Summary of Contents for PCTestPro KD25
- Page 1 KD25/35 PRO Operation Manual...
-
Page 2: Table Of Contents
Contents 1. Overview................................3 1.1 Key Product Features ........................... 3 1.2 Precautions of Use ............................3 1.3 Before Use ..............................3 1.4 Specifications ..............................4 1.5 Package Contents ............................4 1.6 Hardware and Software Requirments ......................5 1.7 Before connecting your hard drive ....................... 6 2.Operation ................................ -
Page 3: Overview
To avoid malfunction, do not use the product near radios, TV sets, and audio devices. • The KD25 Main Unit only works for IDE 2.5” and 3.5” hard drives. It does not support operations of other devices including CD-ROM. 1.3 Before Use •... -
Page 4: Specifications
1.4 Specifications • Model Number: KD25/35PRO • Product Name: KD25/35PRO • Interface: USB Rev2.0 • PC Interface: USB (Type B)/eSATA • Weight: 360g • Dimensions: W146xD102xH25.4mm • Operation Temperature and Humidity: 5-35℃, 20-80% (no condensation and within the operating range of the connected PC) *HDD is not included with this product 1.5 Package Contents... -
Page 5: Hardware And Software Requirments
Supported HDD • 3.5” and 2.5” ATA/SATA HDD *Some Maxtor hard drives may not properly work with the product. Please see Page 16 for more information on connecting Maxtor hard drives (including Seagate hard drives manufactured by Maxtor). 1.6 Hardware and Software Requirments PC Interface: eSATA o PC/AT compatible device or Macintosh with eSATA I/F o Windows2000/WindowsXP/Windows Vista... -
Page 6: Before Connecting Your Hard Drive
PC Interface: USB Windows • PC/AT compatible device with USB2.0 Interface Port (for USB2.0 Mode) • PC/AT compatible device with USB1.1 Interface Port (for USB1.1 Mode) * Models with an Intel chip set recommended • Pentium300MHz/128MB RAM • Windows2000/WindowsXP/Windows Vista Macintosh •... -
Page 7: Operation
2.Operation 2.1 Standalone... - Page 8 *Press the [POWER/START] button to stop auto display change. While auto display change is stopped, [>] appears in the bottom left corner. You can turn the [Mode] dial and change status display. Press the [POWER/START] button again to enable auto display change. Step 7 Complete Copy Mode •...
-
Page 9: Pc Operation
2.2 PC Operation 2.2.1 Windows Usage 2.2.1.1 Install USB Driver 1. Start Windows 2. Power on the KD2535 3. Connect the KD2535 to the host PC via the provided USB cable 4. The PC will automatically install the standard Windows device driver 2.2.1.2 Install eSATA Driver 1. -
Page 10: Functions
3. Functions 3.1 Copy Modes Copy Type Description Disk Copy A sector-to-sector copy that will copy the entire Disk 1 onto Disk 2. • If Disk 2 is smaller than Disk 1, Disk 1 will be copied up to the capacity of Disk 2 •... -
Page 11: Erase Modes
3.4 Erase Modes Erase Type Description DATA ERASE 00x1 Writes 00h to all sectors of the attached drive(s) • This is a single-pass wipe DATA ERASE NSA Writes data to all sectors of attached drive(s) in accordance to the NSA wiping standard •... -
Page 12: Options
4. Options Start up the unit in the standalone mode, turn the [Mode] dial to select [OPTIONS], and press the [POWER/START] button. Option Settings can be accessed by turning the [Mode] dial. Press the [POWER/START] button to select. Option Description Values BUZZER Turns on/off the beeps for buttons and operations. - Page 13 CRC ERROR Automatically retries upon CRC errors. ON: enabled RETRY *When the setting is disabled, the KD25/35PRO (default) stops the operation upon CRC errors and waits for OFF: disabled input. AUTO SHUTDOWN Automatically shuts down the unit upon completion. ON: enabled...
-
Page 14: Lcd Display
5. LCD Display 5.1 Error During Initialization initializing… When errors occur during the initialization of a drive ( is displayed), the following messages are displayed: FIGURE Top: Scroll display for the error Bottom: Available operations for the error ERR: Disk1 not Connected. DISK1 is not connected. -
Page 15: Errors During Operation
5.2 Errors During Operation When errors occur during an operation in the Standalone mode, the following messages are displayed: FIGURE Top: Scroll display for the error Bottom: Available operations for the error ERR: Diskn Read Error (xxxx). Read Error on DISKn (1 or 2) ERR: Diskn Write Error (xxxx). -
Page 16: Troubleshooting
* *This problem is not limited to use with the KD25/35 PRO: it will when directly connecting to a computer motherboard as well. -
Page 17: Faq
Q: When the target drive is larger than the master, what happens to free space on the target drive after duplication? A: The KD25/35PRO copies partitions as well. If the master drive is 40GB and the target is 80GB, it copies 40GB of data, and the target drive will have 40 GB of free space remaining. - Page 18 Q: Can I use an internal hard drive for copy? A: You need to remove the drive from your PC first and then connect it directly to the KD25/35PRO in order to be able to copy it. Q: My source drive has very little used space. Can I copy it to a smaller target drive? A: Yes, but you may not be able to copy all the data, because the operation stops after reaching the capacity of the target drive.
