Dongyang Unitech DNC User Manual

Dnc (dmax network camera)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DNC(Dmax Network Camera) User's Manual Part1
DNC(Dmax Network Camera) User's Manual
Part 1
(Product Overview)
Version 4.0
Dongyang Unitech Co., Ltd
www.d-max.co.kr
www.cctvhome.net
１
DNC
Dongyang Unitech Co., Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DNC and is the answer not in the manual?

Questions and answers

Related Manuals for Dongyang Unitech DNC

Summary of Contents for Dongyang Unitech DNC

  • Page 1 DNC(Dmax Network Camera) User's Manual Part1 DNC(Dmax Network Camera) User’s Manual Part 1 (Product Overview) Version 4.0 Dongyang Unitech Co., Ltd www.d-max.co.kr www.cctvhome.net １ Dongyang Unitech Co., Ltd...

  • Page 2: Table Of Contents

    1.4. DNC IP Camera Packing List ......................７ Hardware Description ......................... ８ 2.1. DNC IP Camera ..........................８ DNC IP Camera HW installation and basic setup ................８ 3.1. Before installation ........................... ８ 3.2. Factory Default Condition ....................... ８ 3.3.

  • Page 3: Product Overview

    1.1. DNC IP Camera DNC® IP Camera is a standalone network camera that has a built-in PTZ Analog Camera and is capable of transmitting the video over the IP Network. IP Camera has built-in web server, so it can transmit the video at the rate of up to 30fps (NTSC@4CIF) over the network such as LAN, leased line, DSL or Cable modem.

  • Page 4: Key Features

    DNC(Dmax Network Camera) User's Manual Part1 1.2. Key Features • Standalone device with built-in web server • 10/100Base-T Auto-Sensing Ethernet • Configuring and controlling through Web browser • Up to 30 fps transmission rate on TCP/IP network • Effective Bandwidth & Bit-rate Control (VBR/CBR) by H.264 •...

  • Page 5: Technical Specification Of Dnc Ip Camera

    DNC(Dmax Network Camera) User's Manual Part1 1.3. Technical Specification of DNC IP Camera 32bit Embedded CPU Flash 8Mbytes / SDRAM: 128Mbytes Hardware Linux version 2.6.xx operating system Battery backed-up real-time clock 1/4”Sony 410K Super HAD CCD Resolution: 520 TV Lines...
  • Page 6 DNC(Dmax Network Camera) User's Manual Part1 Input Impedance : 4 KΩ Phantom Power : 5 Volt Audio Input (MIC) Gain : 20 dB Jack : 3.5mm Mono Output Impedance : 160 Ω Output Power : 50 mW Audio Output (SPK) Output Voltage : 1 Volt (peak-to--peak) Jack : 3.5mm Stereo...

  • Page 7: Dnc Ip Camera Packing List

    DNC(Dmax Network Camera) User's Manual Part1 Powerful API for software integration available at http://www.d- max.co.kr, including Simple Viewer API, DNC Control SDK, event trigger data in video stream, embedded scripting and access to System Integration serial port peripherals over HTTP/TCP...

  • Page 8: Hardware Description

    DNC(Dmax Network Camera) User's Manual Part1 2. Hardware Description 2.1. DNC IP Camera Picture 2. DNC IP Camera with Wall Mount Bracket 3. DNC IP Camera HW installation and basic setup 3.1. Before installation • Read User's Manual carefully • Check User’s Network (IP Address, Network Mask and default gateway) •...

  • Page 9: Hardware Installation

    DNC(Dmax Network Camera) User's Manual Part1 3.3. Hardware installation Following pictures show the installation steps for DNC IP Camera. Next, you need to follow the steps below. 1. Network Configuration on IP-installer. 2. Camera Configuration on IP-installer or admin-menu. 3. Service Configuration on IP-installer or admin-menu.
  • Page 10 DNC(Dmax Network Camera) User Manual Part 2 DNC(Dmax Network Camera) User Manual Part 2 (Network Configuration and DNC Setting) Version 4.03 July 15, 2009 Dongyang Unitech Co., Ltd www.d-max.co.kr www.cctvhome.net Dongyang Unitech Co., Ltd...
  • Page 11 DNC(Dmax Network Camera) User Manual Part 2 TABLE Network Configuration ...................... 6 1.1. Private Network ......................6 1.2. Leased Line Network ....................6 1.3. Cable/xDSL Modem Network with Static IP ............. 7 1.4. Cable/xDSL Modem Network with Dynamic IP ............7 1.5.
  • Page 12 DNC(Dmax Network Camera) User Manual Part 2 2.4.3. RS232 Console Cable ..................27 2.4.4. Confirmation of setup & Access to Home Page ..........28 2.5. Automatic installation with UPnP ................29 2.5.1. Indication of installation status with Status LED ..........29 2.5.2.
  • Page 13 Figure 11 IP Installer Menu ..................... 14 Figure 12 Connection through a HUB ..................15 Figure 13 Connection DNC to PC ................... 15 Figure 14 In case of selecting 1 server for Static IP Assignment ........... 16 Figure 15 In case of selecting 2 or more servers for Static IP Assignment ......17 Figure 16 In case of selecting 1 server for Automatic Static IP Assignment ......
  • Page 14 Figure 24 RS232 Cross Cable ....................27 Figure 25 RS232 Converter Cable ..................28 Figure 26 Main page of DNC ....................36 Figure 27 Screen of DNC Live View ..................37 Figure 28 Player ........................38 Figure 29 Sample ........................39...

