- Page 1 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Ion Rx Installation & Owner’s Manual FOR TECHNICAL ASSISTANCE: CONTACT YOUR LOCAL DISTRIBUTOR For a list of distributors, visit us on the Web at www.amientertainment.com PM0721-09...
-
Page 2: Table Of Contents
Software License Agreement ... p. 52-57 © 2011 AMI Entertainment Network, Inc. Ion Rx, Megatouch, Ion, Mega-Lease, Mega-Link, MegaNet, MegaWeb, TournaMAXX and TournaCHAMP are registered trademarks of AMI. Reproduction of this manual, in any form or by any means, is strictly forbidden without the written permission of AMI. -
Page 3: Site Preparation
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. IMPORTANT NOTICE While the Megatouch Rx is weather-resistant and designed to channel water away from internal electronic components, it is not weatherproof. It is recommended that the Rx be placed in a protected environment out of direct rain and sunlight, such as under a canopy or awning. - Page 4 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. This model features a widescreen LCD with operator in violation of card processing an electronic sidebar that provides space...
-
Page 5: General Care And Maintenance
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. General Care and Maintenance Touch Menu again to select the option you want to change. Use the Left and Right but-... -
Page 6: Cleaning The Cabinet
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. • inserted straight onto the header and To ensure proper operation of the that the connector covers all header game, it is important that all fans are pins. -
Page 7: Rx Optional Marquee Installation Instructions
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Rx Optional Marquee Installation Instructions CAUTION WHILE THE RX MARQUEE IS OPTIONAL, DUE TO THE STRONG ADHESIVE USED TO SECURE IT, ONCE IT IS INSTALLED, IT IS NOT MEANT TO BE REMOVED. -
Page 8: Software Update Cable
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Software Update Cable Discs have been provided with your game in the event that you need to reinstall the software at any time. -
Page 9: Operator Setup Screens Flowchart
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Operator Setup Screens Flowchart Options Credits/Pricing Price Display Quick Price Setup Price/Credits Freeplay Enabled Cost to continue Coin-In Enable Coinless Coin Op... - Page 10 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Diagnostics Video Test I/O Test Touchscreen Calibration Touchscreen Test Checksum Test System Info Verify Databases Hard Drive Self Diagnostics...
-
Page 11: Main Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Main Menu The Main Menu can be accessed by pressing the SETUP button inside the game. Use the Main Menu to set up all game software options. NOTE: For help with the Options in any menu section, touch the green “?”... -
Page 12: Main Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Main Menu Available Options Information • • Gives details about various hardware DIAGNOSTICS System Info (continued) components in the game. -
Page 13: Credits/Pricing Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Credits/Pricing Menu IMPORTANT NOTE: On machines with credit card functionality enabled, adjusting either the Quick Price Setup or Coin-In Menu will change the default credit card pricing. Please make changes to credit card pricing AFTER configuring the Quick Price Setup or Coin-In Menu. -
Page 14: Coin-In Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Coin-In Menu determine the amount of money earned on a game by multiplying the meter pulse by the reading on the hard meter. -
Page 15: Coinless Coin Op Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Coinless Coin Op Menu Settings When enabled via the Options button on the Touching the Settings button allows the... -
Page 16: Rental Mode
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Rental Mode Per-Game Mode NOTE: It is recommended that you clear When players choose this mode, a running the books and perform a Cash Settlement... -
Page 17: Freeplay Mode
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Freeplay Mode tions available for that category and the price for each game, with the list at the bottom... -
Page 18: Hi Scores Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Hi Scores Menu Books Menu View/Clear Hi Scores The Books Screens display the current and lifetime credit totals for each game, as well Use this menu to manage high scores. -
Page 19: Cash Settlement
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Cash Settlement Setup To Enter This Screen, Touch “Books Display” on the Books Menu The Cash Settlement Screens are used to... - Page 20 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. To Enter This Screen, Touch To Enter This Screen, “Cash Settlement Setup” on the Touch “Cash Settlement Collection” Books Menu and touch the...
