Summary of Contents for AMOI LC26A1E
-
Page 2: Table Of Contents
Contents Safety Precautions Important Safety Instructions Overview of TV Panel Description Back Panel Description Antenna Connections Connections I. YPbPr/YCbCr (component) Connection ii. S-Video and Video (Composite) Connections Iii. Scart Connections iv. PC Connection/Audio Out Connection v. HDMI/DVI Connection Remote Control Overview (All Functions Except Teletext) Remote Control Overview (Teletext Functions) Remote Control Operation Basic Operation... -
Page 3: Safety Precautions
NOTE TO CABLE/TV INSTALLER: Do not attempt to modify this product in any way This reminder is provided to call the cable TV without written authorization from AMOI system installer's attention to Article 820-40 of Electronics Co., Ltd. Unauthorized modification the National Electric Code (U.S.A.). -
Page 4: Important Safety Instructions
Important Safety Instructions 1.Read These Instructions-All the safety and 12.Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold operating instructions should be read before the with the apparatus. When a cart is used, use product is operated. - Page 5 Important Safety Instructions 17.Power Lines -An outside antenna system should 23.Outdoor Antenna Grounding -If an outside not be located in the vicinity of overhead power antenna or cable system is connected to the lines or other electric light or power circuits, or product, be sure the antenna or cable system is where it can fall into such power lines or circuits.
-
Page 6: Overview Of Tv
Panel Description Overview of TV SOURCE Press to display the menu of available viewing sources. MENU Press to display the OSD menu. CH+/- Press to change the channel. The two buttons also act as direction buttons VOL+/- Press to adjust volume. The two buttons also act as direction buttons POWER Power on/off the TV. -
Page 7: Back Panel Description
Back Panel Description Overview of TV Video input VIDEO Audio input AUDIO AV IN S-Video input S-VIDEO Headphone Output Rear interface Rear interface description ～ － 110 240 V 50/60HZ POWER EXT1 EXT2 ANTENNA HDMI DVI IN PC AUDIO IN PC IN... -
Page 8: Antenna Connections
Antenna Connections *For optimum picture quality, adjust antenna direction. Indoor Antenna Connection Typical Wall antenna jack used in apartment buildings, connect the antenna cable as shown below (Please use the correct type of antenna cable according to the type of wall antenna jack). 75 ohm Round Cable Bronze Wire 300 ohm Flat Wire... -
Page 9: Ypbpr/Ycbcr (Component) Connection
YPbPr/YCbCr (Component) Connection DVD etc Pr Cr Pb Cb AUDIO(L) AUDIO(R) Audio Cable Component Cable Note: Please refer to the illustration above to connect TV with DVD player or other component signal sources. Connect Component Cable and Audio Cable to corresponding jacks of DVD player or other component signal sources. -
Page 10: S-Video And Video (Composite) Connections
S-Video and Video (Composite) Connections S-Video or composite signal output POWER AUDIO(R) AUDIO(L) VIDEO S-VIDEO AV-3 IN VIDEO AV Cable AV IN AUDIO S- Video Cable S-VIDEO Note： 1.Please refer to the illustration above and in the last page to connect TV with S-Video or other composite signal sources. -
Page 11: Scart Connections
Scart Connections Scart connections(Example) DVD etc Scart Scart Cable Note: Please refer to the above illustration to connect TV with DVD player. Connect Scart Cable to the corresponding jacks of DVD player or other devices. Please choose EXT1, EXT2 or EXT3 in the Source menu when you connect DVD palyer or other sources with Scart connection. How to select viewing source(''EXT1/EXT2'') Please press the "SOURCE"... -
Page 12: Pc Connection/Audio Out Connection
P C Connection/Audio Out Connection PC Connection PC IN PC AUDIO IN AUDIO VGA Cable Audio Cable Note: 1.Please refer to the illustration above to connect TV with PC or DVD player. Connect VGA Cable and Audio Cable to the corresponding jacks of PC and s elect the signal source "... -
Page 13: Hdmi/Dvi Connection
HDMI/DVI Connection Picture A HDMI DVI IN HDMI HDMI Cord PictureB HDMI DVI IN PC AUDIO IN AUDIO(R) AUDIO(L) HDMI I Cord VGA Cord Connet TV with corresponding jacks on DVD or STB, and switch the source to HDMI in Source menu. "... -
Page 14: Remote Control Overview (All Functions Except Teletext)
Remote Control Overview (All Functions Except Teletext) Power button Last source No-picture Main source MUTE To freeze current image Display status To set sleep time Aspect Picture mode Sound mode Dual sound selection Numerical buttons Previous channel Channel list Volume up/down Next/previous channel Fast forward... -
Page 15: Remote Control Overview (Teletext Functions)
