Summary of Contents for Amar Sun Technology Wireless Broadband Router

  • Page 1 Wireless Broadband Router User Manual...

  • Page 2: Table Of Contents

    Contents Features...........................3 Connecting Router .........................5 1. Hardware Installation ......................5 2. Connect to the router......................5 2.1 Correctly set up your computer network configuration ..........5 2.2 Verify the network connection properly..............8 3. Setup Wizard ........................9 1.1 Operation Mode....................10 1.2 Time Zone Setting ....................11 1.3 LAN Interface Setup ....................12 1.4 WAN Interface Setup...................13 1.5 Wireless Basic Settings ..................14...

  • Page 3: Features

    10. Routing Setup.......................38 11. Management........................40 8.1 Status ........................40 8.2 Statistics ........................41 8.3 Dynamic DNS Setting ..................42 8.4 Time Zone Setting ....................43 8.5 Denial of Service....................44 8.6 Log ..........................45 8.7 Upgrade Firmware ....................46 8.8 Save/Reload Settings ..................47 8.9 Password .......................47 Appendix: Glossary......................48 Features Complies with IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE 802.3u standards.
  • Page 4 Supports IGMP Proxy. Connecting Internet on demand and disconnecting from the Internet when idle for PPPoE. Built-in firewall function, support domain filtering and MAC address filtering, can according to the designated computer Internet access open. Support DoS attack prevention, has the virus automatic isolation function. Support ARP guard function, can effectively prevent the connection deceive attack.

  • Page 5: Connecting Router

    Connecting Router 1. Hardware Installation Before setting up the router, please follow these steps for proper connection. 1、Use the network cable to connect the router LAN port and your computer network card. 2 、 Please use the standard power adapter to the router. 3 、...
  • Page 6 2、In the following window opens, right click on the "local connection", select "Properties" 3、In the pop-up dialog box, select the "Internet Protocol (TCP / IP)", then mouse click "Properties" button in the pop-up dialog box, select the "Internet Protocol (TCP / IP)", then mouse click "Properties" button.
  • Page 7 4、In the following window opened, you can choose "automatic IP address (0)" or "Use the following IP address (S); A、"Automatically obtain IP address (0)" as shown below:...

  • Page 8: Verify The Network Connection Properly

    B、"Use the following IP address (S)" IP Address: 192.168.1.XXX: (XXX is 2 to 254) Subnet mask：255.255.255.0 Gateway： 192.168.1.1 DNS Servers：You can fill out your local DNS server address (ask your ISP provider) and also make the router as a DNS proxy server. After setup is completed click "OK"...

  • Page 9: Setup Wizard

    After your successful login, you can see the interface as follows: You can configure and manage the router. There are seven main menus on the left of the Site contents. Submenus will be available after you click one of the main menus. The seven main menus are: Setup Wizard, Operation Mode, Wireless, TCP/IP Settings, Firewall, Management, Reboot.

  • Page 10: Operation Mode

    1.1 Operation Mode You can setup different modes to LAN and WLAN interface for NAT and bridging function.

  • Page 11: Time Zone Setting

    Click the "cancel" button to cancel the setting. Click the "Back" button to return to top-level directory. Click the "Next" button to get into the next-level directory. 1.2 Time Zone Setting You can maintain the system time by synchronizing with a public time server over the Internet.

  • Page 12: Lan Interface Setup

    Click the "cancel" button to cancel the setting. Click the "Back" button to return to top-level directory. Click the "Next" button to get into the next-level directory. 1.3 LAN Interface Setup You can configure the parameters for local area network which connects to the LAN port of your Access Point.

  • Page 13: Wan Interface Setup

    255.255.255.0 as the subnet mask. Click the "cancel" button to cancel the setting. Click the "Back" button to return to top-level directory. Click the "Next" button to get into the next-level directory. Note: If you change the IP Address of LAN, you must use the new IP Address to login the router.