  • Page 15: Network Configuration

    Figure 1 Private Network Diagram 1.2. Leased Line Network In case of leased line, most users use Public static IP, they assign public static IP to DNC server and they can view the images from DNC locally or remotely via Internet.

  • Page 16: Cable/Xdsl Modem Network With Static Ip

    Figure 3 ADSL/Cable Modem (Static IP) Diagram 1.4. Cable/xDSL Modem Network with Dynamic IP You can use Dynamic IP through cable/xDSL modem to view the images from DNC. In this case, you need to register for AOIP service provided by Dongyang Unitech.

  • Page 17: Pstn Modem With Dial-Out

    1.5. PSTN Modem with Dial-out You can use PSTN modem to have DNC server connected to the Internet. DNC makes a call to ISP (Dial-out) and gets connected to the Internet. In this case, the assigned IP by ISP is Public Dynamic IP.

  • Page 18: Network Configuration

    2. Network Configuration The very first thing you need to do for using DNC is proper IP assignment for your DNC servers. After this, you can go on to the next steps. There are two methods can be used. The first method is to use DNC Installer included in CD and the other method is to use terminal emulation program (ex.

  • Page 19: Installation Of Ip Installer

    DNC(Dmax Network Camera) User Manual Part 2 2.1.2. Installation of IP Installer Please double click on the IP Installer Icon. Click Next. Please Check the version of IP Installer and if you want to install it, please click Next. Figure 7 IP Installer First Installation Screen Select the installation location, please click Install.

  • Page 20: Figure 8 Ip Installer Folder Selection

    DNC(Dmax Network Camera) User Manual Part 2 Figure 8 IP Installer Folder Selection Click Finish (Installation Completion) All the required files will be installed and the installation will be done by clicking Finish. If users don’t want to use IP Installer anymore, delete the file, referring to the next chapter, ‘Deleting IP Installer’...

  • Page 21: How To Use Ip Installer

    DNC(Dmax Network Camera) User Manual Part 2 Figure 9 IP Installer Installation Completion 2.2. How to Use IP Installer 2.2.1. How to Run IP Installer To run IP Installer, please double-click IP Installer icon in desktop screen or click the icon located in Programs shown as below.

  • Page 22: Program Menu Description

    2.2.2. Program Menu Description Figure 11 IP Installer’s main screen Menu Description Search and show the list of DNC Linux series installed in the same Search Product LAN of your PC. Clear Product list Clear all the list of DNC products IP Installer will check the network information and you can set up IP automatically.

  • Page 23: Right Mouse Button Menu

    Found * For second try, ‘Found’ means the number of devices available for searching normally. Shows the total number of DNC servers with no response on search again. Timeout * For second try, ‘Timeout’ means the number of normally ‘not- responding’...

  • Page 24: Ip Assignment

    DNC(Dmax Network Camera) User Manual Part 2 2.3. IP Assignment There are three different ways of IP setup for the network connection of your DNC server. Static IP Assignment General IP assignment method, to setup public or private static IP address.

  • Page 25: Static Ip Assignment

    There are two types of static IP including public IP or private IP in LAN with an IP sharer or a router. Please run IP Installer, and search to see available DNC servers on the list. Then, please select the server from the list and click on IP Setup button or IP Setup from the right mouse button menu.

  • Page 26: Figure 15 In Case Of Selecting 2 Or More Servers For Static Ip Assignment

    KT uses ‘’168.126.63.1’ and Drunet uses ‘210.117.65.1’. HTTP Port Default web port for DNC. Default value is 80. Password for DNC server to authenticate a valid user. The default Root password password for DNC is root. Save Configuration Option It makes set items save.
  • Page 27 Cancel window. After IP configuration, click “Connect” icon to access DNC. See live view of DNC or specify system configuration on admin menu. Please refer to chapter 3.2 Live View and “User Manual for DNC” for more details of system configuration and live view.

