ReconRobotics Command Monitoring Station 2.0 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Command
Monitoring
Station 2.0
Version 1.0 August 2012
User Manual
R000417

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Command Monitoring Station 2.0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ReconRobotics Command Monitoring Station 2.0

  • Page 1 Command Monitoring Station 2.0 Version 1.0 August 2012 User Manual R000417...
  • Page 2 All materials contained in this document are proprietary and confidential. Reproduction and duplication, without specific written permission, is strictly prohibited. For the most up-to-date version of this manual, please visit the ReconRobotics website. ReconRobotics, Inc 7620 W 78 Street Edina, MN 55439...

  • Page 3: Table Of Contents

    ReconRobotics Command Monitoring Station 2.0 Table of Contents Page Command Monitoring Station 2.0 (CMS 2.0) Inventory Hardware Setup & Use Channel Selection CMS 2.0 Software System Requirements CMS 2.0 Software Installation CMS 2.0 Software Main Screen CMS 2.0 Software Configuration...

  • Page 4: Command Monitoring Station 2.0 (Cms 2.0)

    Command Monitoring Station 2.0 (CMS 2.0) Inventory The Command Monitoring Station comes with the following components. Please inspect the inventory in this package to ensure that all materials are present. If any of the materials are missing, please contact support@reconrobotics.com for assistance.

  • Page 5: Hardware Setup & Use

    Hardware Setup & Use Follow these instructions to set up your Command Monitoring Station 2.0: Plug either power supply cord into the CMS Receiver.  Plug the power supply cord into a power source – standard wall (AC)  or vehicle outlet (DC), but not both at the same time.

  • Page 6: Channel Selection

    Channel Selection Every ReconRobotics robot is preset to one specific channel. The channel is indicated by a sticker on the shell of the robot. When pairing an OCU and a robot, the channel designations must match identically. Robot systems are specified with...

  • Page 7: Cms 2.0 Software System Requirements

    CMS 2.0 Software System Requirements  Minimum System Requirements USB 2.0 equipped desktop or laptop  CPU: 1 GHz  RAM: 512 MB  OS: Microsoft® Windows® XP w/ Service Pack 3 or above  Hard Drive Disk Space: 20MB ...

  • Page 8: Cms 2.0 Software Installation

    The installation may require a reboot of  your computer. After restarting, you should be able to  run the CMS 2.0 software from a shortcut on your desktop. If you run into any problems, contact:  ReconRobotics Customer Service 1-866-697-6267 ext. 3 Page 7...

  • Page 9: Cms 2.0 Software Main Screen

    CMS 2.0 Software Main Screen CONTROL BAR: Located at the bottom of the CMS 2.0 Software main window and contains all of the controls for the following functions. RECORD VIDEO: Start recording. Once pressed, the status bar at the top of the window will indicate that the software is recording and will note the elapsed time.

  • Page 10: Cms 2.0 Software Configuration

    CMS 2.0 Software Configuration Configuration window By clicking on the button on the main window, the configuration window appears. The configurable settings are: Save snapshots to – the directory where the snapshots (  button on main window) are saved. The default location is the Desktop of the current user.

  • Page 11: Faqs / Troubleshooting

    FAQs / Troubleshooting Why can’t my computer detect the Command Monitoring Station? Make sure that the CMS Receiver is connected to a USB 2.0  port. Make sure that your system has updated USB host drivers.  Make sure the CMS Receiver power is on. ...
  • Page 12 ReconRobotics sales representative. Our technical staff will attempt to troubleshoot the problem over the  phone. If necessary, ReconRobotics will issue an RMA (Return Material  Authorization) for repair. In addition to your original sales receipt, you will need to provide the ...

  • Page 13: Warranty

    Warranty Warranty The manufacturer’s warranty documentation is available online at http://www.reconrobotics.com/warranty. ReconRobotics, Inc 7620 W 78th Street Edina, MN 55439 Phone: 1-866-697-6267 or 952-935-5515 Fax: 952-935-5508 Website: http://www.reconrobotics.com For customer service, call 866-398-1921 Or email support@reconrobotics.com Page 12...
