- Page 1 MODELS H6082, H6083, H6086 INSTRUCTION MANUAL COPYRIGHT © MAY, 2004 BY GRIZZLY INDUSTRIAL, INC. REVISED JANUARY, 2007 (BL) WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
- Page 2 WARNING Some dust created by power sanding, sawing, grind- ing, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-based paints. •...
-
Page 3: Table Of Contents
Installing Bridge on Model H6082/83 ... 16 Installing Bridge on Model H6086 ... 17 Mounting Back Plates ... 18 Gluing the Nut on the Model H6082 and H6083 ... 18 Attaching the Nut on the Model H6086 ... 19 Truss Rod Cover ... 19 Winding Strings on Model H6082/83 ... -
Page 4: Section 1: Safety
Do not underestimate the ability of these tools and machin- ery to cause injury. Never operate any tool without all guards in place and always wear approved safety glasses. For your own safety, please heed this warning. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits... -
Page 5: Section 2: Introduction
It represents our effort to produce the best documentation pos- sible. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits Contact Info If you have any comments regarding this manual, please write to us at the address below: Grizzly Industrial, Inc. -
Page 6: Section 3: Parts Inventory
Hex Wrench 4mm 23 PH6082023 Nut 24 PH6082024 Audio Jack Plate Figure 1. H6082/3 boxed components. Figure 2. H6082/3 peghead components. Figure 3. H6082/3 guitar parts. Figure 4. H6082/3 more guitar parts. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits... -
Page 7: Model H6086 Parts
22 PH6086022 Tap Screws M2.6 X 16 23 PH6086023 Audio Jack Plate Figure 5. H6086 boxed components. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits Figure 6. H6086 peghead components. Figure 7. H6086 bridge parts. Figure 8. H6086 guitar parts. -
Page 8: Supplies/Tools
Switch ⁄ " Blade Tailstop Tone Controls 3-Way Switch Figure 10. Model H6082/3 identification. Fretboard Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits Identification Bridge Pickups Volume Controls Tremolo Bar Figure 9. Model H6086 identification. Strap Bridge Button Pickups... -
Page 9: Section 4: Assembly
It also increases the likelihood of the strings pulling out of the nut slots. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits Layout the tuners on the test piece to ensure you have enough room between the tuners and for the tuner buttons to turn. -
Page 10: Sanding The Body
The fretboard requires no sanding. Sanding the fretboard will affect the playability of the guitar and could lead to unrepairable damage. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits... -
Page 11: Finishing The Neck
Thread the hook through the upper peghole and hang the neck in the finish room. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits Apply the finish according to "Finishing the Body"; steps 5–11 on page 10. -
Page 12: Finishing The Body
• Apply the finish to the desired guitar parts and immediately leave the finish room. • DO NOT return to the room until the specified drying time has elapsed. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits... -
Page 13: Installing The Tuners
Slide a washer over the tuner shaft and screw the barrel nut onto the tuner. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits Align the tuners perpendicular to the edge of the headstock and parallel to each other. -
Page 14: Installing The Neck
Clamp the neck to the body as shown in Figure 16. Note—To protect the neck and body, place wood blocks and pads between the clamp and the guitar. Figure 16. Clamping the neck to the body. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits... -
Page 15: Installing The Pickups
Figure 17, and place the pickup in the cavity with the thin edge towards the neck. Figure 17. Neck pickup wire. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits Push the gray wire on the bridge pickup (the thicker pickup) through the hole shown in Figure 18 and place the pickup in the cavity with the thin edge towards the neck. -
Page 16: Wiring The Pickups
H6086, or to the bridge insert hole for the Model H6082 and H6083. Install the back cover plate over the electron- ics cavity. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits To Neck Pickup White... -
Page 17: Audio Jack
Secure the jack plate to the guitar body with four tap screws. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits Strap Buttons The strap buttons are positioned on the guitar as shown in Figure 22. -
Page 18: Installing Bridge On Model H6082/83
Repeat for the other insert. Thread the bridge adjustment screws into the inserts as shown in Figure 25. Figure 25. Tailpiece adjustment screw. Slide the tailpiece onto the adjustment screws. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits... -
Page 19: Installing Bridge On Model H6086
Figure 26 with the notches against the adjustable inserts. Figure 26. Tremolo bridge placement. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits Flip the guitar body over and place the spring claw in the cavity as shown in Figure 27. -
Page 20: Mounting Back Plates
The strings will hold the nut in place until the glue dries. Wipe away the excess glue before it sets up, then allow the glue to dry for 24 hours. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits and H6083... -
Page 21: Attaching The Nut On The Model H6086
Thread two screws through the locking nut and into the neck. Note—The remaining lock blocks and cap screws will be installed after the guitar is tuned. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits Truss Rod Cover Components Needed Guitar ... 1 Truss Rod Cover ... -
Page 22: Winding Strings On Model H6082/83
Final tensioning should be completed during the string tuning process. Figure 33. String wrapped around tuner. Use wire cutters to cut off the excess string. Repeat the above process for the remaining strings. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits... -
Page 23: Winding Strings On The Model H6086
Hex Wrench 3MM ...1 Saddle Lock Screw Lock Block Figure 34. Bridge components. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits To install the guitar strings: Cut the ball ends and wraps off of the guitar strings. Insert the strings between the lock block and the front edge of the lock box as shown in Figure 35. -
Page 24: Section 5: Set Up
Restring the guitar and recheck the neck with the straightedge. —If the neck is correctly adjusted, go to the next section. —If the neck is still out of adjustment return to step 3. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits... -
Page 25: String Height Adjustment For Model H6082/83
⁄ " the 6th string mea- surement should be ⁄ ". Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits De-tension the strings and adjust the bridge height as shown in Figure 38. String Figure 38. Adjusting the bridge height. -
Page 26: String Height Adjustment For The Model H6086
Re-tune the guitar and check the string height. —If the strings are at the correct height, go to the next section. —If the strings are at the wrong height return to step 2. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits... -
Page 27: Pickup Adjustments
Fasten the pickups to the body with the M3 X 12 tap screws. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits Measure the distance from the top of the outside screw heads on the neck pickup to... -
Page 28: Spring Adjustment On The Model H6086
6th, 5th, 4th, and 3rd strings. On the Model H6086, when the guitar is in tune, tighten the lock blocks on the locking nut to prevent the strings from going out of tune. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits ���� � �... -
Page 29: Setting Intonation
2 is also in tune. Model H6082, H6083, and H6086 Heirloom Electric Guitar Kits Figure 46. H6082 and H6083 saddle adjust- Figure 47. H6086 saddle adjustments screws. -