  • Page 14: Wireless Basic Settings

    by your ISP if provided. DNS 3 - (Optional) Type the third DNS address in dotted-decimal notation provided by your ISP if provided. c. If you choose PPPoE, you should enter the following parameters. User Name/Password - Enter the User Name and Password provided by your ISP. These fields are case-sensitive.

  • Page 15: Wireless Security Setup

    Click the "cancel" button to cancel the setting. Click the "Back" button to return to top-level directory. Click the "Next" button to get into the next-level directory. 1.6 Wireless Security Setup You can setup the wireless security. Turn on WEP, WPA, WPA 2 or WPA 2 Mixed by using Encryption Keys could prevent any unauthorized access to your wireless network.

  • Page 16: Operation Mode

    Click the "Back" button to return to top-level directory. Click the "Next" button to get into the next-level directory. Click the "Finished" button to enable configuration to take effect. 4. Operation Mode As the following screenshots, you can setup different modes to LAN and WLAN interface for NAT and bridging function.

  • Page 17: Wireless

    Click "Apply Change" button to enable configuration to take effect. Click "Reset" button to reset. 5. Wireless There are seven submenus under the Wireless menu : Basic Settings, Advanced Settings, Security, Access Control, WDS settings, Site Survey and WPS. Click any of them, and you will be able to configure the corresponding function.
  • Page 18 Mode — you can choose four types of mode: Client, AP, WDS, AP+WDS. Network Type — while you choose client mode, you can configure the network type. SSID — Enter a value of up to 32 characters. The same name (SSID) must be assigned to all wireless devices in your network.

  • Page 19: Wireless Advanced Settings

    While you choose AP or AP+ WDS mode, you can click "Show Active Clients" to look over the active clients. AS follows: This table shows the MAC address, transmission, receive packet counters and encrypted status for each associated wireless client. Click "Apply Change"...

  • Page 20: Wireless Security Setup

    Click "Apply Change" button to enable configuration to take effect. Click "Reset" button to reset. 3.3 Wireless Security Setup You can setup the wireless security. Turn on WEP or WPA by using Encryption Keys could prevent any unauthorized access to your wireless network.

  • Page 21: Wireless Access Control

    Encryption —if you select "Disable" the wireless stations will be able to connect the router without encryption. The encryption settings are described below. Authentication Type - You can select one of the following authentication types: WEP 、WPA 、WPA2 、WPA-Mixed Note: When you choose one of the four authentication types, you must set the key value.

  • Page 22: Wds Settings

    Click "Apply Change" button to enable configuration to take effect. Click "Reset" button to reset. Click "Delete Selected" button to remove the selected access control list. Click "Delete ALL" button to clear the current access control list. 3.5 WDS Settings Wireless Distribution System uses wireless media to communicate with other APs, like the Ethernet does.

  • Page 23: Wireless Site Survey

    3.6 Wireless Site Survey This page can scan the wireless network, when the operation mode of the router set as wireless ISP mode, in the wireless basic Settings are set to model, it can be connected to search to any AP or IBSS, recommend choice connect without encryption wireless network, and stronger signals.

  • Page 24: Wps

    3.7 WPS This page allows you to change the setting for WPS (Wi-Fi Protected Setup). Using this feature could let your wireless client automatically synchronize its setting and connect to the Access Point in a minute without any hassle. This page can change WPS Settings, this feature allows routers and another machine configuration has WPS wireless set between automatic build a wireless encrypted connection.

  • Page 25: Tcp/Ip Settings

    Allow wireless time: enabled wireless time limit function; Weeks: choose you want to use wireless number of days, optional every day of the week, or what days; Time: choose you want to use wireless number of days, optional always, or the exact setting time, Setting is completed, click ok to save these Settings, the system can hint whether restart routers, you can choose to "reboot", only later, after restart router configuration...
  • Page 26 mask, DHCP, etc. Note: a. If you change the IP Address of LAN, you must use the new IP Address to login the router and you must change the DHCP Client Range at the same time. b. If the new LAN IP Address you set is not in the same subnet, the IP Address pool of the DHCP server will not take effect, until they are re-configured.

