- Page 1 RB865io Terminal User Manual Date: 25 Jul 2013 Powered by Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. +48 (22) 751 76 80 05-092 Łomianki k/Warszawy www.teleorigin.com...
-
Page 2: Table Of Contents
No connection/communication with the modem ..............23 9.2. Receiving ERROR message ....................23 9.3. Receiving NO CARRIER message ..................24 Technical characteristics ....................25 Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. +48 (22) 751 76 80 05-092 Łomianki k/Warszawy... - Page 3 Responsibility........................ 35 Accessories ........................36 14.1. Accessories critical for using modem................36 14.2. Additional accessories ....................37 On-line support ......................... 38 Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. +48 (22) 751 76 80 05-092 Łomianki k/Warszawy www.teleorigin.com...
-
Page 4: Overview
1. Overview The RB865io terminal is the complete modem solution for wireless m2m applications. Based on the Telit GL865 or G30 module offers high level GSM/GPRS features in compact aluminium housing with all the standardized interfaces and configurable I/O. Together with its small size and wide supply voltage range, makes it easy to integrate into all kinds of machines. -
Page 5: Trademarks
TELIT and the Stylized T Logo are registered in Trademark Office. All other product or service names are the property of their respective owners. Copyright © Telit Communications S.p.A. 2011. Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. -
Page 6: Package
We can find product sticker on the box. It matches modems sticker that is placed on the device. This proves that your modem is original product. More information about stickers in chapter 6.3 Product sticker Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. -
Page 7: Complete Package Contents
(items C) antenna GSM (via SMA) (item D) CD with software (item E) RS232 cable (item F) Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. +48 (22) 751 76 80 05-092 Łomianki k/Warszawy www.teleorigin.com... -
Page 8: General Presentation
6. General presentation 6.1. Description connector LEDs Power supply DATA SIM card Extractable holder ejector SIM card holder 15-pin connector Audio Input/Output Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. +48 (22) 751 76 80 05-092 Łomianki k/Warszawy www.teleorigin.com... -
Page 9: External Connections
If range of GSM is low or none, an outdoor or indoor (for instance in place where GSM range is sufficient) antenna should be used. Note: If there is no antenna connected to SMA connector, the connection with GSM network is impossible. Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. -
Page 10: 15-Pin Connector (Rs232)
6.2.2. 15-pin connector (RS232) RB865io terminal is equipped with 15-pin connector (as shown below). 15-pin connector Table of DB15 pins: Pin No. Name Description Ground GPIO (ADC) IN/OUT General purpose input / output. ADC range 0..3V, 10 bit resolution. Data Terminal Ready. Raised by DTE when powered on. In auto- answer mode raised only when RI arrives from DCE. -
Page 11: Power Supply Connector
V+BATTERY Ground Attention! An attempt to power terminal from DC source outside of 5..30 V range may result in physical destruction of the device. Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. +48 (22) 751 76 80 05-092 Łomianki k/Warszawy... -
Page 12: Audio Input/Output
6.2.5. SIM card holder SIM card holder is placed in front of RB865io terminal (as shown below) and is accessible externally. To insert SIM card into the holder press the yellow button, eject the little drawer, place there Your SIM card and insert drawer into the modem (You will hear click). -
Page 13: Product Sticker
Product stickers are on the modem and on the box of the product. A production sticker includes the following information: Product serial number (IMEI) the CE marking the 15-digit bar code the model signature (RB865io) Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. -
Page 14: Basic Features And Services
7. Basic features and services Basic features and available services for RB865io are contained in table below. Feature/service Description Standard Supported Bands: GSM Quad-band 850/900/1800/1900MHz Physical: 83 x 72 x 25 mm Weight 151g GPRS Multi-slot class 10 (4 Down;... -
Page 15: Using The Modem
Verify if SIM card fits in the drawer properly (as shown). Insert the drawer into the modem. Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. +48 (22) 751 76 80 05-092 Łomianki k/Warszawy... -
Page 16: Mounting The Modem
To mount modem on DIN bus install DIN handle as shown below 8.2.2. On the wall To mount modem on the wall install wall handles as shown below. Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. +48 (22) 751 76 80 05-092 Łomianki k/Warszawy... -
Page 17: Checking The Communication With The Modem
8.3. Checking the communication with the modem Once the modem is connected you can check communication between RB865io terminal and the PC using Telit AT Controller available here: http://teleorigin.com/download/Tools/Common/Telit_AT_Controller_r2_2_1.zip Configuration of the DTE (port COM) should be as follows: ... -
Page 18: Status Of The Modem (Leds)
8.4. Status of the modem (LEDs) The operational status of the RB865io Terminal is signalized by external LEDs placed on the front panel of the modem. The table below shows what is the meaning of LEDs. LED colour Status description... -
Page 19: Verifying The Strength Of Received Signal
8.6. Verifying the strength of received signal RB865io Terminal can establish connection with network if the received signal strength is sufficiently strong. To verify the signal strength and bit error rate, do the following: Using software such as Hyperterminal enter AT+CSQ. This command displays the received signal strength indication <rssi>... -
