Summary of Contents for PRAGMATIC COMMUNICATIONS SYSTEMS CATS-KP
- Page 1 CATS-KP M A R T A L L E Y P A D User’s Manual Pragmatic Communications Systems, Inc. 2934 Corvin Drive, Santa Clara CA 95051 Tel. (408) 735 0300 Fax (408) 735 0800 sales@wireless-experts.com...
- Page 2 Microsoft is a registered trademark of Microsoft Corp. Windows is a trademark of Microsoft Corp. CATS™ is a registered trademark of Pragmatic Communication Systems, Inc. CATS-KP User’s Manual Document Number: 30521...
-
Page 3: Technical Support
2. Refer to the CATS™ User’s Manuals for more information about the CATS™ Network. What is CATS-KP™? CATS-KP™ is a microcontroller-based graphics LCD wall keypad designed to integrate different aspects of today’s modern houses – multi source/multi room audio/video distribution, lighting and climate control as well as some other features of smart homes. -
Page 5: Table Of Contents
Technical Support ............................iii ____________________________________________________________ 9 NSTALLATION Installation steps..............................9 Step 1—CAT5 cable............................9 Step 2—connecting the CATS™ units ......................10 Step 3—connecting the CATS-KP™ keypads....................11 CATS™ N _______________________________________ 13 ETWORK CONFIGURATION Prerequisites ..............................13 Configuration steps ............................13 Step 4—Configuring the CATS™ unit address .....................13 Step 5—Configuring the CATS-KP™... - Page 6 Clock/Calendar Setup ...........................27 Lighting scenes configuration........................27 Labels Setup ..............................29 Source Labels Setup.............................29 Scene Labels Setup ............................29 IR R ______________________________________________________ 31 EMOTE ONTROL __________________________________________________ 33 ECHNICAL SPECIFICATION I. N ______________________________________________ 35 PPENDIX ETWORK EXAMPLE _________________________________________________________________ 37 OTES Table of Contents...
- Page 7 CATS-KP Table of Figures Figure 1: Wiring plans.......................10 Figure 2: CATS™ connectors....................10 Figure 3: Keypad connectors....................11 Figure 4: Menu structure #1......................15 Figure 5: Menu structure #2......................16 Figure 6: Menu structure #3......................17 Figure 7: Root screens ......................19 Figure 8: Root functionality .......................19 Figure 9: Source selection screen .....................20...
-
Page 9: Installation
IMPORTANT: For normal operation the CATS™ units have to be v2.3 or higher. Installation steps Installing CAT5 cables and RJ-45 plugs. Connecting CATS™ units to the network. Connecting CATS-KP™ keypads to the network. Connecting TW523 (TW7223) Power Line Interface (optional) Configuring installed keypads. Step 1—CAT5 cable Short for Category 5, network cabling that consists of four twisted pairs of copper wire terminated by RJ45 connectors. -
Page 10: Step 2-Connecting The Cats™ Units
Figure 1: Wiring plans We recommend using plan T-568B. Before connecting units we recommend to test the integrity of the cables and the connectors using a cable analyzer (such as AtlasIT). Loose or broken wires may stop the network functioning. Step 2—connecting the CATS™... -
Page 11: Step 3-Connecting The Cats-Kp™ Keypads
250 for the router 100 – 131 for CATS-KP™ wall keypads You can use the CATS-KP™ keypad or a PC-based software to store unique addresses in the Note: units. Only 1 unit must be connected to the RS485 network during this procedure! Step 3—connecting the CATS-KP™... -
Page 13: The Cats™ Network Configuration
Step 4—Configuring the CATS™ unit address There are two ways of configuring a CATS™ unit address: by using PC-based software or by using a CATS-KP™ keypad. Please refer to the User’s Manual if you are using PC-based software for more information. -
Page 14: Step 7-Configuring Scene Labels
We strongly recommend you read the entire User’s Manual in order to familiarize yourself with all the keypad’s features. Your keypad should now be ready for use. Enjoy the elegant convenience of the CATS-KP™ smart wall keypad. The CATS™ Network Configuration... -
Page 15: Menu Structure
CATS-KP Menu structure Menu structure Root screen (Long press) Lighting scenes Transport (Short press) Source Selection (Short press) CATS Media Server (CMS) More sources/ Root after 2.5 sec Setup screen [1] Clock setup Mute (1&2 simultaneously) [2] Lighting scenes Utilities (Long press) -
Page 16: Figure 5: Menu Structure #2
Utilities (Long press on button #5 from Root) Root Bass / Treble Balance Screen contrast CATS Setup Root Setup transmitters (8 screens) Target receiver setup Router setup Set address Router output Keypad address Figure 5: Menu structure #2 Menu structure... -
Page 17: Figure 6: Menu Structure #3
