Installation and Operation Data
Installation and
Op er a tion Man u al
JandyColors
Digital Color Blending,
Underwater Pool and Spa Lights
FOR YOUR SAFETY - This product must be installed and serviced by a pro fes sion al pool/
spa service technician. The procedures in this manual must be followed ex act ly. Failure to
follow warning notices and instructions may result in property damage, serious injury, or
death.
TM
WARNING
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Jandy JandyColors JPL1230
- Page 1 Installation and Operation Data Installation and Op er a tion Man u al JandyColors Digital Color Blending, Underwater Pool and Spa Lights WARNING FOR YOUR SAFETY - This product must be installed and serviced by a pro fes sion al pool/ spa service technician.
-
Page 3: Table Of Contents
Preparing the Light Fixture for Installation ............... 6 Installing the Light Fixture ....................7 Section 4. Replacing Jandy Light Fixture in an Existing Pool or Spa ............. 9 Preparing the Light Fixture for Replacement ..............9 Replacing the Light Fixture ....................9 Section 5. -
Page 4: Section 1. Safety Information
Page 4 Section 1. Safety Information IMPORTANT SAFETY INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS READ AND FOLLOW ALL INSTRUCTIONS When installing and using this electrical equipment, basic safety precautions should always be followed, including the following: WARNING RISK OF ELECTRICAL SHOCK OR ELECTROCUTION. -
Page 5: Section 2. Product Description And Model Numbers
Page 5 Section 2. Product Description and Model Numbers Product Voltage Cord Length Model # Jandy Pool Light 12 Volt AC 30 feet JPL1230 Jandy Pool Light 12 Volt AC 50 feet JPL1250 Jandy Pool Light 12 Volt AC 12 Volt AC... -
Page 6: Section 3. Installing Jandy Light Fixture During New Construction
Page 6 Section 3. Installing Jandy Light Fixture during New Construction Preparing the Light Fixture for Installation NOTE The electrician must complete preparatory steps before light fixture is installed; see Figure 1 (or Figure 2, for spa). Ensure that the pool or spa meets the requirements of the current National Electrical Code and all local codes and ordinances. -
Page 7: Installing The Light Fixture
Use only approved wet niches (see following note) to ensure a safe and proper installation. NOTE Jandy Pool and Spa Lights are ETL listed (ETL for installation with only the following report/file 3033587.001) manufacturer’s wet niche fixtures:... - Page 8 Page 8 Coil the 4-foot length of cord around the fi xture and place the light assembly into the niche. Engage the retainer tab on the bottom of the face ring, then pivot the top of the fi xture inward and tighten the special pilot screw.
-
Page 9: Section 4. Replacing Jandy Light Fixture In An Existing Pool Or Spa
Page 9 Section 4. Replacing Jandy Light Fixture in an Existing Pool or Spa WARNING Risk of Electrical Shock or Electrocution. This underwater light must be installed by a licensed or certified electrician or a qualified pool or spa serviceman in accordance with the National Electrical Code and all applicable local codes and ordinances. - Page 10 Page 10 NOTE The light fixture may be replaced without removing water from the pool or spa. Turn off the main electrical switch or circuit breaker, as well as the switch, which operates the underwater light. To remove the light assembly, remove the special pilot screw at top of the face ring, remove the light assembly from the niche, and place the assembly on the deck.
-
Page 11: Section 5. Wiring Options For Controlling Jandy Pool Lights Or Jandy Spa Lights
Section 5. Wiring Options for Controlling Jandy Pool Lights or Jandy Spa Lights NOTE The Jandy Pool and Spa Lights will not operate properly with light dimmers. Do not wire the Jandy Lights to any dimming circuitry. To the extent allowed by code and capacity of the electrical equipment, multiple... -
Page 12: Wiring To A Time Clock
Wiring to a Time Clock The Jandy Pool and Spa Lights can be wired into a basic time clock to automatically turn on the lights at a predesignated time. Refer to Figure 5 to connect the lights into the clock. -
Page 13: Section 6. Jandy Pool Light And Jandy Spa Light Operating Instructions
(see Table 1 in Section 6.1). NOTE To synchronize colors on multiple Jandy Pool and Spa Light systems wired to separate switches, perform the above actions on all of their switches simultaneously. All Jandy Digital Pool and Spa Lights will... -
Page 14: Section 7. Replacing Bulbs
Turn off the main electrical switch or circuit breaker, as well as the switch, which operates the underwater light. Be sure to have the following items: • A new lens gasket (P/N R0399800 for Jandy Pool Light and P/N R0400500 for Jandy Spa Light). • Eight (8) new bulbs. See Table 2 for bulb specifi cation. - Page 15 Figure 6. Removing the Light Assembly for Bulb Replacement Disassemble the light fi xture and replace bulbs. Use the following bulb removal instructions for Jandy Pool and Spa Light: a. Loosen the Phillips head screw on the band clamp to allow the clamp to be removed. Screw should Loosen the Phillips head screw on the band clamp to allow the clamp to be removed.
- Page 16 Reassemble the fi xture (applies to both Jandy Pool Light and Jandy Spa Light). a. If not already done, remove the gasket from the glass lens and install a new gasket, If not already done, remove the gasket from the glass lens and install a new gasket, Jandy Pool Jandy Pool...
-
Page 17: Section 8. Twelve (12) Volt Installation
A separate 12-Volt AC Transformer is required on all 12-Volt Models--For Jandy Pool Light use a 300-watt multi tap 12-volt system. For the Jandy Spa Light, a 100 watt 12-volt system is acceptable. To ensure maximum safety, it is strongly recommended that a transformer that has been listed or recognized by a Nationally Recognized Testing Laboratory (NRTL) for the application be used. -
Page 18: Section 9. Exploded View And Replacement Parts
Page 18 Section 9. Exploded View and Replacement Parts Jandy Digital Pool Light Figure 7. Jandy Digital Pool Light Exploded View DWG# Part# Description Field Replaceable Pool Light Housing NO - Purchase New Light Transformer (120 Volt lights only)-Pool NO - Purchase New Light... -
Page 19: Jandy Digital Spa Light
Page 19 Jandy Digital Spa Light Figure 10. Jandy Digital Spa Light Exploded View DWG# Part# Description Field Replaceable Spa Light Housing NO - Purchase New Light Transformer (120 Volt lights only)-Spa NO - Purchase New Light Bulb Holder and Electronics Assembly-Spa... - Page 20 If the dealer is not available, you can locate a service center in your area by visiting www.jandy.com or by calling our technical support department at (707) 776-8200 extension 260. All returned parts must have a Returned Material Authorization number to be evaluated under the terms of this warranty.
