Smart Card Reader

www.lindy.com
Tested to Comply with FCC Standards
For Home and Office Use!
© LINDY ELECTRONIC S LIMITED & LINDY-ELEKTRONIK GMBH - FIRST EDITION (JUNE 2011)
User Manual

Installation

1. Turn on the computer.
2. Insert the ExpressCard in to an available slot in your PC, when the
hardware is fully inserted, the system will automatically detect the
new hardware. Please click Cancel.
3. Double click setup.exe file on the supplied CD-ROM.
4. Once the setup file has run the driver is installed, click Finish and
restart the computer.
Express Card
No.51541
User Manual

Introduction

Thank you for purchasing the LINDY ExpressCard Smart Card Reader
which reads and edits the data from your smart cards. It provides smart
card security for all types of ISO7816 compatible cards, e.g. home
banking, network security, secure logon, email encryption, online
gaming etc.

Features

•
Suitable for an Express Card 34 slot, or using the supplied adapter,
for an ExpressCard 54 Slot
•
Compliant with EMV specification
•
Universal Serial Bus Specification, version 1.1 / 2.0.
•
PC Smart Card industry standard – PC / SC 1.0
• Supports CT-API
•
US Federal Information Processing Standards (FIPS) Publ. 201
requirements on smart card reader interoperability, Includes WDM
driver to work on Windows 98 and Windows 2000
•
Support T0, T1 protocol, I2C memory card, SLE4418, SLE4428,
SLE4432,SLE4442, AT88SC1608 and AT45D041 card
•
Compatible with Microsoft USB-CCID driver
• Supports 3V / 5V cards
•
Compatible with Win 2000 / XP / Vista / 7, Mac OS 10.2.4 and
above
User Manual
For notebooks with ExpressCard/54 slot, please use the enclosed
adapter, which helps prevent the ExpressCard from moving around in the
slot.