  • Page 28: Ip Assignment Through Dhcp

    Set up systems either by looking at videos of DNC or using Admin Menu. To know ‘looking at videos’, refer to ‘2.6. How to see DNC video’ and to know how to set up systems, refer to DNC user manual.

  • Page 29: Figure 17 In Case Of Selecting 1 Server For Dhcp Ip Assignment

    Server Name Assign a name to selected DNC HTTP Port Default web port for DNC. Default value is 80. Password for DNC server to authenticate a valid user. The default Root password password for DNC is root. Save Configuration Option Menu to save set items.

  • Page 30: Ip Assignment By Pppoe

    Local Network. 2.3.4. IP Assignment by PPPoE Assign static IP of DNC in same the class with PC. Or it’s easy to setup IP assignment in reference to ‘2.2. How to use IP Installer’. After IP setup, check out if you can access to the homepage of DNC server by clicking “Connect”...

  • Page 31: Figure 19 In Case Of Selecting 1 Server For Pppoe Ip Assignment

    PPPoE User Name Enter PPPoE ID PPPoE Password Enter PPPoE Password PPPoE Confirm Enter PPPoE Confirmed Password Password for DNC server to authenticate a valid user. The default Password password for DNC is root. Save Configuration Option Save set items. Save Configuration All the changes will be stored in Flash Memory.

  • Page 32: Network Configuration Through Hyper Terminal Mode

    You can continue below configuration after Network setting, and the next process will be same as using Installation Wizard Program. 2.4.1. Hyper Terminal Installation Wizard Program Link up with the provided serial cable between COM port at DNC server and COM1 or COM2 at user’s PC. Run Hyper Terminal Program on user’s PC.

  • Page 33: Figure 21 Com Port Connection Description

    DNC(Dmax Network Camera) User Manual Part 2 Figure 21 COM Port Connection Description Select the connected COM port with serial cable and press OK button. Figure 22 COM Port Connect To Information When ‘Port Settings’ window shows up, input each values from the table below.

  • Page 34: System Login And Network Configuration By Hyper Terminal

    DNC(Dmax Network Camera) User Manual Part 2 Figure 23 COM Port Settings Serial Port Settings Value Bits per Second 115200 Data bits Parity None Stop bits Flow control None 2.4.2. System Login and Network Configuration by Hyper Terminal After setting Hyper Terminal, press Enter key several times and then you can see messages below.
  • Page 35 DNC(Dmax Network Camera) User Manual Part 2 ‘Input ‘netconfig eth1 IP, SubnetMask, Gateway’, and press Enter key as below. e.g.) bash# netconfig eth1 192.168.0.253 255.255.255.0 192.168.0.1 bash# netconfig eth0 192.168.0.253 255.255.255.0 192.168.0.1 Your network configuration was changed. Shutting down interface ppp2 [ OK ]...

  • Page 36: Rs232 Console Cable

    Cable used for RS232 Console Cable can be made with a combination of RS232 Cross Cable and RS232 Converter Cable 2.4.3.1. RS232 Cross Cable RS232 Console Cable is DNC’s Console Cable made of DB9 Connector, it can be used properly. Figure 24 RS232 Cross Cable 2.4.3.2.

  • Page 37: Confirmation Of Setup & Access To Home Page

    Figure 25 RS232 Converter Cable In connection to Modem, RS232 Converter Cable can be linked to Modem Cable. 2.4.4. Confirmation of setup & Access to Home Page Open Internet Explorer, type IP address to access to DNC. Dongyang Unitech Co., Ltd...

  • Page 38: Automatic Installation With Upnp

    UPnP function of DNC is for providing easy installation environment for users by executing port mapping after searching for router to support UPnP. Users can configure network so that access to DNC would be possible without port mapping of router, IP installed can be used liking to (Always On IP) Service.

  • Page 39: Upnp Admin

    DNC(Dmax Network Camera) User Manual Part 2 2.5.2. UPnP Admin Page setup Port mapping -> UPnP Auto Selected Port Router to support UPnP function executes port mapping automatically by request, result is displayed in UPnP status. External Port number is automatically assigned.
  • Page 40 This function is ‘Enable’ as default in Windows Vista. IP class of PC should correspond to that of DNC. Windows setting in Windows XP is needed although DNC is displayed in ‘My Network Places’. DNC is not shown in other applications not Windows VISTA, Windows XP.