Setup (Long press on button 3 from Root) Root Clock setup Lighting scenes Labels Source labels Scene labels Reset Figure 6: Menu structure #3 Menu structure... -
Page 19: Menu Items
CATS-KP Menu items Root Root is the first screen keypads display after a reset. There are 2 modes in the root screen: Normal Muted Figure 7: Root screens Both modes have identical functionality except for a simultaneous press of buttons [1] and [2] which issuing the mute command while in normal mode, and while in muted mode volume up button [1] to return the keypad to normal mode. -
Page 20: Source Selection
Source selection [Root –> (#3) -> Source selection] CATS-KP™ keypad allows up to 18 sources to be configured and labeled. Sources 1 and 2 belong to the local (target) CATS™ receiver which the keypad has been configured to control. Source #1 corresponds to the Local Main input and source #2 to the Local Aux input. Sources 3 to 18 belong to remote transmitters. -
Page 21: Lighting Scenes
[Root –> (#4 short press) -> Lighting scenes] Figure 11: Lighting scenes screen The CATS-KP™ keypad allows for configuration of up to 4 lighting scenes, each consisting of up to 7 X10 commands issued sequentially. A typical mode would be the “I am home” scene when a series of light control commands may be issued in order to provide desired mood lighting. -
Page 22: Utilities Menu
Utilities Menu [Root –> (#5)(Long press) -> Utilities] Root CATS™ Setup Contrast adjustment Balance adjustment Tone adjustment Figure 13: Utilities Menu Tone adjustment [Root –> (#5) (Long press) -> Utilities -> (#1) -> Treble/Bass] This function adjusts audio tone on the local CATS™ receiver. Balance adjustment [Root –>... - Page 23 The keypad’s LCD is, by default, automatically adjusted to provide the optimum contrast. However, users can change the contrast manually in fine (buttons [1] and [2]) and coarse steps (buttons [3] and [4]). Adjusted contrast is not stored in the non-volatile memory and will be reset to the default value should a power cut occur.
-
Page 24: Cats™ Setup
[Root –> (#5) (Long press) -> Utilities -> (#5) -> CATS Setup -> (#1) TX Setup] As described before, the CATS-KP™ keypad can control up to 18 audio/video sources (1 CATS™ receiver and up to 8 CATS™ transmitters). Each transmitter available to the keypad must be made known to the keypad by providing its network address. -
Page 25: Target Setup
Target Setup [Root –> (#5) (Long press) -> Utilities -> (#5) -> CATS Setup -> (#2) Target Setup] Similarly to transmitters’ addresses above, the receiver’s address must be made know to the keypad before it can “talk” to it. Although only 1 receiver’s address can be entered, several keypads can control the same receiver. -
Page 26: Keypad Address Setup
This will store the router’s output number to which the target receiver is connected in the keypad’s non-volatile memory. Please have your network diagram available at the time of entering to ensure that the entering number is correct. Please see the CATS™ User’s manuals for more information on the structure of the CATS™ network. -
Page 27: Keypad Setup
Clock/Calendar Setup [Root –> (#4 long press) -> Keypad Setup -> #1 -> Clock/Calendar Setup] The CATS-KP™ keypad has a real-time clock/calendar which needs to be set before the keypad can be used properly. Buttons #3 and #4 will move the cursor left and right whereas buttons #1 and #2 will change the values. - Page 28 There are 28 scene components grouped in 4 scenes of 7 components each. In other words, components 01 – 07 belong to lighting scene #1, 08 – 14 to scene #2, 15 – 21 to scene #3, 22 – 28 to scene #4. IMPORTANT: Please remember that you must configure at least 1 scene’s component to include the scene in the list of available scenes.
-
Page 29: Labels Setup
Labels Setup [Root –> (#4 long press) -> Keypad Setup -> #3 -> Labels Setup] Figure 16: Labels menu Before labels are entered the keypad must know which kind of labels (Source or Scene) is being entered. Although the entering procedure is almost identical, the labels are stored in different part of the internal memory. -
Page 31: Ir Remote Control
CATS-KP IR Remote Control The CATS-KP™ keypad uses the same format of the IR commands as the CATS™ units. The following commands have been implemented: Figure 18: CATS™ IR Remote Control VCR [000] 1 – Lighting Scene #1 VCR [000] 2 – Lighting Scene #2 VCR [000] 3 –... -
Page 33: Technical Specification
CATS-KP Technical specification Power supply: 9-12 V DC unregulated reverse polarity protected Consumption: 55 ma typical, 80 ma max Operating temperature: 5 – 40 ºC (non-condensing) Labels length: Source: 6 characters (v3.2x); 16 chars (v4.xx) Scene: 6 characters (v3.2x); 16 chars (v4.xx) -
Page 35: Appendix I. Network Example
CATS-KP Appendix I. Network example Appendix I. Network example... -
Page 37: Notes
CATS-KP Notes Notes... - Page 38 Enjoy the elegant convenience of CATS-KP™ If you have comments or questions, contact us at: Pragmatic Communications Systems, Inc. 2934 Corvin Drive, Santa Clara CA 95051 sales@wireless-experts.com www.wireless-experts.com...