-
Page 21: System Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. System Menu FIGURE 14 - SYSTEM MENU The Set Time Menu allows you to set both the time and date on the Set Time game. -
Page 22: Diagnostics Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Diagnostics Menu FIGURE 15 - DIAGNOSTICS MENU Video Test Touch the screen to cycle through a series of video test screens. -
Page 23: Hard Drive Self Diagnostics
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Hard Drive Self Diagnostics To Enter This Screen, Touch “Show Details” on the Hard Drive Self Your Ion hard drive is equipped with the Diagnostics Screen S.M.A.R.T. -
Page 24: Network Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Network Menu - Hardware Setup This section describes the hardware side of networking your games. If you are connecting your Ion game wirelessly, skip to Connection Wizard. - Page 25 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Dial-Up Internet Setup For dial-up connections you will need to have a modem installed in your game. Turn off the game.
-
Page 26: Connection Wizard
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Connection Wizard NOTE: In order to establish any network connection (Internet, game-to-game, or jukebox), you must enter and complete the Connection Wizard. Additionally, since you can be con- nected to each network in a separate way, you must complete the Connection Wizard for each connection you wish to establish, be it wired, wireless or dial-up. - Page 27 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Wireless Ethernet After touching WIRELESS ETHERNET, you’ll be prompted to choose your connection method. • If you want to connect to an AMI router, touch AUTO-CONNECT TO AMI ROUTER and continue with step 8.
- Page 28 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. On the next screen, simply touch ACCEPT SETTINGS AND CONNECT to accept the default settings. If you wish to change the settings, touch MODIFY SETTINGS and use the SET or MANUAL buttons to enter the new settings.
-
Page 29: Ami Jukebox Mega-Link Setup
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. AMI Jukebox Mega-Link Setup tings. For help with any of the settings, touch the ? buttons on screen. After you... - Page 30 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Viewing Jukebox Revenue The game will download the music. A “Connection Successful” message will To view jukebox revenue from your AMI-en-...
-
Page 31: Local Tournament Mode
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Local Tournament Mode NOTE: If your game was running Tournamaxx and you are switching from On-Line Mode (Tournamaxx) to Off-Line Mode (Local Tournament), you will need to perform an “Update From Server”. - Page 32 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Programming a Tournament Press the SETUP button. At the MAIN MENU, touch the Tourna- ment button (see Figure 19).
- Page 33 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Repeat Icon Icon FIGURE 22 - TOURNAMENT SETUP SCREEN (EXPLANATION OF BUTTONS CONTINUES ON FOLLOWING PAGE) A programmed sequence of up to 5 tournament games.
- Page 34 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Tournament Sets duration for tournament games in the displayed Duration Tournament Sequence. Prize Sets the percentage of the tournament’s total coin drop Pool to be used for tournament prizes.
- Page 35 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. FIGURE 23 - WINNERS’ LIST SCREEN Awarding Prizes Players qualify for prizes by finishing with one of the top three high scores for the tournament.
-
Page 36: Credit Card Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Credit Card Menu (available on some models) Vault Credits Clear Player Vault Credits This option in the Vault Credits Menu will clear... -
Page 37: Presentation Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Presentation Menu Operator Ad Screens Sidebar images can also be created and re- A total of 24 advertising screens can be cre- motely sent to the game through the Tour- ated with the software and added to the game. -
Page 38: Promotion Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Promotion Menu NOTE: My Merit data will be cleared when a software update is performed. Be sure The Promotion Menu is designed to encour- to back up the data before updating the age player interest. -
Page 39: Merit Money
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Merit Money Promo Credits FIGURE 26 - MERIT MONEY SCREEN FIGURE 27 - PROMO CREDITS SCREEN The Merit Money screens allow location... -
Page 40: Meganet Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. MegaNet Menu Operator Web Site Access (U.S. Games Only) Direct access to the operator’s company Web site is available from the MegaNet Player NOTE: The game must perform an “Up-... - Page 41 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. MegaWeb and will not lose any credits. The timer count- down begins and specified credits are allo- MegaWeb allows the player to access the cated to the Web browser upon successful World Wide Web through the game.
