1.
This tow draw bar was designed to
mount into a 2" x 2" square hitch
receiver. NEvER use this product for
any purpose it was not designed for.
2.
Know your load and tongue weight!
NEvER exceed the gross load towing
capacity or the tongue weight capacity
of the hitch receiver or draw bar.
3.
When mounting the draw bar, only use
an approved hitch pin with a safety clip
properly installed through the hitch
receiver and draw bar.
4.
ALWAyS attach load-appropriate safe-
ty chains to the load and through the
hitch receiver chain loops.
5.
ALWAyS thoroughly inspect each com-
ponent of the towing assembly for
damage or any unsafe condition before
attaching a load. If you are in doubt
about the safe operation of any of these
towing devices, DO NOT use them.
6.
If you do not have experience towing
loads with your vehicle, WE STRONGLy
RECOMMEND that you read books or
get professional help before towing
any load. Grizzly will not be held liable
for accidents caused by lack of training
or failure to follow safe towing prac-
tices.
WARNING: NO pORTION Of ThIS MANUAL MAy BE REpRODUCED IN ANy ShApE
OR fORM WIThOUT ThE WRITTEN AppROvAL Of GRIzzLy INDUSTRIAL, INC.
Copyright © oCtoBEr, 2008 By grizzly industrial, inC.
#ts11147 printEd in China
MODEL G8731/G8732/
G8733
TOW DRAW BAR
INSTRUCTIONS
Ball hitch
Mounting
hole
tongue
figure 1. Model g8731/g8732/g8733
identification (shown in "lower" position).
Specifications
Maximum load towing Capacity ......... 5000 lbs.
Maximum tongue Weight Capacity ........ 500 lbs.
required hitch receiver size ...... square 2" x 2"
required hitch pin ....
distance Between Center of hitch receiver shaft
& tongue:
— Model g8731 ......................................... 2"
— Model g8732 ........................................ 4"
— Model g8733 ........................................ 6"
Ball hitch Mounting hole diameter .................. 1"
hitch receiver Construction .................
tongue Construction ............... Welded
Weight:
— Model g8731 ....................................7 lbs.
— Model g8732 ...................................9 lbs.
— Model g8733 ..............................13.5 lbs.
hitch receiver shaft
hitch pin hole
⁄
" diameter w/safety Clip
5
8
⁄
3
16
⁄
3
4
" steel
" steel
