VP-4 Pager – Programming User Guide
Manual Programming Mode
The manual programming provides access to the settings of 6 capcodes, baud rate, frequency and data polarity.
1. Insert a battery and turn on the pager.
2. a. Press the FUNCTION (ARROW UP) key until the graphic menu is displayed.
b. Press the RIGHT ARROW key until the display shows ON/OFF PAGER.
c. Press the FUNCTION (ARROW UP) key to turn off the pager.
3. Press and hold the both the LEFT ARROW and RIGHT ARROW keys until the password screen is displayed.
4. Enter the password using the RIGHT ARROW key to select a digit and press FUNCTION (ARROW UP) key to navigate to the
next password digit.
After the 4th digit was entered, press the READ/ON-OFF key.
Note: Default password is 1141.
Changing Capcodes
1. Enter the manual programming mode as described in the Manual Programming Mode section. The display will show
ADSYSBFRQT.
2. a. Verify that the AD field is underlined or use the RIGHT ARROW key to navigate the cursor to the AD field.
b. Press the SELECT (ARROW UP) key.
3. The display will show "1: CCCCCCC 0", where CCCCCCC is the capcode already programmed in to the pager.
The first digit label represents the number of the capcode (capcode ID) to be edited. For example, 1 represents capcode #1 and 6
represents capcode #6.
4. Select the ID of the capcode to be edited using the SELECT (ARROW UP) key.
5. Press the RIGHT ARROW key. The cursor will move to the CAPCODE field.
6. a. Use the SELECT (ARROW UP) key to enter a respective capcode digit for each underlined digit in the capcode field.
b. Press the RIGHT ARROW key to navigate to the next digit.
c. After the rightmost digit was entered, press the RIGHT ARROW key. The cursor will move to the ON/OFF field.
Note: Standard capcode range is from 0000008 to 2097151. Invalid capcodes will be rejected.
7. Use the SELECT (ARROW UP) key to toggle between 0 (ON) and 1 (OFF) for the selected capcode. If you wish the capcode to
be active, select 0 (ON).
8. Press the RIGHT ARROW key. The cursor will move to the capcode ID field.
9. To program additional capcodes, press the SELECT (ARROW UP) key to select the capcode to be programmed and repeat steps
4-8 for each capcode.
Otherwise, press the READ/ON-OFF key to return to the main programming menu.
10. a. If additional programming is not required, press the RIGHT ARROW key until the cursor is under the QT field.
b. Press the SELECT (ARROW UP) key exit the programming mode and return to standard operation mode.
Changing Baud Rate, Polarity and Password
1. Enter the manual programming mode as described in the Manual Programming Mode section. The display will show
ADSYSBFRQT.
2. a. Press the RIGHT ARROW key to position the cursor under the SY field.
b. Press the SELECT (ARROW UP) key.
3. The display will show a sequence of data digits in two lines: "PRRRURRS TCL" on the first line and "B FFFF WWWW" on the
second line. Below is the description of each field:
P – Polarity
RRR
U – Unread Messages Alarm
RR
S - Stand By Icon
VP-4 Pager – Programming User Guide – Version 1.00
0 – Normal, 1 – Inverted
Reserved (Do Not Modify)
0 – Enable, 1 – Disable
Reserved (Do Not Modify)
0 - Disable, 1 – Enable