  • Page 27: Wan Interface Setup

    4.2 WAN Interface Setup You can configure the parameters for Internet network which connects to the WAN port of your Access Point. Here you may change the access method to static IP, DHCP, PPPoE or PPTP by click the item value of WAN Access type. a.
  • Page 28 You should type the following parameters into the spaces provided: IP Address - Enter the IP address in dotted-decimal notation provided by your ISP. Subnet Mask - Enter the subnet Mask in dotted-decimal notation provided by your ISP, usually is 255.255.255.0. Default Gateway - (Optional) Enter the gateway IP address in dotted-decimal notation provided by your ISP.
  • Page 29 your ISP. DNS 2 - (Optional) Type another DNS address in dotted-decimal notation provided by your ISP if provided. DNS 3 - (Optional) Type the third DNS address in dotted-decimal notation provided by your ISP if provided. b. If you choose PPPoE, you should enter the following parameters. User Name/Password - Enter the User Name and Password provided by your ISP.

  • Page 30: Firewall

    These fields are case-sensitive. Connection Type: Connect on Demand - You can configure the router to disconnect your Internet connection after a specified period of inactivity (Max Idle Time). If your Internet connection has been terminated due to inactivity, Connect on Demand enables the router to automatically re-establish your connection as soon as you attempt to access the Internet again.

  • Page 31: Ip Filtering

    Click "Apply Changes" button to enable configuration to take effect. Click "Rest" button to rest. Click "Delete Selected" button to remove the selected filter entry. Click "Delete ALL" button to clear the current filter table. 5.2 IP Filtering The IP address Filtering feature allows you to control Internet Access by specific users on your LAN based on their IP addresses.

  • Page 32: Mac Filtering

    Click "Apply Changes" button to enable configuration to take effect. Click "Rest" button to rest. Click "Delete Selected" button to remove the selected filter entry. Click "Delete ALL" button to clear the current filter table. 5.3 MAC Filtering The MAC Filtering allows you to control access to the internet by users on your local network based on their MAC Address.

  • Page 33: Port Forwarding

    Click "Apply Changes" button to enable configuration to take effect. Click "Rest" button to rest. Click "Delete Selected" button to remove the selected filter entry. Click "Delete ALL" button to clear the current filter table. 5.4 Port Forwarding Entries in this table allow you to automatically redirect common network services to a specific machine behind the NAT firewall.

  • Page 34: Url Filtering

    Click "Apply Changes" button to enable configuration to take effect. Click "Rest" button to rest. Click "Delete Selected" button to remove the selected port forwarding entry. Click "Delete ALL" button to clear the current port forwarding table. 5.5 URL Filtering URL filter is used to deny LAN users from accessing the internet.

  • Page 35: Dmz

    Click "Apply Changes" button to enable configuration to take effect. Click "Rest" button to rest. Click "Delete Selected" button to remove the selected filter entry. Click "Delete ALL" button to clear the current filter table. 5.6 DMZ A Demilitarized Zone is used to provide Internet services without sacrificing unauthorized access to its local private network.

  • Page 36: Vlan

    5.7 VLAN Entries in below table are to config vlan settings.VLANs are created to provide the segmengation services traditionally provided by routers.VLANs address issues such as acalbility,security,and network management. Enable VLAN: enable VLAN function; To Prot1 ~ 4 (Ethernet Wireless LAN) ask AP (LAN), a insgroupsto AP1 ~ 4 (Ethernet LAN), Prot5 (WAN) setting.
  • Page 37 Entries in this table improve your online gaming experience by ensuring that your game traffic is prioritized over other network traffic, such as FTP or Web. Enable QOS: enable QOS function; Can choose automatic uplink speed, automatic descending speed, Also can manual Settings uplink speed, descending speed. Unit is Kbps (not less than 100Kbps).

