Summary of Contents for abi IQ E-Tablet
-
Page 1: User Manual
IQ E-Tablet User Manual (Adapted for E001, E002, E003) Copyright(C) 2003-2007 A Brighter Image Pty Ltd. Website: www.iqboard.com.au or www.abimage.com.au Tel: 02.9938 6866 Fax: 02.9938 6899 E-mail: info@www.iqboard.com.au... -
Page 2: Important Statements
Important Statements: 1. Use this product strictly according to the detailed operation instruction in this User Manual to ensure proper use. Please read the instruction thoroughly to save installation time. 2. I f this product is defective, please return it to the appointed agent or our company, together with your original sales receipt or invoice for replacement. - Page 3 A Brighter Image, ABI, Returnstar and Recoverystar are the registered trademarks or company names. Any modification of Copyright marks, product names and brand names of this product and its copies is strictly prohibited.
-
Page 4: Chapter 1 Product Introduction
USB line or wireless Bluetooth (special for wireless type). Fixed on flat screen (such as LCD or laptop), the IQ E-Tablet can transform a normal computer screen into a flat panel computer. When used on paper or plastic hard surface, it can save the writing as an original document, electronically sign any text file, or create an electronic image using free drawing or tracing. -
Page 5: Chapter 2 Function Features
Working with IQ whiteboard software, direct writing and various teaching and demonstration effects can be achieved. In this way, the IQ E-Tablet can transform a normal computer to a Tablet PC or a electronic interactive whiteboard. - Page 6 Its capability of pre-lesson preparation, saving new lessons or presentations, saving changes to lessons and standard MS files makes the IQ E-Tablet and software a powerful teaching and presentation tool. The abundant and powerful resource library included in the software makes it easy for the preparation of lessons and presentations to improve the overall learning effect.
- Page 7 2.2.6 Two of the IQ E-Tablet models can be used offline. Without connecting to a computer, it can save text and drawings written on normal paper into the receiver, with storage capacity of more than 100 pages. The writing content also can be saved in different documents and pages.
-
Page 8: Chapter 3 Specification And Parameter
Chapter 3 Specification and Parameter 3.1 Product Specification Model 1-E001 1-E002 1-E003 Type Standard Storage Wireless PC connection Wireless Bluetooth/ USB None 100 pages (A4 size) 100 pages (A4 size) Storage Capacity 3.2 Standard Configuration: 1 receiver, 1 digital pen (including battery), 2 plastic pen cores, 2 ball pen refills, 1 pen refill clamp, 1 USB cable, 1 wireless adapter (special for wireless type), 1 set of screen companion (receiver screen clamp), 1 installation CD, 1 user manual, 1 carry bag. - Page 9 3.5 System Requirement: CPU: Based on X86 CPU pentium166 or above Memory: 64 MB RAM (recommend 128 MB RAM) Hard Disk: 30 MB free space USB Port: at least one available USB port Projector: any brand, model or resolution Projection media: Paper material or other material, flat screen (LCD or laptop). 3.6 Storage and Operating Specifications: Storage: Temperature:-40 degrees to 60 degrees...
-
Page 10: Chapter 4 Hardware Installation And Instruction
5. Power switch: Controls the power of the signal Dimension 175mm x 25mm x 20mm receiver. Charging < 3 hours time Note: IQ E-Tablet Standard type doesn’t have Continuous 8 hours power switch 6. USB port: Connects signal receiver and offline computer. - Page 11 Note: The signal receiver will be charged if being connected with computer. 4.1.4 USB wireless adapter (Only for IQ E-Tablet Wireless type) Function Plug the USB wireless adaptor in the USB port of the computer, the signal receiver and computer can be...
- Page 12 4.1.5 Screen companion Function Fix the signal receiver on the computer screen. 1. Screen clamp (small): Fix the signal receiver on the top centre, left centre, or right centre of the computer screen. Note: this clamp suits a computer screen with narrow frame.
- Page 13 3. When replacing the pen core, twisting the pen core a bit will make the process easier. 4. The pen core used for digital pen is available in supermarket and stationary store, or from ABI. 4.2.3 When using the digital pen, please pay attention that: 1.
