  • Page 1 ADC-8434-A Quad Analog Audio to AES Converter User Manual...
  • Page 2 The material in this manual is furnished for informational use only. It is subject to change without notice and should not be construed as commitment by Ross Video Limited. Ross Video Limited assumes no responsibility or liability for errors or inaccuracies that may appear in this manual.
  • Page 3: Important Safety Instructions

    Important Regulatory and Safety Notices to Service Personnel Before using this product and nay associated equipment, refer to the “Important Safety Instructions” listed below to avoid personnel injury and to prevent product damage. Product may require specific equipment, and/or installation procedures to be carried out to satisfy certain regulatory compliance requirements.
  • Page 4 Notice — Changes or modifications to this equipment not expressly approved by Ross Video Limited could void the user’s authority to operate this equipment. CANADA This Class “A”...
  • Page 5 The crossed out wheelie bin symbol invites you to use these systems. If you need more information on the collection, resuse, and recycling systems, please contact your local or regional waste administration. You can also contact Ross Video for more information on the environmental performance of our products.
  • Page 6 Company Address Ross Video Limited Ross Video Incorporated 8 John Street P.O. Box 880 Iroquois, Ontario, K0E 1K0 Ogdensburg, New York Canada USA 13669-0880 General Business Office: (+1) 613 • 652 • 4886 Fax: (+1) 613 • 652 • 4425 Technical Support: (+1) 613 •...
  • Page 7: Table Of Contents

    Before You Begin ........................ 2-2 Static Discharge..................... 2-2 Unpacking......................2-2 Installing the ADC-8434-A ....................2-3 Rear Modules for the ADC-8434-A ..............2-3 Installing a Rear Module ..................2-3 Installing the ADC-8434-A ................... 2-4 Cabling for the ADC-8434-A ....................2-5 DFR-8310 Series Frame Cabling Overview............2-5 DFR-8321 Series Frame Cabling Overview............
  • Page 8 • Contents ADC-8434-A User Manual (Iss. 01)
  • Page 9: Introduction

    Congratulations on choosing an openGear ADC-8434-A Quad Analog Audio to AES Converter. Your ADC-8434-A is part of a full line of Digital Products within the openGear Terminal Equipment family of products, backed by Ross Video's experience in engineering and design expertise since 1974.
  • Page 10: Overview

    The ADC-8434-A Quad Analog Audio to AES Converter is a broadcast quality, modular product used to convert four analog audio channels to two, 24-bit, unbalanced AES-3id signals. The ADC-8434-A accepts 4 analog audio signals (2 stereo pairs) and provides 2 copies of each of the 2 AES / EBU output signals.
  • Page 11: Functional Block Diagram

    Functional Block Diagram This section provides a functional block diagram that outlines the workflow of the ADC-8434-A. Figure 1.1 Simplified Block Diagram — 8310AR-036 and 8320AR-036 Full Rear Modules ADC-8434-A User Manual (Iss. 01) Introduction • 1–3...
  • Page 12: User Interfaces

    DashBoard, refer to the DashBoard User Manual available from our website. Card-edge Controls The ADC-8434-A provides card-edge controls for adjusting the gain levels, selecting the reference, and configuring remote control options. The front-edge of the ADC-8434-A also includes LEDs that display the status of the input signals. As selections are made in the menus, the LEDs display the status of the input signals.
  • Page 13: Documentation Terms And Conventions

    20-slot (DFR-8321 series frames) frames and any available options unless otherwise noted. • “Frame” refers to DFR-8300 series frame that houses the ADC-8434-A, as well as any openGear frames. • “Operator” and “User” refer to the person who uses ADC-8434-A.
  • Page 14 1–6 • Introduction ADC-8434-A User Manual (Iss. 01)
  • Page 15: Installation

    Installation In This Chapter This chapter provides instructions for installing the Rear Module(s) for the ADC-8434-A, installing the card into the frame, and cabling details. The following topics are discussed: • Before You Begin • Installing the ADC-8434-A • Cabling for the ADC-8434-A •...
  • Page 16: Before You Begin

    Unpacking Unpack each ADC-8434-A you received from the shipping container and ensure that all items are included. If any items are missing or damaged, contact your sales representative or Ross Video directly.
  • Page 17: Installing The Adc-8434-A

    Note that Slot 1 is the left most slot as you look into the openGear frame from the front. Rear Modules for the ADC-8434-A The Rear Module for the ADC-8434-A depends on the openGear frame you are installing the card into. The following rear modules are required: •...
  • Page 18: Installing The Adc-8434-A

    1. Locate the Rear Module you installed in the procedure “Installing a Rear Module” on page 2-3. 2. Hold the ADC-8434-A by the edges and carefully align the card-edges with the slots in the frame. 3. Fully insert the card into the frame until the rear connection plus is properly seated in the Rear Module.
  • Page 19: Cabling For The Adc-8434-A