  • Page 41: Setup Following Network Configuration

    So users can use this when users want to proceed with the all the operation tests without waiting for the time needed. 2.5.3. Setup following network configuration 2.5.3.1. When IP sharer to support UPnP Port mapping is installed in DNC and registration to AOIP server is needed UPnP Port mapping : UPnP-Auto or UPnP-User Assigned AOIP Setting: Enable.
  • Page 42 DNC(Dmax Network Camera) User Manual Part 2 2.5.3.4. When IP sharer not to support UPnP Port mapping is installed in DNC and users want to register DNC to AOIP server by manually do port mapping in sharer. UPnP Port mapping : Manual Assigned (Port : NAT Port assigned by users) AOIP Setting: Enable.
  • Page 43 DNC(Dmax Network Camera) User Manual Part 2 2.5.3.7. When DNC is accessible to Internet directly and registration of DNC to AOIP server is not needed UPnP Port mapping : Manual Assigned (Port : Default Web Port) AOIP Setting: Disable. 2.5.3.8. DNC is installed in local network, registration of AOIP server is needed M.
  • Page 44 DNC(Dmax Network Camera) User Manual Part 2 2.5.3.9. DNC is installed in local network, registration of AOIP server is not needed O. UPnP Port mapping : Manual Assigned (Port : Default Web Port) AOIP Setting: Disable. Dongyang Unitech Co., Ltd...

  • Page 45: Home" Screen Server Through The Web Browser On The Pc Shown As Below

    DNC(Dmax Network Camera) User Manual Part 2 2.6. “Home” screen server through the web browser on the PC shown as below. Figure 26 Main page of DNC 2.7. “Live View” Menu Once users click ‘Live View’ in the upper right, SW “Smart Viewer” is installed automatically (or manually) in PC, then real-time video of server is displayed.

  • Page 46: Figure 27 Screen Of Dnc Live View

    DNC(Dmax Network Camera) User Manual Part 2 Figure 27 Screen of DNC Live View Dongyang Unitech Co., Ltd...

  • Page 47: Player" Menu (Nvr Only)

    DNC(Dmax Network Camera) User Manual Part 2 2.8. “Player” Menu (NVR only) Figure 28 Player This menu is for searching for videos recorded, SW “Smart Player” is installed automatically (or manually) and users can search for videos by the condition in need after accessing to NVR.

  • Page 48: Admin" Menu

    Figure 29 Sample 2.10. “Admin” Menu This menu is the administration menu for a user to manage all the functions of DNC and you need the administrator ID and Password for this menu. Factory default Admin ID is “root” and Password is “root” and you can change the Password in Admin Menu.
  • Page 49 DNC(Dmax Network Camera) User’s Manual Part 3 DNC(Dongyang Network Camera) User’s Manual Part 3 (Admin Menu) Version 4.06 December 10, 2009 Dongyang Unitech Co., Ltd www.d-max.co.kr www.cctvhome.net Dongyang Unitech Co., Ltd...
  • Page 50 DNC(Dmax Network Camera) User’s Manual Part 3 Index Admin Menu.......................... 4 1.1. Entering Admin Menu ....................4 1.2. Admin Menu Structure ....................5 Quick Configuration ......................6 2.1. Step 1: Changing Server Name ..................6 2.2. Step 2: Time Setup ....................... 7 2.3.
  • Page 51 DNC(Dmax Network Camera) User’s Manual Part 3 5.1.2. Serial Output Mode ..................... 32 5.1.3. Transparent Mode ....................32 5.1.4. PTZ Mode ......................33 5.1.5. PTZ Mode ......................35 5.2. Camera & Motion ......................42 5.2.1. Camera & Motion ....................43 Camera Configuration ......................

  • Page 52: Admin Menu

    1. Admin Menu Admin Menu is where you can set up the most of features in DNC Servers. User ID and password for administrator are required to log in. The factory default is root for both ID and password. Once logged in, you can change the password to a new one.
  • Page 53 DNC(Dmax Network Camera) User’s Manual Part 3 1.2. Admin Menu Structure Category Main Menu Level 1 Sub-Menu Level 2 Sub-Menu Step 1 Step 2 Step 3 Quick configuration Step 4 Step 5 Step 6 Finish Server Name Setup Date & Time Admin.

