Oricom CID99 User Manual

Caller Back from Caller ID Memory

1. With the handset for the phone connected to the Caller
ID unit on the base, repeatedly press or to find the
desired number.
2. Press CALL BACK once. The Caller ID unit automatically
PICK UP CALL PICK UP CALL
redials the number and PICK UP CALL PICK UP CALL PICK UP CALL appears.
Note: If you pick up the handset before pressing CALL
REPLACE HANDSET REPLACE HANDSET REPLACE HANDSET REPLACE HANDSET REPLACE HANDSET
BACK, will appear. Replace the
handset than the number will be redialed and PICK UP PICK UP PICK UP PICK UP PICK UP
CALL CALL CALL CALL CALL will appear.

Notes for operation in New Zealand

The grant of a Telepermit for any item of terminal equipment indicates
only that Telecom has accepted that the item complies with the
minimum conditions for connection to its network. It indicates no
endorsement of the product by Telecom, nor does it provide any sort
of warranty. Above all, it provides no assurance that any item will
work correctly in all respects with another item of Telepermitted
equipment of a different make or model, nor does it imply that any
product is compatible with all of Telecom's network services.
Telepermitted equipment only may be connected to the Phone Jack.
The Phone Jack is not specifically designed for 3-wire-connected
equipment. 3-wire-connected equipment might not respond to
incoming ringing when attached to this socket.

REN (RN for New Zealand)

The REN (Ringer Equivalence Number) or (RN) is of significance only
if you wish to connect more than 1 telephone to your telephone line. A
standard telephone line has a maximum REN capacity of 3 (RN of 5).
6
It is possible to connect 3(5) devices with a REN of 1 (RN of 1) with no
degradation to the product's performance. Exceeding this limit may
cause the volume of the ringer in any phone to decrease or not ring at
all
Caller Display - Customers Using Another
Company's Toll Services
Some customers use another company's toll services and have their
line set up so that their chosen carrier's access code is automatically
inserted by the Telecom exchange. If you use such a service, and
you dial automatically from this device, your local calls will also be
passed to the other carrier because the telephone automatically inserts
a "0" and the local area code. A toll charge may be incurred. Check
with the carrier concerned. If you recognise the telephone number
that appears on the display as definitely being a local, non-cellular
number then you should ignore the "0" prefix and the local area code
digit and simply dial the caller's 7-digit number. This will avoid the
possibility of incurring a toll charge for a local call.
Manual insertion of dialling prefixes (eg 0197)
This unit will only work in conjunction with a tone signalling (DTMF)
telephone, but some telephones may not be compatible. Since noise
or speech from the telephone can upset dialling from this unit, errors
may result if the devices are used together in other than quiet conditions
Where it is necessary to dial prefix digits, such as a Caller Display
override code ("0196" or "0197"), this unit will have to be used in
conjunction with an associated tone signalling (DTMF) telephone.
7
Note that some telephones are NOT compatible with this unit and
dialling errors may result if the two devices are used together in other
than quiet conditions. The Telecom Faults Service is NOT to be called
should such problems arise. In such cases, it is recommended that
the prefix and wanted number are dialled manually.

Troubleshooting

If you feel this product is not working correctly please consult the user
guide and ensure that you are using the product in accordance with
the instructions.
Remove all extra telephone equipment and connect only this telephone
directly to the telephone socket.
If the fault is still present, connect another telephone (if available) to
the telephone socket. The results will show you whether the fault lies
with this product or with the telephone line. If this product is working
correctly the fault is on the telephone line. Please contact your network
operator for assistance
In the case of technical problems with this product please consult our
website for further information or send us an email for a prompt
response to your enquiry.

Cleaning and care

The surface of the case can be cleaned with a dry, soft, lint-free cloth.
Never use cleaning agents, particularly aggressive solvents.
8

Warranty Information

This product is covered by a 12 month warranty against defective
workmanship or parts, effective from the date of purchase.
The warranty does not extend to damage caused by misuse,
negligence, excessive voltage, faults on the telephone line or lightning.
This warranty in no way affects your statutory rights. Full details of the
warranty are contained in the enclosed warranty card.

Technical support

In the unlikely event of a fault during this period, please consult our
website for assistance or send us an email for a prompt response to
your enquiry. If the product is then found to be faulty you will be asked
to return it directly to us with a copy of the purchase receipt.
For further information about the Oricom range of products please
visit our website.
Australia New Zealand
Oricom International Pty Ltd Atlas Gentech (NZ) Ltd,
ABN 46 086 116 369 Private Bag 14927,
PO Unit 5681 Panmure,
South Windsor, NSW 2756 Auckland
Customer support Customer support
Email: support@oricom.com.au Email: support@atlasgentech.co.nz
Web: www.oricom.com.au Web: www.atlasgentech.co.nz
Fax: (02) 4572 0939 Fax: (09) 574 2722
Ph: 1300 889 785 Ph: 0900 50 025 (Toll Call)
LIBA25Y1
9
Caller ID unit CID99
User Guide