Remote Control Overview (Teletext Functions) Teletext PageUp Teletext Index Teletext PageDown Teletext Subpage Up Teletext Subpage Down Teletext SubPage Teletext Size Teletext Display/Mix Teletext Hold Teletext Reveal Teletext Color button -13-... -
Page 16: Remote Control Operation
Remote Control Operation Batteries installation Remote control direction Point the remote control at the remote sensor. Pull the battery cover downward in the direction shown by the arrow and remove it. Insert the batteries with correct polarity. Replace the battery rear cover. -
Page 17: Basic Operation
Basic Operation Power On /Off 1. Connect the TV unit to power source using power cord. 2. Turn on the power switch. 3. When the power indicator in red, the TV is in standby mode. Now press the "Power" button on remote control or front panel to turn on the TV. -
Page 18: Menu Description
Basic Operation Menu Description If you want to adjust the display settings, please follow the instruction below. Press the "MENU" button to browse the Picture Menu, Sound Menu, Channel Menu, Window Menu, Setting Menu in turn. Press "EXIT" to exit "MENU" mode. Picture Sound Channel... -
Page 19: Picture Menu
Picture Menu Picture Setting You can adjust the Picture effection to meet your favorite picture requirement. Press the ''MENU'' button to enter Picture menu. Press '' '' buttons to select ''Picture Mode''. Picture Sound Window Channel Setting Press '' '' buttons to adjust the "Picture mode". Picture Mode User Brightness... -
Page 20: Sound Menu
Sound Menu Sound Mode You can use this function to adjust the perfect audio effect. Press "MENU" button to select "Sound" menu. Press " " buttons to select sub items. Picture Sound Channel Window Setting Press " " buttons to change the setting. Sound Mode User Bass... -
Page 21: Channel Menu
Channel Menu Channel Menu Sound System Press "MENU" button to select "Channel menu. " Picture Sound Channel Window Setting Press " " buttons to select " Sound System'' Sound System Press " " buttons and choose the suitable systemof Current Channel local TV signal. - Page 22 Channel Menu Channel Menu Rename Channel You can rename the channel when you are browsing the channel list. Press "MENU" button to select "Channel menu. " Channel Picture Sound Window Setting Press " " buttons to select " Rename Channel'' Sound System Press "...
-
Page 23: Auto Search
Channel Menu Auto search " " You can set TV program list with Auto Searching function quickly. Press the "MENU" button to select "Channel" menu. Press the " " buttons to select "Channel Preset". Picture Sound Channel Window Setting Sound System Current Channel Skip Channel Rename Channel... -
Page 24: Manual Search
Channel Menu Manual search You can also set program list again one by one by "Manual Search" function. Press the MENU button to select " " "Channel" menu Press the " " buttons to select "Channel Preset ". Picture Sound Channel Window Setting... -
Page 25: Fine Tuning
Channel Menu Fine tuning "Fine tune" helps you adjust specific programs image and sound quality. Press the "MENU" button to select "Channel" menu. Press the " " buttons to select "Channel Preset". Picture Sound Channel Window Setting Sound System Current Channel Skip Channel Rename Channel Exchange... -
Page 26: Window Menu
Window Menu Aspect You can adjust the aspect to meet your requirement. Press "MENU" button to select "Window" menu. Picture Sound Window Channel Setting Press " " buttons to select '' Aspect Ratio Press " " buttons to change the setting. Aspect Ratio Full Screen PC Window... -
Page 27: Setting Menu
Setting Menu OSD language setting Press "MENU" button to select "Setting" menu. Press " " buttons to select '' OSD Language Picture Sound Channel Window Setting Press " " buttons to change the setting. English OSD Language Country Color Temperature Timer Setting Source Setting Other... -
Page 28: Sleep Timer
Setting Menu Current Date/time Press '' MENU'' button to select ''Setting’' menu. Press '' '' buttons to select ''Timer Setting''. Picture Sound Channel Window Setting Press '' '' button to enter the menu. English OSD Language Country U.K. Color Temperature Timer Setting Source Setting Other... - Page 29 Setting Menu Setting the Wake up timer You can set the Wake up timer , then your TV set will switch on automatically. Press the ''MENU'' button to select ''Setting'' menu. Picture Sound Channel Window Setting Press '' '' buttons to select ''Timer Setting''. English OSD Language Country...
- Page 30 Setting Menu Setting the alarm clock Press the ''MENU'' button to select ''Settings'' menu. Press '' '' buttons to select ''Timer Setting''. Picture Sound Window Channel Setting English OSD Language Country U.K. Color Temperature Timer Setting Source Setting Other Setting Timer Setting Press '' '' button to enter "...