  • Page 54: Quick Configuration

    2. Quick Configuration 2.1. Step 1: Changing Server Name In step 1, you can find out the system information as model number of the DNC Server, server name, MAC address (serial number), firmware version, and webimage version. As an administrator, you can change the name of the server name here, but other values are not allowed to change.
  • Page 55 If you only changed Date and Time setting, you simply click Apply button to take it into effect immediately. If you want to retrieve the exact current time from NTP server on the network, click Get NTP Server Time button. Clicking Refresh button will display the date and time retrieved from DNC® Server. Dongyang Unitech Co., Ltd...
  • Page 56 DHCP Client: In this case, ISP or network gateway is running a DHCP server. Most of ISP services such as cable modem or DSL are providing this type of service. DNC server needs to be configured to be DHCP Client so that it can be assigned a dynamic IP address.
  • Page 57 2.3.2. DHCP Client Configuration The default network type is set to DHCP Client and default DNS is set to KT DNS in DNC Servers. Selecting DHCP Client on the Network Configuration will show the window shown below. Click Apply button to save the setting. Otherwise, click Back button.
  • Page 58 2.5. Finish You need to save all the changes to the Flash Memory after finishing the configuration. The changes made to DNC Server will be permanent by this step. Click Finish on Quick Configuration menu. Click Save Configuration button. This will write the new settings to the system’s flash memory. If you don’t want to save them, click Back button.

  • Page 59: System Configuration Menu

    3. System Configuration Menu 3.1. Server Name Setup You can find the system information such as the model number of DNC Server, server name, MAC address (serial number), firmware version, and webimage version. As an administrator, you can change the name of the server name here, but other values are not allowed to be changed.
  • Page 60 DNC(Dmax Network Camera) User’s Manual Part 3 After entering the new server name, click Apply button to save the setting. In this case, the new server name takes effect immediately. 3.2. Date & Time Click Date & Time on System Configuration menu. Local Date & Time Configuration window will be displayed.
  • Page 61 If you want to retrieve the exact current time from NTP server over the network, click Get NTP server time button. Clicking Refresh button will display the date and time from DNC® Server. In order to retrieve Time and Date information from a NTP server, you need to put NTP server address in advance, such as pool.ntp.org.
  • Page 62 Click Apply button to put it into effect. Because you have replaced the password with a new one, the existing network connection made with old password to DNC Server is lost now. In this case, you have to reconnect to the DNC server using new password.
  • Page 63 DNC(Dmax Network Camera) User’s Manual Part 3 3.5. User Registration You can add, modify, or delete users for your DNC® Server in User Registration. Once registered as Limited Access setting, the user can access the DNC Server with limited privileges.
  • Page 64 DNC(Dmax Network Camera) User’s Manual Part 3 DNC Server can have multiple VS modules registered in it. When user ticks on any Enable of Enable checkboxes, other fields in that row are enabled to select. The registered user can select VS Modules that are available.
  • Page 65 NVR (Network Video Recorder) as remote server devices. Click IP Devices Registration on System Configuration menu. Select one of the VS Module ID (IP Devices) from the list to add as a remote server. DNC Server supports vendors such as Axis, Panasonic, Vivotek and more than 10 others as well as DNC products.
  • Page 66 DNC(Dmax Network Camera) User’s Manual Part 3 Each IP NVR model has different number of supported channels which can be added. FW-5050: Up to 8 channels including other vendor’s model (3M pixel supported) FW-5071: Up to 16 channels including other vendor’s model (3M pixel supported) FW-5450: Up to 16 channels including other vendor’s model and analog (D1 supported)
  • Page 67 DNC(Dmax Network Camera) User’s Manual Part 3 Select the number of channels to add. Now enter the name of the server, IP Address, VS Module ID (for DNC only), Server Port, Login ID/Password Dongyang Unitech Co., Ltd...
  • Page 68 Name of the server to add IP Address IP Address of the server to add VS Module ID Applicable to DNC only. Enter 0 for other vendor’s models. Service Port Web port number of the server Login ID / Password...
  • Page 69 DHCP Client: In this case, ISP or network gateway is running a DHCP server. Most of ISP services such as cable modem or DSL are providing this type of service. DNC server needs to be configured to be DHCP Client so that it can be assigned a dynamic IP address.
  • Page 70 4.2.1. HTTP Port This is the network port that is used when a Client PC connects to the DNC® Server’s Web page. It can be assigned between 80 and 65535 and the default value is 80. If the HTTP port number is changed to other value than default (80), make sure the new HTTP port number goes together with the DNC Server's Internet address.
  • Page 71 4.4. Bandwidth Control Configuration With this feature, you can set the maximum network traffic on DNC® Server. If there occurs more network traffic than you set up here, DNC® server randomly drops any of the data packets to limit the total bandwidth.
  • Page 72 4.5. View Network Status You can see the status of the DNC® Server with this feature. Click Refresh button to reload the updated information from the server.
  • Page 73 In Sender field, enter your email address or other meaningful words that will show the message was sent from the DNC server as a notification. Now enter the email addresses of the recipients in the three Recipient fields, up to 3 persons. In the User-Defined Message box, you may want to put the message to explain why the message was sent.
  • Page 74 CCTVHOME DNS™ (http://www.cctvhome.net), and register the MAC address and the product-Key of your DNC® Server. To set up the usage of CCTVHOME DNS™ in the DNC® Server, click CCTVHOME DNS™ on Network Configuration menu. Select Enable on Service field, then enter the address of CCTVHOME DNS™ Server that your DNC server is registered in.
  • Page 75 Configuration. Click Confirm button to check if your server is successfully registered in CCTVHOME DNS™. You will find the URL address of your DNC server. 4.8. Port Forwarding & UPnP UPnP (Universal Plug and Play) is a set of network protocols that enables discovering and configuring local devices automatically.
  • Page 76 RTSP (Real-Time Streaming Protocol) is a protocol to transfer video and audio stream over the network. Any application supporting Standard RTSP can be used for DNC server. Quick Time Player or VLC program can be used for this, but it may not be supported in the environment within firewall. There are two types of usage, one for Unicast address condition and the other for Multicast address condition.
  • Page 77 DNC(Dmax Network Camera) User’s Manual Part 3 Address for multicast video transfer Multicast Address The multicast address 0.0.0.0 is for stopping multicast. Multicast Port Port number for viewing the video with a multicast address Dongyang Unitech Co., Ltd...

