- Page 1 USB VoIP Phone Adapter User’s Manual...
-
Page 2: Ce Mark Warning
FCC Certifications This Equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 and part 68 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 3 Trademarks: Skype, is registered trademark or trademark of Skype Technologies S.A in the U.S.A. and/ or other countries. IBM is registered trademark or trademark of IBM Corporation in the USA and/or other countries. Windows is either registered trademark or trademark of Microsoft Corporation in the U.S.A.
-
Page 4: Table Of Contents
KYPE CALL ............16 ALL A NORMAL PHONE CALL ............ 16 NCOMING CALL OTIFICATION ................18 KYPE THE USB VOIP PHONE ADAPTER UTILITY ......19 ..............20 ELECT ........ 21 ECORD LAYBACK FOR YOUR KYPE CCOUNTS TROUBLE SHOOTING GUIDE ..........23... -
Page 5: Unpacking Information
Unpacking Information Thank you for purchasing this USB VoIP Phone Adapter. Before getting start, please verify that your package contains the following items: 1. One USB VoIP Phone Adapter 2. One RJ-11 cable 3. One USB cable 4. User’s manual... -
Page 6: Introduction
Introduction The USB VoIP Phone Adapter is designed for users to process PC-based VoIP with regular phone, offering users to enjoy the cost-effective VoIP without changing the familiar dialing habit. With characters of user-friendly and high capability, the device integrates the regular (PSTN) and Skype VoIP phone calls, allowing users to receive both regular and Skype calls with the same phone. -
Page 7: Installation Guide
Installation Guide System requirement One IBM compatible computer equipped with CD-ROM drive and one available USB port. Windows 2000/XP operation system. Note: Skype is compatible with Windows 2000/XP only LED Definition Power: Green: Power on Off: Power off VoIP: Steady Amber: User is not talking via PSTN line. -
Page 8: Hardware Installation
Hardware installation 1. Connect your phone and the device with the RJ-11 cable we provide. Plug one end to your telephone, the other to the “Phone” connector on the device. Note: The device doesn’t support phones with Pulse mode. Please make sure that your phone is not configured as Pulse mode. - Page 9 Note: As usual, the PSTN line is the RJ-11 cable connecting to your phone for normal phone calls. Please connect the RJ-11 cables before connecting USB cable. 3. To link the device with your computer by the USB cable, connect one end to the device’s USB port and the other end to your PC.
-
Page 10: Driver Installation
Driver installation For telephonic standard varies from nations or regions, the product is manufactured with various versions to be compatible to your region. Please make sure that the device is corresponded to where you live. If you have any questions about the product version, please contact your retailer for more information. - Page 11 3. After the InstallShield Wizard preparing for installation automatically, click Next on the welcome screen 4. After specifying the username and the company name, you may choose to install the driver for everyone that use the PC or for yourself only.
- Page 12 5. Choose the destination folder for the driver and click next to start driver installation. You may click Browse to change the location. 6. After driver installation, click “Finish” to quit installShield Wizard and activate the device.
- Page 13 Note: 1. After installing the driver successfully, the driver will be activated automatically upon starting Windows and the icon will be shown on system tray in the bottom-right corner of your desktop. 2. If the driver fails to auto-start, please click Start Programs VoIP Phone Adapter Driver VoIP Phone Adapter Driver...
-
Page 14: Using The Usb Voip Phone Adapter
Please wait the program to set up automatically. If the dialogue window fails to auto-close, please select “Allow this program to use Skype” and click OK Note: Before doing any operation, please make sure that the icon... -
Page 15: Specify Audio Devices For Your Computer
Specify audio devices for your computer After installation, the VoIP phone adapter is configured as the default audio device for your computer. All audio signals will be played from your phone. Users have to specify the original audio device manually for playing music or multimedia. Users that don’t use the computer for other audio demand please skip to next paragraph Click Start Settings Control Panel, double click the... - Page 16 Start your Skype window. Click File Options Click the tab. Specify “ ” Hand/Headsets USB Audio Device in the drop list then click Save. Audio In Audio Out...
-
Page 17: Answer And Terminate A Skype Call
Answer and terminate a Skype call There are two ways to answer or terminate a Skype call, 1. By Skype button 2. By picking-up or hanging-up your phone Call a normal phone call To call a normal (PSTN) phone call, please refer to the following procedures: 1. - Page 18 Call a Skype Account Step 1. Setup the Skype Speed-Dial Key for your frequent-contacting accounts: 1. Right click on an account and select “Assign Speed-Dial” 2. Fill in a Skype speed-dial key from 00 to 99 and click OK...
-
Page 19: Skypeout
Skype speed-dial keys. SkypeOut Users that buy SkypeOut credits are allowed to call from Skype to friends that used PSTN or mobile phone. The procedures to SkypeOut via this phone adapter are as easy as calling a Skype contact: 1. -
Page 20: The Usb Voip Phone Adapter Utility
The USB VoIP Phone Adapter Utility After the driver being activated, users may click the icon activate the utility. The main menu of the utility shows as the following picture. This utility allows users to: 1. Select operation mode: a. Auto-detect VoIP and PSTN b. -
Page 21: Select Mode
Select Mode Auto: This mode allows the device to auto-switche between PSTN and VoIP phone calls. Users with both PSTN and VoIP connected to the device please select this mode. VoIP Only: The device is used to convert VoIP signals to your phone only. Users with only VoIP connected to the device please select this mode. -
Page 22: Record Playback For Your Skype Accounts
Record Playbacks for your Skype Accounts The device allows users to record a playback as an identifier for a Skype contact. The playback is going to be played from the phone and help you to figure out which contact that you are calling. - Page 23 3. Click Select on main menu to choose a playback for a specific speed-dial account. (ex, Click the Select button of item 2 to specify a playback for the Skype contact with speed-dial key “2” ) 4. Select a file you recorded and click Select to assign the...
-
Page 24: Trouble Shooting Guide
“VoIP Phone Adapter Driver” “VoIP Phone Adapter Driver” to start the driver. If the icon lights red, check if both the driver and your Skype are activated. ‧ Check if your PSTN line works. If your PSTN line doesn’t work... - Page 25 2. I disconnect the device and it seems fail to work. ‧ Please restart your Skype and try again. ‧ Please restart your computer if the system still fails to work. ‧ We recommend users not to remove any audio device that used for processing Skype without closing Skype first.
- Page 26 5. Does the device support call forwarding or call directing? ‧ No, this device doesn’t embed dialing function. All the dialing behaviors are performed by the telephone connected to the device. Call forwarding or directing needs auto-dialing mechanism, thus this device does not provide call forwarding or call directing functions.
-
Page 27: Product Specification
Product Specification Standard USB1.0 USB2.0 Interface 1x female USB Type A port 2X RJ-11 ports LED indicator Power: Green VoIP: Amber Power Input USB bus power compliant (5V/500mA) Operating - 40 C (32 - 104 Temperature Operating 10% ~ 90% (non-condensing) Humidity Emission FCC Part 15 Class B, FCC Part 68...