- Page 42 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Hot Topics Home Page Hot Topics games allow players to compete Once the game connects to the Internet, the...
-
Page 43: Dip Switch Settings
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. DIP SWITCH SETTINGS The following table provides information on the functionality of the hard DIP switches in Mega- touch games. Make sure to read the information in the Notes column to determine what is affected when performing these functions. -
Page 44: Troubleshooting
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Troubleshooting Guide for Megatouch Ion Games ROBLEM ORRECTIVE CTION • • no power Check that the power cord is connected to a “live” outlet. - Page 45 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Troubleshooting Guide for Megatouch Ion Games continued ROBLEM ORRECTIVE CTION • • poor picture Adjust Brightness, Contrast, Horizontal, and Vertical quality controls with the monitor control board.
- Page 46 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Troubleshooting Guide for Megatouch Ion Games continued ROBLEM ORRECTIVE CTION • When the game is turned on, it will check the type of...
-
Page 47: Parts List And Illustrations Game Illustrations
COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Ion Rx Diagrams BILL ACCEPTOR COIN MECH CREDIT CARD READER FIGURE 32 - FRONT VIEW OF THE ION RX REAR LOCK POWER SWITCH PHONE COUPLER PROVIDED TIE WRAP SECURING POWER CORD TO U-BOLT... - Page 48 FIGURE 34 - REAR VIEW OF AN OPEN MEGATOUCH ION RX SATA SOFTWARE BOARD UPDATE PORT USB WIRELESS ADAPTER HARD DRIVE USB PORT FIGURE 35 - ANGLED REAR VIEW OF AN OPEN MEGATOUCH ION RX PM0721-09 MEGATOUCH ION RX OWNER’S MANUAL...
-
Page 49: Replacement Parts List
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Megatouch Ion Rx Replacement Parts List REPLACEMENT COMPONENTS ION RX PART NUMBER DESCRIPTION SA10078-02 ION MOTHERBOARD EC9788-02 BILL ACCEPTOR. $1/2/5, 700 STACKER... -
Page 50: Connection Diagrams
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Connection Diagrams SATA SOFTWARE HARD DRIVE UPDATE CONNECTION MOTHERBOARD CONNECTOR (SATA 0) POWER WATCHDOG TIMER/ DIMM POWER ON MEMORY... - Page 51 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Connection Diagrams Motherboard - Power Connector FIGURE 37 - REAR VIEW OF CABLE CONNECTOR WIRE COLOR ORANGE +3.3 VDC ORANGE +3.3 VDC...
-
Page 52: Connection Diagrams
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Connection Diagrams J1 & J20 ELECTRONIC MECH METER 2 (TWO CONNECTIONS) METER 1 TO OSD MECHANICAL BOARD DIP SWITCH... -
Page 53: Warranty
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. Video Machine Limited Warranty AMI Entertainment Network, Inc. warrants and copies of sales invoices, bills of lading its video machines to be free from defects... -
Page 54: Software License Agreement
COPYRIGHT © 2011 AMI ENTERTAINMENT NETWORK, INC. AMI Entertainment Network, Inc. Software License Agreement AMI Entertainment Network, Inc. (“Licensor”) is willing to license the enclosed software to you only if you accept all of the terms in this license agreement (“Agreement”). - Page 55 York shall have exclusive jurisdiction and venue regarding any disputes arising with regard to this Agreement or arising out of activity or misuse of the Software. 15. AMI Entertainment Network, Inc. in its sole discretion, may assign this agreement or any of its rights and obligations hereunder.