  • Page 78: Device Configuration

    DNC(Dmax Network Camera) User’s Manual Part 3 5. Device Configuration You set up the connection between DNC® Server and the camera in this part of configuration. That includes Video data, external devices, Input / Output, Alarm control, and etc. 5.1. Serial Ports There are two serial ports configurable in the system, COM and AUX.
  • Page 79 DNC(Dmax Network Camera) User’s Manual Part 3 • Current Port: This shows the name of the port currently configured. • Current Protocol: This shows the protocol being used. (only RS-232 can be displayed) • Serial Input Model: You can select the sensor’s model number to use for Serial Input The following example is when a speed sensor, AGILIS-HE820-SINGAPORE, is selected.
  • Page 80 5.1.3. Transparent Mode When there are two DNC Servers present on the network, they can act like a transparent interface between two different UART devices so that the communication between the UART devices can be made transparently without a flaw.
  • Page 81 5.1.4. PTZ Mode With the PTZ camera’s RS-485 cable wired to DNC® Server’s COM or AUX port, select the proper PTZ model in PTZ Mode Configuration screen, then click Apply button to save the change. Before purchasing receivers or PTZ cameras, please contact Dongyang Unitech or distributor to find out if the product’s protocol is supported by DNC server.
  • Page 82 DNC(Dmax Network Camera) User’s Manual Part 3 American Dynamics : DELTA DOME Pelco-D-AUX : HUVIRON KALATEL : CYBER DOME(KTA-xxxx) Pelco-P-AUX : ONE KING Panasonic : WV-CS854 Pelco-D-AUX : Probe SONY : EVI-D30 Honeywell : HSDN-P 251(H) CANON : VC-C4 After selecting the proper PTZ model, click Module 0 to activate the camera channel.
  • Page 83 5.1.5. PTZ Mode These DNC Servers are Speed Dome models, which are all-in-one type network cameras and don’t have PTZ configuration part. It’s possible to set Preset, Swing, Group, and Tour functionalities in those servers and further detailed parts can be configured by use of OSD. Below is the steps for configuration.
  • Page 84 DNC(Dmax Network Camera) User’s Manual Part 3 Enter the Preset names as required. You can make up to 32 Preset names. Below is the example of entering 4 different room names. Use the buttons to configure Preset, OSD, Swing, Group, and Tour. (Swing, Group, and Tour) Dongyang Unitech Co., Ltd...
  • Page 85 DNC(Dmax Network Camera) User’s Manual Part 3 • Preset & Menu: You can pre-define the spot you want to see. Up to 32 settings can be stored. Click Menu button to configure the camera’s attributes. • Swing: Repeat moving between two positions in certain period.
  • Page 86 DNC(Dmax Network Camera) User’s Manual Part 3 setting can be made by Up, Down, Left, Right arrow keys. After setting is finished, click Menu button. Group Set Click the button and it will display the Group setting window as shown below. Select a group number as you’d like, and click Start Set button.
  • Page 87 DNC(Dmax Network Camera) User’s Manual Part 3 After Preset is configured, click Save Set button. Group setup window will be displayed. You can configure up to 6 groups. The usage of Group can be controlled at PTZ Control window in Smart Viewer.
  • Page 88 DNC(Dmax Network Camera) User’s Manual Part 3 Swing Set Click the button and it will display the Swing Set window. Use PTZ to direct the camera to put the desired spot on the center of the camera viewing area, then click Set Start Position button.
  • Page 89 DNC(Dmax Network Camera) User’s Manual Part 3 Select the moving speed between the starting position and the ending position, then click Speed button. Click Confirm button. Dongyang Unitech Co., Ltd...
  • Page 90 You are to configure what data will be combined with video data, and set up specific operating environment for each channel. (A Channel means a camera which is directly wired to DNC® Server Cameras or remotely connected over the network)
  • Page 91 Click Device Camera & Motion on Device Configuration menu. Configure the video data format and other information to be contained in it. • Default Video Format: Video transmitting format of the camera attached to DNC Server. Select from NTSC or PAL. •...
  • Page 92 With DNC server, you can set the number of P-frames in the video which is independent still images between I-frames.
  • Page 93 • Audio: Select if Audio function is to be used (applies to Primary Stream only) DNC® Server provides 2-way audio streaming by combining microphone input with video data. Users can listen to the streamed audio on PC speakers. •...
  • Page 94 DNC(Dmax Network Camera) User’s Manual Part 3 network bandwidth. Selecting the right requires lower network bandwidth, but gives decreased image quality. • Color Mode: Select either Color or Gray (applicable to Primary Stream only) • Hue: Set the color of image between -100 and 100 (applicable to Primary Stream only) •...