-
Page 31: Source Setting
Setting Menu Source Setting Press "MENU" button to select "Setting" menu. Picture Sound Channel Window Setting Select "Source Setting" item, then press" " button to enter. English OSD Language Press " " buttons to select the sub item. Country U.K. Color Temperature Press "... -
Page 32: Function Button Instruction
Function button Instruction MUTE ● Press the button to mute audio, press again to resume. VOL+/- ● Press "VOL+" button to increase the volume; ● Press "VOL- " button to decrease the volume. Volume Earphone Volume ● Press the '' +'' button to increase the earphone volume; ●... - Page 33 Function button Instruction Use numerical button to select the channel directly ● To select a one-digit channel: Press from 0-9 to directly input your desired channel number. ● To select a two-digit channel: Press from 1-9 to input the first digit and from 0-9 to input the second digit ●...
- Page 34 Function button Instruction Browse the channel list ● Press "LIST" button, the Channel list will display on screen. LIST Channel list 5 CV 0 CCTV5 1 CCTV1 6 CCT 2 CCTV2 7 CC 8 CTV2 3 CCTV3 9 CC3 4 CCTV4 Use direction buttons to select specific channel.
- Page 35 Function button Instruction ASPECT ● Press "ASPECT" button, the following window will be displayed on the screen. Aspect Ratio Full Screen Press '' '' buttons or ''Aspect'' button to select your favourite mode. Five options: Full Screen/4:3/Wide/Subtitle/Standard. Note: 1. Support "Auto Scale Mode". 2.
- Page 36 Function button Instruction Dual sound ● The options of Dual setting in single picture is as follows: Options Source Mono A stereo signal Nicam stereo Mono In the NICAM Nicam Dual_A A bilingual signal broadcasts Nicam Dual_B Nicam Dual_AB Mono A monaural signal Nicam Mono Mono...
-
Page 37: Use Usb Memory And Multimedia Memory Card
Use USB Memory and Multimedia Memory Card This TV set is equipped with USB Memory jack and Multi-media Memory Card slot. You can enjoy pictures in JPEG, videos in MPG, DAT and MPEG-4 as well as MP3 and WMA music files stored in the USB Memory and Multi-media Memory Card, both of which support synchronized playback of music and pictures. -
Page 38: Use Usb Memory And Multimedia Memory Card
Use USB Memory and Multimedia Memory Card Insert the USB memorizer into the USB jack on the TV or multimedia memory card into the memory card slot and then select "USB/SD/CF" as the signal source (please refer to page 18).After reading, the TV will display as shown in picture A: （... - Page 39 Use USB Memory and Multimedia Memory Card Other settings: Picture Play speed: Slow, Normal, Fast. PLAY / PAUSE ● To play or pause picture, video or music. ● To stop playback of picture, video or music. ● To exit digest. FW REV ●...
-
Page 40: Teletext
Teletext Teletext is an information system broadcast by certain channels which can be consulted like a newspaper. It also offers access to subtitles for viewers with hearing problems or who are not familiar with the transmission language (cable networks, satellite channels, etc.). Teletext Language Selection. - Page 41 Teletext HOLD Press the button once to hold page and the second time to release holding of page. Selecting a page by numeric buttons directly You can select a page by numeric buttons directly in TXT/MIX mode. PAGE DOWN/UP Use the direction buttons to page up/down.
-
Page 42: Maintenance
Maintenance Care for your TV Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you will have with your TV. Be sure to turn the power off and pull outthe plug before you begin any cleaning. -
Page 43: Trouble Shooting
Trouble Shooting Please read this user's manual before using the TV set. If you have any troubles in using this TV set, try to solve it by the suggestions mentioned below. If you can not remove the trouble after adopting corresponding suggestions, please contact the technical service center or dealer authorized by us. -
Page 44: Display Mode (Pc)
Display Mode (PC) Display Mode (PC) Both screen position and size will vary depending on the type of PC monitor and its resolution. The table below shows all of the display modes that are supported: Horizontal Frequency Resolusion Vertical Frequency Sync Polarity （... -
Page 45: Specifications
Specifications MODEL LC26AF1E LC26A1E Power Supply Input: AC110-240V 50Hz/60Hz Standby: < 1W Power Consumption Max: 150W Audio System DK/BG/I /L/L TV System PAL, SECAM Sync.: H/V Separate, TTL, P. or N. Video Signal: 0.7Vp-p, 75ohm ， Audio in: RCA JACK L&R 0.5Vrms (-9dB) - Page 46 AMOI ELECTRONICS CO., LTD. 45 TIYU RD, XIAMEN, FUJIAN 361012, CHINA URL: www.amoi.com FKV2.025.079SSE...
