USER MANUAL
Congratulations on purchasing GOPRO TRAP-2, an automatic system of photo-video
documentation.
GOPRO-TRAP 2 was born from many years of experience in wildlife research and
environmental monitoring, the system allows you to create day and night video
documentation in FULL HD without human operator and in every weather condition for the
detection / documentation of various rare and elusive species of fauna, for the control of
the environment, for environmental surveillance and private security as well as for sport.
The versatility of the system allows the use of wireless remote sensors (optional).
That can be positioned at a distance, the use of a solar panel (optional) for auto-recharge.
All the components can be secured to natural supports or mounted on tripods.
Systems of photo-video trapping can be used for the purposes authorized by law
and its procedures. Any other use is to be considered illegitimate.
Before using the system, we recommend that you READ THIS MANUAL CAREFULLY
which contains all the answers to any doubts about the correct use.
It is recommended to perform function tests prior to operating.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for GoPro GOPRO TRAP-2
Summary of Contents for GoPro GOPRO TRAP-2
-
Page 1: User Manual
USER MANUAL Congratulations on purchasing GOPRO TRAP-2, an automatic system of photo-video documentation. GOPRO-TRAP 2 was born from many years of experience in wildlife research and environmental monitoring, the system allows you to create day and night video documentation in FULL HD without human operator and in every weather condition for the detection / documentation of various rare and elusive species of fauna, for the control of the environment, for environmental surveillance and private security as well as for sport. - Page 2 Components: The camera and DVR with their equipment and the electronic circuit are hosted in a polypropylene container, equipped with relief valve, durable and weatherproof, that protects the components from the wheather conditions. It houses: 1-Camera 2-Electronic circuit with connectors and display 3-Battery Power Other components: 4-Sensor sleeve...
- Page 4 Our systems OPTIONALS AND ACCESSORIES WIRELESS SENSOR setting schemes...
- Page 5 DIP 1 DIP 2 DIP 3 DIP 4 FUNCTION ILLUSTRATION PIR tracking for 10” after ignition Only night Day-night Day-night Only day High sensitivity sensitivity...
-
Page 6: Operation - Adjustments
OPERATION - ADJUSTMENTS First, move the power switch (9) to ON After 5 seconds the display will show the word PASSWORD. Enter default password (12341234). To change it see the last menu entry in the dialog box shown below. * WARNING *: store the password and always remember it: you cannot use the tool without the password, and the system will be sent to the assistance in order to reconfigure it again! (this operation is not under warranty). - Page 7 REGOLA PARAMETRI (SET PARAMETERS) + + PUNTAMENTO SENSORE PIR (POINTING PIR SENSOR) (see note *) MENU / OK the device is set to be positioned conveniently to go to Stabilizzazione PIRS (PIRS Stabilization) During stabilization (which thus stops) or at any subsequent time, you can enter settings and controls for the system: verification of data and settings and selection of the various adjustments 1.
- Page 8 MENU / OK – to choose Italiano o English to go back to REGOLA PARAMETRI (Set parameters) After completing the selection of settings, it is time to ACTIVATE THE SYSTEM pressing ESC STABILIZ PIRS, after few seconds GoProTrap2 will be operative. * Notes: NUMBER OF PIR EVENTS To reset press and hold for 3 seconds - button (less)
- Page 9 In addition, the PIR sensitivity is closely related to temperature. The higher is the temperature the lower will be the sensitivity of the PIR beyond the sensitivity level selected. So it is suggested to select the "High" level of sensitivity in high temperature environments. With the function off, you can completely disconnect the frontal PIR sensor and start recording video troggered only by wireless sensors.
- Page 10 Before turn on the system for the first time, it is advisable to charge the battery of the Go Pro Camera connecting the appropriate USB cable to a computer. The front light will flash red until the full charge. If the Go Pro is turned off or not used for a medium / long term (over 30 days) it is advisable to repeat the procedure.
