Summary of Contents for Defender Security 82-12460
-
Page 1: User Manual
5.6” TFT LCD MONITOR User Manual Part Number 82-12460 Edition V1.00... -
Page 2: Safety Information
Notice: Federal Communications Commission (FCC) This equipment has been tested and found to comply with the limitations for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 3: Warranty Information
A 1-year warranty against workmanship from the data of purchase is valid only if the monitor housing is unopened. If a problem is encountered under normal use, please contact Defender Security Customer Service at 1-800-543-4330. Warranty cannot be guaranteed if damage to the monitor... -
Page 4: Table Of Contents
INDEX Introduction................... 5 Package Contents..............5 TFT LCD Monitor..............6 OSD Menu ................8 OSD Menu Descriptions ............. 8 Test Patterns................ 9 Dimension: ................9 Specifications ................10 Specifications........Error! Bookmark not defined. -
Page 5: Introduction
Introduction Before operating you new 5.6” TFT LCD Monitor, please review the following: • Check package contents • Review TFT LCD Monitor controls • Review Monitor function keys Check package The following items are packaged with the monitor when shipped. Please note that some optional accessories may not be included in your package. -
Page 6: Tft Lcd Monitor
TFT LCD Monitor Controls Refer to the following front, side and rear view figures and charts describing the controls and inputs on TFT LCD monitor: Front view Description Power / Charge indicator Power on/off Input signal source selection Speaker TFT LCD Display Speaker Volume Down Control, or Scroll Down menu selections OSD Menu / Picture... - Page 7 Side View Description Power ON/OFF/Charge Power input jack (12VDC) 3.5mm Audio Input/ Output BNC Video Output BNC Video1 / Video 2 Input Rear View: Description Rechargeable battery/cover...
-
Page 8: Osd Menu
OSD Menu 1. LANGUAGE 2. AUTO OFF 3. CONTRAST 4. BRIGHTNESS 5. COLOR 6. TINT 7. SHARPNESS 8. RECALL 1. Press “PICTURE” function key to display the on-screen “MENU” 2. Use UP/DOWN function keys to scroll through the menu options. Press the “PICTURE”... -
Page 9: Test Patterns
TEST PATTERNS Press the “SOURCE” button, and select “PATTERN” in the sub-menu. Use the “DOWN”/ “UP” arrows to select the desired test pattern: Cross-hatch Color Bars Point Dimension:... -
Page 10: Specifications
Specifications: Item Specification LCD Display 5.6” TFT LCD Monitor Resolution 320(H) x 234(V) (4:3) Contrast ratio 150:1 Brightness 300cd/m Response Time Tr / Tf 35ms(tr+tf) Display Mode Video 1,Video 2,Test pattern 2 x BNC Inputs (1.0Vp-p 75Ω) Input 1 x Audio Input (3.5mm stereo Jack) 1 x BNC Outputs (2.0Vp-p 75Ω) Output 1 x Audio Output (3.5mm stereo Jack)