- Page 14 The power source of receiver is normal. Slowly flash (3 seconds) Charging the receiver battery. Normally on Successfully saved page when used offline. Green light and red light both flash 3 times. Receiving the signal normally The storage capacity is fully occupied when Normally on recording.
-
Page 15: Chapter 5 Install And Uninstall Driver And Orientation Programs
Chapter 5 Install and uninstall driver and orientation programs 5.1 Install: When you first use IQ E-Tablet, you must install the driver and orientation program. Put the enclosed small CD in your CD-ROM, double click “Setup.exe” in the CD and install according to the prompt. -
Page 16: Chapter 6 Operations
Autorun Setting: you can decide whether to run IQ E-Tablet automatically when starting the computer. Click “Autorun Setting” and enter the setting window (as follows). If you select “Autorun Notes Genius when the system starts”, IQ E-Tablet will be automatically started every time you start your computer. Otherwise, you have to start IQ E-Tablet manually. - Page 17 Clear all files in receiver: Clear all Electronic Noting files saved in receiver. Prompt: Refer to “6.2.2 Electronic Noting” for detailed operation steps. About: Click “About” to popup the information window of IQ E-Tablet, as follows Exit: Click “Exit” to quit IQ E-Tablet 6.1.2 Install signal receiver...
- Page 18 Step 2. Insert the pin of the connector into the screen clamp (big). The side with double sided tape on the screen clamp should be downward, as follows: Step 3. Tear out the protection layer of the double sided tape, then stick the screen clamp on the center of the screen upper frame, as follows: Installation of the screen clamp (small) Step 1.
- Page 19 Step 2. turn over the signal receiver to the receiving face, and turn up the pin, make it vertical to the signal receiver, as follows: Step 3. Insert the pin of the connector into the screen clamp (small), then the signal receiver and the connector will be joined, as follows: Step 4.
- Page 20 After you move the digital pen away, the green indicator will turn off. Caution: 1. All types of IQ E-Tablet (Standard, Storage, and Wireless) can use USB cable to connect the signal receiver and computer. 2. When using USB cable for connection, it doesn’t matter whether the power switch on the back of receiver is at “ON”...
- Page 21 6.1.4 Screen Orientation (Calibration): When you fix the signal receiver on the computer screen and intend to write on the screen, you need to orient the IQ E-Tablet in order to make it work accurately. Once oriented, the moving track of digital pen will match the cursor, and you don’t need to re-orient using the same environment.
- Page 22 After you finish the orientation, you can use the digital pen for Screen Writing. 6.2 Electronic Noting Prompt: Only IQ E-Tablet Storage and Wireless types have Electronic Noting function; the Standard type does not include this function. 6.2.1 Fix signal receiver: As the above picture, clamp the signal receiver on the top center of the A4 paper or folder;...
- Page 23 Caution: 1. If you want to switch IQ E-Tablet Wireless type to Electronic Noting mode, you must first use digital pen to click B Zone, and release after half a second. If the greed indicator flashes six times rapidly, it means the receiver has been switched into Electronic Noting mode. If you haven’t clicked the B Zone, the receiver will be under “Wireless connecting”...
- Page 24 Caution: 1. For IQ E-Tablet Wireless type, please unplug the wireless adapter before reading the file saved in the receiver. 2. When you want to read files from the receiver, please start Returnstar Whiteboard Software first, or the system will prompt an error message.
-
Page 25: Chapter 7: Warnings
4. During the writing process, there should be no obstacle between the digital pen and signal receiver. 5. Promptly replace the button cell and pen core when they run out. 6. Do not use the IQ E-Tablet in places having severe electromagnetic interference. 7. Avoid dropping the receiver and digital pen. -
Page 26: Chapter 8 Faqs
The relevant application is not Install the application. installed. The indicator is not lighting, but the Please contact the dealer or ABI operation is normal. service center The signal emitter on digital pen Please contact... - Page 27 Imprecise orientation or the signal Re-orient or install the signal of the digital pen receiver is not well installed. receiver again. does not correspond to the track of the cursor. For any technical enquiries or problems, contact ABI on 02.9938 6866.