  • Page 95: Advanced Configuration

    DI (Sensor Input) Status/DO (Alarm Output) Control These DNC models have 1 Alarm output port and they act like a push button. When you click On button, it is essentially like the push button pressed. When you click Off button, it is like the push button not pressed.
  • Page 96 DNC(Dmax Network Camera) User’s Manual Part 3 In Periodic Service, only the image, alarm/sensor status after an event/schedule is reported to you upon the server is triggered. 6.1. Advanced Services Pre-Alarm buffer size and buffering speed can be defined here.
  • Page 97 DNC(Dmax Network Camera) User’s Manual Part 3 Pre-Alarm Buffer Size: You can set the buffer size which will store the images before event. The unit is in frame, and each channel can be set with different values. The total number of frames for Pre- Alarm Buffer and Post-Alarm Buffer is limited to 10 frames.
  • Page 98 DNC(Dmax Network Camera) User’s Manual Part 3 Item Description Camera 1 – Camera 4 Select a channel to be configured for email notification Service Select Enable in order to use this service SMTP server address Enter SMTP server’s address for sending email.
  • Page 99 DNC(Dmax Network Camera) User’s Manual Part 3 Item Description Condition 1 ~ Condition 3 Select a condition for Email service to be activated. Pre-Alarm Buffer Size The Buffer size assigned for Pre-Alarm. Check Video buffer Click this link to go to Advanced Services for buffer setup.
  • Page 100 DNC(Dmax Network Camera) User’s Manual Part 3 Select the format for the Event or DI data to email. NONE: Don’t Send, INT: Decimal Value Format HEX: Hexadecimal, BIN: Binary IPA: IP Address, EVT: Name of Event After finishing setup, click Save button to apply. If you don’t want to change, click Back button.
  • Page 101 DNC(Dmax Network Camera) User’s Manual Part 3 If you click on a Condition link, the Advanced Service windows is displayed as shown below. Alarm Service is activated only when the conditions in Advanced Services are met. Item Description Service This shows what service this condition is for.
  • Page 102 DNC(Dmax Network Camera) User’s Manual Part 3 Item Description Camera 1 - Camera 4 Select which channel to set up for FTP (Buffered). Service Select Enable to use the FTP (Buffered) service. Otherwise select Disable. Server Address FTP Server Address.
  • Page 103 DNC(Dmax Network Camera) User’s Manual Part 3 If Directory Name is checked, new directory is created with server name. Server Name If File Name is checked, new file is created with server name. If Directory Name is checked, new directory name is created with weekday.
  • Page 104 DNC(Dmax Network Camera) User’s Manual Part 3 Item Description Select a condition for FTP (Buffered) service to be activated. Up to 3 Condition 1 ~ Condition 3 conditions can be set. Pre-Alarm Buffer Size The Buffer size assigned for Pre-Alarm.
  • Page 105 DNC(Dmax Network Camera) User’s Manual Part 3 Item Description Camera 1 - Camera 4 Select which channel to set up for FTP (Periodic) service Service Select Enable to use the FTP (Periodic) service. Otherwise select Disable. Server Address FTP Server Address.
  • Page 106 DNC(Dmax Network Camera) User’s Manual Part 3 Date Description Mode Select Date Display Style (e.g. 20090228) Connection Mode Select connection mode for FTP server Overwrite If checked, new file overwrites the existing file with the same name. If Directory Name is checked, new directory is created with server name.
  • Page 107 DNC(Dmax Network Camera) User’s Manual Part 3 Item Description Select a condition for FTP (Periodic) service to be activated. Up to 3 Condition 1 ~ Condition 3 conditions can be set respectively. Alarm Speed Select the speed of images to send in FTP(Periodic) service After finishing setup, click Save button to apply.
  • Page 108 DNC(Dmax Network Camera) User’s Manual Part 3 Item Description Input 1 - Input 4 Select which input to set up for Sensor Notification Service Service Select Enable to use Sensor Notification. Otherwise select Disable. Service Mode Select network mode for CGI. Select one among HTTP, TCP, or UDP.
  • Page 109 DNC(Dmax Network Camera) User’s Manual Part 3 Sensor Notification Service Configuration for Each Input Item Description CGI Name or Alarm Port Message Enter the contents of CGI when it is used. Click Save button to save the change. Clicking Back button will cancel the change and go back to previous page.
