GPS Car Alarm System
USER MANUAL
(Model: TK210)
GUANGZHOU TOPTEN ELECTRONICS FACTORY
Address: 20/F, Tower B, Gaoke Building, Tianhe North Road, Guangzhou, China.
Tel: (+86)20-38351400, 38351401 Fax: (+86)20-38351400
Website:http://www.t10.cn
Email:
sales@t10.cn
Version 2.0
(Date: Oct., 2011)
Advertisement
Table of Contents
Related Manuals for Topten TK210
Summary of Contents for Topten TK210
- Page 1 Wireless GPS Car Alarm System USER MANUAL (Model: TK210) GUANGZHOU TOPTEN ELECTRONICS FACTORY Address: 20/F, Tower B, Gaoke Building, Tianhe North Road, Guangzhou, China. Tel: (+86)20-38351400, 38351401 Fax: (+86)20-38351400 Website:http://www.t10.cn Email: sales@t10.cn Version 2.0 (Date: Oct., 2011)
-
Page 2: Table Of Contents
TK210 GPS Car Alarm Website: http://www.GPScaralarm.com User Manual CONTENT Preface ............................2 I. Features & Functions ......................3 II. How to Operate it ........................4 SMS Command Format ....................4 Authorize the Alert-received Mobile.................4 Change User Password....................4 Check the Real Physical Address..................5 Check the GPS Coordinates by SMS................5 Check the location by Google Map’s URL...............5... -
Page 3: Preface
² It is specially used to work with the central lock system or ordinary car alarm system. The user can use the original remote control to arm/disarm the TK210 for car security. It is very convenient for the user since there is no need of taking so many types of remotes control around. -
Page 4: Features & Functions
TK210 GPS Car Alarm Website: http://www.GPScaralarm.com User Manual I. Features & Functions 1. Arm/disarm by SMS remotely, or by the remote controller of original central lock system or existing car alarm system, or by phone call. 2. Upgrade the ordinary car alarm to GPS alarm system;... -
Page 5: How To Operate It
TK210 GPS Car Alarm Website: http://www.GPScaralarm.com User Manual II. How to Operate it SMS Command Format User can send SMS instruction to operate the tracker by any mobile phone, the format of the instruction is: User Password(******)+ Control Code(XXX) The default user password is 111111. -
Page 6: Check The Real Physical Address
TK210 GPS Car Alarm Website: http://www.GPScaralarm.com User Manual Check the Real Physical Address SMS command: 111111ADD When user sends this SMS command to the tracker, the tracker will automatically send back the car’s real physical address (such as city name, street name) to your mobile by SMS. -
Page 7: Arm/Disarm The System By Sms
TK210 GPS Car Alarm Website: http://www.GPScaralarm.com User Manual Arm/Disarm the System by SMS SMS command: 111111ARM This SMS instruction is used to arm the system SMS command: 111111DSM This SMS instruction is used to disarm the system Arm/Disarm by Phone Calling User could also use the first alarm-received mobile phone to call the system SIM card number, so as to arm/disarm the system. -
Page 8: Restore The Stopped Car To Normal Status
TK210 GPS Car Alarm Website: http://www.GPScaralarm.com User Manual Restore the Stopped Car to Normal Status SMS command: 111111RES This instruction is used to restore the car to normal status after stopping the car. It is also used to stop the receiving of SOS alert SMS once the anti-robbery SOS switch is pressed down. -
Page 9: Set Up Geo-Fence Alert
TK210 GPS Car Alarm Website: http://www.GPScaralarm.com User Manual parking point for about 80 meters, the movement alert will be triggered. Set up Geo-Fence Alert 111111FEN0 Disable the Geo-fence 111111FEN1 Enable the Geo-fence, using the stored setting 111111FEN？ Check the setting of geo-fence... -
Page 10: Adjust The Vibration Sensor's Sensitivity
TK210 GPS Car Alarm Website: http://www.GPScaralarm.com User Manual Adjust the Vibration Sensor’s Sensitivity 111111SHK0 Normal status, when sensor is activated, it will trigger the alarm immediately. It is the default setting. 111111SHK1 Time-delay status, if the sensor is activated for 3 seconds continuously, it will trigger the alarm. -
Page 11: Setting For Mute Alarm
TK210 GPS Car Alarm Website: http://www.GPScaralarm.com User Manual Setting for Mute Alarm. 111111MUTE:0 The siren will sound if there is alarm, it is the default setting 111111MUTE:1 The siren will not sound if there is alarm, but system will still send out alarm by GSM network. -
Page 12: Sos Anti-Robbery Alert
TK210 GPS Car Alarm Website: http://www.GPScaralarm.com User Manual SOS Anti-robbery Alert once the SOS switch is pressed down & hold for at least 2 seconds, the system will send alarm SMS to the second alert-received mobile & the center number. User can send command 111111RES to release it. -
Page 13: Specifications
TK210 GPS Car Alarm Website: http://www.GPScaralarm.com User Manual Eg: 111111WWW：COM：8500； ² APN:XXX; This is to set the APN (access point name). Please use “,” to separate the APN, APN username & APN password. Eg: 111111WWW：APN：web.gprs.mtnnigeria.net,web,gprs； ² RPT:XXX; This is to set the upload time interval. The unit is second, the value is between 15-999 seconds. - Page 14 TK210 GPS Car Alarm Website: http://www.GPScaralarm.com User Manual 98*64*25 Size of the main unit: (mm) Weight of the main unit: 0.1KG Working temperature: -20 ~ 80℃ Humidity: 0 ~ 95% GSM frequencies: Dual-band:900MHz/1800MHz (or Quad-band: 850MHz/900MHz/1800MHz/1900MHz) GPS chip: Latest SiRF-Star III chipset...
-
Page 15: Packing List
TK210 GPS Car Alarm Website: http://www.GPScaralarm.com User Manual antenna; (3) Chang another GPS antenna to test; (4) In cloudy condition, it is a little hard to get the GPS signal, and the GPS coordinate might have some errors. (1) Please setup the system firstly. (authorize I can check the location, but I SMS-received mobile number, etc);... -
Page 16: Installation
TK210 GPS Car Alarm Website: http://www.GPScaralarm.com User Manual VII. Installation Wiring Diagram Page 15... - Page 17 TK210 GPS Car Alarm Website: http://www.GPScaralarm.com User Manual Important Notice (1) Please read the manual carefully before installation and make sure you understand the installation wiring diagram and the car circuit & wiring firstly. We strongly advise you to ask professional car electricians to do the installation.
- Page 18 SIM card from the main unit, please power off the main unit firstly, otherwise, it might damage the unit. (3) The way to program the original remote to work with TK210: Connect green line & purple line of the 10-pins connector correctly ---->> Power on the unit --->>Keep the car door open --->>...
- Page 19 If you want to use the remote controls of the original central lock system (or car alarm system) to arm/disarm the TK210 tracker, the green line and purple lines MUST be connected correctly according to the wiring diagram. These 2 lines are used to detect the actual working status by central lock status, so that the tracker can be armed/disarmed correctly.
-
Page 20: Maintenance
TK210 GPS Car Alarm Website: http://www.GPScaralarm.com User Manual The gray line can also be connected to the positive pole of the direction lamp. ² Fix the power supply wire (Red line and black line) The tracker is specially designed for normal car which has +12VDC power supply. - Page 21 TK210 GPS Car Alarm Website: http://www.GPScaralarm.com User Manual ² Please keep the terminal in dry place. In case of soaking or leaking water, contact the local professionals. Do not start the car yourself, or we take no responsibility for any loss caused thereafter.