  • Page 38: Routing Setup

    MAC address: choose the type for the MAC address is, need to fill in to limit the MAC address; Pattern: select the smallest bandwidth guarantee, or maximum bandwidth guarantee. Uplink bandwidths: fill to limit the uplink bandwidths. Downlink bandwidth: fill to limit downline bandwidth. Annotation: fill in the description.
  • Page 39 Allow dynamic routing: enable dynamic routing functions; NAT: default is Enabled, still can choose harbor, Send: default is harbor, still can choose RIP1 or RIP2; Reception: default is harbor, still can choose RIP1 or RIP2; Fill after completion, click ok to save these Settings, the system can hint whether restart router, can choose "later, only after the restart"...

  • Page 40: Management

    waiting for 30 seconds. Reset: reset. In "static routing table" will display has added successful static routing table of information. Delete options: delete selected item, Delete all: delete filter in the list of all entries, Reset: reset. Note: NAT: Network Address Translation (NAT, they maybe) belong to access a WAN technology, is a private (reserves) addresses into legitimate IP Address of conversion technology, it is widely used in various types of Internet access and various types of Network.

  • Page 41: Statistics

    8.2 Statistics The Statistics page displays the network traffic of each PC in LAN, including total traffic and traffic of the last Packets Statistic interval seconds.

  • Page 42: Dynamic Dns Setting

    8.3 Dynamic DNS Setting Dynamic DNS is a service, that provides you with a valid, unchanging, internet domain name (an URL) to go with that (possibly everchanging) IP-address. To set up for DDNS, follow these instructions: 1. Type the domain names your dynamic DNS service provider gave. 2.

  • Page 43: Time Zone Setting

    Click "Apply Changes" button to enable configuration to take effect. Click "Rest" button to rest. 8.4 Time Zone Setting You can maintain the system time by synchronizing with a public time server over the Internet.

  • Page 44: Denial Of Service

    Click "Copy Computer Time" button, copy the computer time to the router. Click "Apply Changes" button to enable configuration to take effect. Click "Rest" button to rest. 8.5 Denial of Service A "denial-of-service" (DoS) attack is characterized by an explicit attempt by hackers to prevent legitimate users of a service from using that service.

  • Page 45: Log

    8.6 Log You can see the system log if you enable system log. You can set remote log server.

  • Page 46: Upgrade Firmware

    8.7 Upgrade Firmware You can upgrade the Access Point firmware to new version. Click "Browse…" button, and choose the upgrade files, then click '"upload" button. When you upgrade the router's firmware, do not power off the device because it may crash the system. The router will reboot after the upgrading has been finished.

  • Page 47: Save/Reload Settings

    8.8 Save/Reload Settings You can save current settings to a file or reload the settings from the file which was saved previously. Besides, you could reset the current configuration to factory default. Click "save" button to save current settings to a file. Click "Browse…"...

  • Page 48: Appendix: Glossary

    Click "Apply Changes" button to enable configuration to take effect. Appendix: Glossary 2x to 3x eXtended Range WLAN Transmission Technology - The WLAN device with 2x to 3x eXtended Range WLAN transmission technology make its sensitivity up to 105 dB, which gives users the ability to have robust, longer-range wireless connections.
  • Page 49 videoconferencing. DNS (Domain Name System) - An Internet Service that translates the names of websites into IP addresses. Domain Name - A descriptive name for an address or group of addresses on the Internet. DoS (Denial of Service) - A hacker attack designed to prevent your computer or network from operating or communicating.
  • Page 50 Amar Sun Technology Co., Limited Address: Left Oriental Start Building, Meihua Road, Shangmeilin, Futian District, Shenzhen, Guangdong, China Zip code: 518049 Tel:86-755-83129559 Fax:86-755-83120511 Mobile:18926435245 Email: carmenzheng@amarsun.com.cn Homepage: www.szamarsun.com www.amarsun.com.cn...
