Appendix A: wave types

Wave types1-128.
Analogue types:
Sine, Saw, Square, Triangle, Rez 1, Rez 2, Rez 3, HalfSine, SineSaw, SineSqr, SineRez, SawSqr, SawRez,
SqrRez, White Noise, Pink Noise.
Additive wave types:
Harmonic 1, Harmonic 2, Harmonic 3, Harmonic 4, Saw 2, Saw 3, Saw 4, Saw 5,
Sqr 2, Sqr 3, Sqr 4, Sqr 5, Triangle 2, Triangle 3, Glass, Hollow.
Octave, Overtone, Rez 4, Rez 5, Digix, Organ 1, Organ 2, Organ 3, Church Organ, Whistle, Vocal A, Vocal
E, Vocal O, Vocal U, Vox 01, Vox 02, Vox 03, Vox 04, Vox 05, Vox 06, Vox 07, Vox 08, Vox 09.
Spectral wave types:
Spectral 01 - Spectral 73.

Appendix B: LFOSync Settings

Off, 16/1*, 16/1, 16/1T, 8/1*, 8/1, 8/1T, 4/1*, 4/1, 4/1T, 2/1*, 2/1, 2/1T, 1/1*, 1/1, 1/1T, 1/2*, 1/2, 1/2T, 1/4*,
1/4, 1/4T, 1/8*, 1/8, 1/8T, 1/16*,1/16, 1/16T, 1/32*, 1/32, 1/32T.
Note: "T" stands for Triplet and "*" stands for a dotted note. In the case of a dotted note, the note duration is
equal to 1.5 times its original undotted value.

Appendix C: Delay Sync Settings

Off, 1/2, 1/2T, 1/4*, 1/4, 1/4T, 1/8*, 1/8, 1/8T, 1/16*,1/16, 1/16T, 1/32*, 1/32, 1/32T.
Note: "T" stands for Triplet and "*" stands for a dotted note. In the case of a dotted note, the note duration is
equal to 1.5 times its original undotted value.