    DFR-8300 series frames. Connect the input and output cables according to the following sections. DFR-8310 Series Frame Cabling Overview In the DFR-8310 series frames, the ADC-8434-A is used with the following Rear Modules: • 8310AR-036 Rear Module — Each module occupies one slot and accommodates one card.
  • Page 20: Software Upgrades For The Adc-8434-A

    — DashBoard version 3.0.0 or higher is required for this procedure. To upgrade the software on a card 1. Contact Ross Technical Support for the latest software version file. 2. Display the Device View of the card by double-clicking its status indicator in the Basic Tree View.
  • Page 21: User Controls

    User Controls In This Chapter This chapter provides a general overview of the user controls available on the ADC-8434-A. The following topics are discussed: • Card Overview • Configuring the DIP Switches • Control and Monitoring Features ADC-8434-A User Manual (Iss. 01)
  • Page 22: Card Overview

    OFF — DIP Switch status is reported in DashBoard, however DIP Switch settings are ignored. Parameter adjustments made in DashBoard are applied. SW3 is used for factory service only. Do not use SW3 unless instructed to do so by Ross Technical Support personnel.
  • Page 23 SW9, SW10 — Input Level Selection SW9 and SW10 are used in conjunction to specify the input level (+4dB). Refer to the section “Setting the Nominal Input Level” on page 3-4 for details. ADC-8434-A User Manual (Iss. 01) User Controls • 3–3...
  • Page 24: Configuring The Dip Switches

    Configuring the DIP Switches This section provides a brief summary of the DIP switches of the ADC-8434-A. Refer to Figure 3.1 for DIP Switch locations. Figure 3.2 shows all the DIP Switches in the OFF position. Figure 3.2 Jumper and Switch Locations...
  • Page 25: Control And Monitoring Features

    Control and Monitoring Features This section provides information on the LEDs for the ADC-8434-A. Refer to Figure 3.3 for the location of the LEDs. Figure 3.3 ADC-8434-A Card-edge Controls Status LEDs on the ADC-8434-A The front-edge of the ADC-8434-A has LED indicators for the communication activity. Basic LED displays and descriptions are provided in Table 3.4.
  • Page 26 3–6 • User Controls ADC-8434-A User Manual (Iss. 01)
  • Page 27: Dashboard Menus

    DashBoard Menus In This Chapter This chapter provides a summary of the menus available for the ADC-8434-A. Parameters noted with an asterisk (*) are the default values. The following topics are discussed: • Status Tabs • Settings Tab ADC-8434-A User Manual (Iss. 01)
  • Page 28: Status Tabs

    Status Tabs The Status tabs provide read-only information such as software revision issue, signal status, and power consumption of the ADC-8434-A. Card Info Tab Table 4.1 summarizes the read-only information displayed in the Card Info tab. Table 4.1 Card Info Tab Items...
  • Page 29: Settings Tab

    ADC # Output Mode converter Left Only Right Only Calibrates the analog nominal input level of the card. Input Calibration Note that this setting overwrites the value set by SW9 and SW10. ADC-8434-A User Manual (Iss. 01) DashBoard Menus • 4–3...
  • Page 30 4–4 • DashBoard Menus ADC-8434-A User Manual (Iss. 01)
  • Page 31: Specifications

    Specifications In This Chapter This chapter provides the technical specifications for the ADC-8434-A. Note that specifications are subject to change without notice. The following topics are discussed: • Technical Specifications ADC-8434-A User Manual (Iss. 01) Specifications • 5–1...
  • Page 32: Technical Specifications

    Technical Specifications This section provides the technical specifications for the ADC-8434-A. Table 5.1 ADC-8434-A Technical Specifications Category Parameter Specification Number of Inputs 4 balanced channels (2 stereo pairs) Connector Terminal Block (WECO™) Analog Inputs Impedance >20kOhms Nominal Input Level +4dB...
  • Page 33: Service Information

    Service Information In This Chapter This chapter contains the following sections: • Troubleshooting Checklist • Warranty and Repair Policy ADC-8434-A User Manual (Iss. 01) Service Information • 6–1...
  • Page 34: Troubleshooting Checklist

    Routine maintenance to this openGear product is not required. In the event of problems with your ADC-8434-A, the following basic troubleshooting checklist may help identify the source of the problem. If the frame still does not appear to be working properly after checking all possible causes, please contact your openGear products distributor, or the Technical Support department at the numbers listed under the “Contact Us”...
  • Page 35: Warranty And Repair Policy

    FIVE (5) years from the date of shipment from our factory. In the event that your ADC-8434-A proves to be defective in any way during this warranty period, Ross Video Limited reserves the right to repair or replace this piece of equipment with a unit of equal or superior performance characteristics.
  • Page 36 Contact Us Contact our friendly and professional support representatives for the following: • Name and address of your local dealer • Product information and pricing • Technical support • Upcoming trade show information Telephone: +1 613 • 652 • 4886 Technical After Hours Emergency: +1 613 •...
