BEA WebLogic User Manual page 51

a. In the service explorer in the left pane, browse the application view folders and
b. Open the service adapter and select the desired service.
c. Select <new> from the Request Document Variable drop-down list.
Figure 3-19 Variable Properties Dialog Box
a. Enter a name for the new variable.
b. Select the variable type XML from the drop-down list.
c. Check the Input and Output options in the Parameter group.
d. Click OK.
You return to the Call Service dialog box.
a. Select Synchronous.
b. Select New from the Response Document Variable drop-down list.
c. Enter a name for the new variable.
d. Select the variable type XML from the drop-down list.
e. Click OK.
f. Click Set in the Call Service dialog box to set the request document.
BEA WebLogic Adapter for Manugistics User Guide
Testing Service Adapter Application Views Using WLI Studio
select the application view that corresponds to the service adapter.
The Variable Properties dialog box appears.
As this is only a partial workflow, the request document containing the
request must be set.
3-15