  • Page 110 DNC(Dmax Network Camera) User’s Manual Part 3 Category Contents Output 1 – Output 4 Select the output port to configure for Alarm Output Service. Service Select Enable to use the service, otherwise select Disable. After finishing the configuration, click Save button to apply the change and continue to the next page.
  • Page 111 User ID 7.2. Save Configuration After setting up DNC® Server, it is recommended to make sure by saving the changes in Flash Memory in the system. To save all the changes made during configuration, first click on Save Configuration on Utilities menu.
  • Page 112 Server is on. Click OK button to close the web browser and reboot right away. If you click Cancel, the web browser is still open, but you will not be able to access the DNC Server until rebooting is done.
  • Page 113 7.5. System Update DNC Server’s system program and data are stored in Flash memory, and it consists of Kernel Image, RAM Disk Image, System Image, and Web Image. In order to update the system of the server, you should have proper image files ready in your PC.
  • Page 114 System and Web Update: Only System and Web images are to be updated. • Web Only Update: Only Web image is to be updated. Up-to-date system files can be downloaded in Support page of Dongyang Unitech’s homepages at www.cctvhome.net. After the update is done, it is required to reboot the server. 7.5.1.
  • Page 115 DNC(Dmax Network Camera) User’s Manual Part 3 In the next window, enter the location of the Firmware Image file to update with. You can use the Browse.. button to navigate the directories in your PC to find the file. Once the image file is selected, click Next button to proceed.
  • Page 116 DNC(Dmax Network Camera) User’s Manual Part 3 The next window is for locating the RAM Disk Update file. Go through the same steps as in Firmware Update, and do the same in update process for System and Web Update files.
  • Page 117 DNC(Dmax Network Camera) User’s Manual Part 3 Now the final confirmation window will appear. Click Reboot button and the system will reboot. 7.5.2. System and Web Update 1. Click the Start button next to System and Web Update item on the menu, and a confirmation window will appear.
  • Page 118 7.5.4. PTZ Device Driver Update When adding a new PTZ model that doesn’t have a proper driver found in DNC Server, it is required to install a driver for the PTZ function. The name of the file used in update process is PTZModel.bin.
  • Page 119 DNC(Dmax Network Camera) User’s Manual Part 3 4. It displays the window that requests to enter the location of the PTZ Device Image file. The upper right corner of the window shows the progress of current update. If your web browser’s pop-up blocker is enabled, your PC many not display the confirmation window above.
  • Page 120 Sensor Device Driver Update When adding a new Sensor device that doesn’t have a proper driver found in DNC Server, it is required to install a driver for it. The name of the file used in update process is SensorModel.bin.
  • Page 121 7.5.6. Flexible Extra system Flexible Extra system is an integrated system combining DNC® Server’s video with external devices. Examples of the external devices can be entry control equipment, POS terminal, intelligent video analyzer, GPS terminal, dust density monitor, license plate recognition system, and so on.
  • Page 122 DNC(Dmax Network Camera) User’s Manual Part 3 Now you can check the file name and the size in the new window. If you want to go back to the previous stage, click Previous button. Click Next button to update the System Image right away and proceed to next stage.
  • Page 123 DNC(Dmax Network Camera) User’s Manual Part 3 Check the file name and the size of Config Image file. If Previous button is clicked, it’ll go back to start of file locating stage. If Next button is clicked, the update process will be done and go back to the next stage.
  • Page 124 DNC(Dmax Network Camera) User’s Manual Part 3 Click Save button to save the Config file. Click Close button to close the editing window. If you click Next button, a window for rebooting is displayed. Click Reboot button, and the system will start over.