Page 20: Network Registration
Two-byte cell ID in hexadecimal format. <ci> *To manage connecting to network SIM card inserted into the modem must be valid. For further information about AT commands and their usage, refer to [1] / [2]. Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. -
Page 21: Gprs Network Registration
Two-byte cell ID in hexadecimal format. <ci> *To manage connecting to network SIM card inserted into the modem must be valid. For further information about AT commands and their usage, refer to [1] / [2]. Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. -
Page 22: At Commands Summary
Returns status of PIN. Check PIN code e.g. READY or SIM PIN status +CME ERROR: <err> General error* Refer to [1] / [2]. Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. +48 (22) 751 76 80 05-092 Łomianki k/Warszawy www.teleorigin.com... -
Page 23: Troubleshooting
ERROR +CME ERROR: <err> where <err> is a description of error which has occurred Refer to [1] or [2] for further details about occurred error Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. +48 (22) 751 76 80 05-092 Łomianki k/Warszawy... -
Page 24: Receiving No Carrier Message
Invalid number format (incomplete number) No circuit/channel available Network out of order Temporary failure For further information about AT commands and their usage, refer to [1] or [2]. Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. +48 (22) 751 76 80 05-092 Łomianki k/Warszawy... -
Page 25: Technical Characteristics
83 x 53.5 x 26 mm (w/ connectors) ≈ 89 g Weight Volume 100 cm (w/o connectors) 10.2. Housing description (dimensioning diagram) Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. +48 (22) 751 76 80 05-092 Łomianki k/Warszawy www.teleorigin.com... -
Page 26: Electrical Characteristic
Minimum radiated RF performance is shown in the table below: Band 850/900 1800/1900 GSM/GPRS TRP [dBm] 24,5 TIS [dBm] -101,5 EGPRS TRP [dBm] 20,5 19,5 TIS [dBm] -92,5 -93,5 Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. +48 (22) 751 76 80 05-092 Łomianki k/Warszawy www.teleorigin.com... -
Page 27: External Antenna
11.4. Environmental characteristic Table below gives the environmental operating conditions of RB865io terminal. Attention! Exceeding the values may result in permanent damage to the module. Parameter... -
Page 28: Python Script Interpreter
Python scripts are text files stored in Telit module NVM (Non Volatile Memory). There is a file system inside the module that allows to write and read files with different names on one single level (no subdirectories are supported) Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. - Page 29 GPS controller. Its purpose is to handle the GPS controller without the use of dedicated AT commands through the MDM built-in module. Visit Python official web site for more information http://www.python.org/. More information can be found also in Telit_Easy_Script_Python.pdf [6] Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel.
-
Page 30: Executing Scripts
Python script. This option compiles the file and saves it on the same directory with a *.pyo extension. Compilation results and further errors will appear in the active window. Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. -
Page 31: Write Python Script
#RSCRIPT command does not return the text of the script and keeps it “confidential”, you can see the name of the script only using the #LSCRIPT command. Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. - Page 32 Another way to download using HyperTerminal and when PythonWin is installed, is to disconnect and, when the prompt appears, to right click on the file and select “download”. Reconnect after the download completes. Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul.
-
Page 33: Enable Python Script
NVM. See AT#STARTMODESCR and AT#EXECSCR commands for further Python script execution modes. For further information please refer to [6] Telit_Easy_Script_Python.pdf Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. +48 (22) 751 76 80 05-092 Łomianki k/Warszawy... -
Page 34: Safety Recommendations
Using GSM modem close to other electronic equipment may also cause interference if the equipment is inadequately protected. It may lead to damage or failure of GSM modem or the other equipment. Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. -
Page 35: Care And Maintenance
13.2. Care and Maintenance The RB865io terminal is a electronic product that should be treated with care. Please follow suggestions shown below due to using modem for many years. Do not expose RB865io to any extreme circumstances like high temperature or high humidity ... -
Page 36: Accessories
14. Accessories The tables below shows recommended accessories for RB865io terminal. 14.1. Accessories critical for using modem Table below shows accessories critical for using modem. Without them usage of modem is impossible. Accessory Description Part no. Power adaptor Example of power adaptor is shown in the picture below Power adaptor 5 V Elproma Elektronika Sp. -
Page 37: Additional Accessories
Magnetic antenna 2dBi Antenna with extra gain ANT-DBMAG HandsFree headphones Headphones and microphone HF24 Magnetic antenna 2dBi ANT-DBMAG HandFree headphones HF24 Elproma Elektronika Sp. z o.o. E-mail: office@elproma.com.pl ul. Szymanowskiego 13 Tel. +48 (22) 751 76 80 05-092 Łomianki k/Warszawy www.teleorigin.com... -
Page 38: On-Line Support
15. On-line support Elproma provides a range on on-line support which includes: the latest version of this document the latest drivers for RB865io technical support www.teleorigin.com This information can be found on our web sites at For further information or product support please contact us using the details below: E-mail: info@elproma.com.pl...
