Summary of Contents for DREAMJET 329 MIRACLE
- Page 1 Dream Jet 329 Miracle Manual Dreamjetkorea DREAMJET 329 MIRACLE 1 / 22 page www.dreamjetkorea.com...
-
Page 2: Safety Instruction
Dream Jet 329 Miracle Manual Dreamjetkorea 1.Safety Instruction. Read all of the instructions in this section when setting up and using your printer. When choosing a place for the printer Avoid places subject to rapid changes in temperature and humidity. Also, keep the printer away from direct sunlight, strong light, or heat sources. - Page 3 Dream Jet 329 Miracle Manual Dreamjetkorea 2. Packing Contents. - Printer boxes * Printer * Dreamjet setup disk * Power cord * Anti-static Brush * Injector * 8-color ink sample (each color 100ml) * usb cable * 100ml power clinic solution.
- Page 4 Dream Jet 329 Miracle Manual Dreamjetkorea 3. Dreamjet button name. Vacuum power button Main power button Bed vaccum button USB connetor Power connetor temperature controller Power button www.dreamjetkorea.com 4 / 22 page...
- Page 5 Dream Jet 329 Miracle Manual Dreamjetkorea - The function of the remote controller. . Start button To let the printer start of initialization. . Function button To go into the function menu. . Paper set button To let the bed come out.
- Page 6 Dream Jet 329 Miracle Manual Dreamjetkorea 3. How to charge the ink. 1) Open the left upper case, and then fill out the ink in each bottle. (image 1) (image 2) (image 3) 6 / 22 page www.dreamjetkorea.com...
- Page 7 Dream Jet 329 Miracle Manual Dreamjetkorea 2) After fill out the ink, pull the ink to the head. There’s two way, just choose one of them. - First way - Connect the power cord Press the start button on the remote When the standby button is blink, press the standby button ...
-
Page 8: Install The Printer Driver
If the initialization is finish, the standby button blinks. Install the printer driver. There’s execute file in the dreamjet data CD, or if you can’t find it, you can download the driver file from the Epson website (http://www.epson.com) Driver Name : Epson stylus photo R2400 After finishing the installing, you can find the driver (Epson stylus photo R2400) in the printer folder on the computer as the below. - Page 9 Dream Jet 329 Miracle Manual Dreamjetkorea 5. How to set the printer driver. 1. Click the “Printing preferences” after click the right button on the mouse of the EPSON Stylus photo R2400 icon in the printer and FAX folder. 2. Click the“Advanced”.
- Page 10 Dream Jet 329 Miracle Manual Dreamjetkorea Defined as paper size Set the name of the paper size as 3290*6500 Set the width of paper as 3290 Set the length as 6500. Save OK 10 / 22 page...
- Page 11 Dream Jet 329 Miracle Manual Dreamjetkorea 5. Clear all the print options like the following image. Click the Save Setting Save custom settings name as “Low RPM”. 11 / 22 page www.dreamjetkorea.com...
- Page 12 Dream Jet 329 Miracle Manual Dreamjetkorea Above the same way, save the setting name as “Best Photo” . “High speed should be not checked.” It is done when you click the “OK” button after you make below. *. Rowrpm : High resolution, low speed.
- Page 13 Dream Jet 329 Miracle Manual Dreamjetkorea 6. How to printing. - Initalize the machine. Make the machine initialized. Refer to the page #9 on this manual. After finishing the initialization, the standby button is blinked. Print on the Bed with guideline.
- Page 14 Dream Jet 329 Miracle Manual Dreamjetkorea If you click the button (property), be appeared the dialog box as the below. Choose the best photo, and then click “OK”. Click the “Print” If you send the data, starting print the guideline on the bed.
- Page 15 Dream Jet 329 Miracle Manual Dreamjetkorea - Make a test to print on the material. Put the material on the bed as the below, and then press the standby button. The bed move to the backside. (20cm) (30cm) Img #1...
- Page 16 Dream Jet 329 Miracle Manual Dreamjetkorea Put the image which you want to print on the guideline as the below, and then click “Print” Be appeared the dialog box as the below, choose the print driver(Epson stylus photo R2400), and then click the button in the red box.
- Page 17 Dream Jet 329 Miracle Manual Dreamjetkorea You can find one more option as below , select the “Rowrpm”. Select the Bestphoto And then click “ok” and click print. To print just image, you should check this option(Selection) 17 / 22 page...
- Page 18 Dream Jet 329 Miracle Manual Dreamjetkorea If you click the print button, the machine start to print. While it is printing, please check the height gap between the head and material. After printing, you can get the result as the below.
-
Page 19: Nozzle Check
Dream Jet 329 Miracle Manual Dreamjetkorea 7. Nozzle Check Put the paper on the front side of the bed and then move the bed to the backside by “standby button” on the remote of the printer Choose the Epson Stylus photo R2400 icon from “Printers and Fax folder” Click the ... - Page 20 Dream Jet 329 Miracle Manual Dreamjetkorea Click the nozzle Check button Click the print. If you get the result as pic 1, it is good, but when you get it as Pic 2, you should clean the head.
- Page 21 Dream Jet 329 Miracle Manual Dreamjetkorea 8. How to setting the height controlled sensor. Sometimes the height controlled sensor value is changed because of the over electronic power in a moment. There are two kinds of symptoms. When you turn on the power, even though there’s nothing, if the sensor is light on as the below, you should set the sensor again.
- Page 22 Dream Jet 329 Miracle Manual Dreamjetkorea Do following instruction. Change as “SET” 2. Press “OFF” 3. Block the sensor as the below (Must check the led “On”) and then press “ON”Button 4. After reset the sensor, must check whether the led is “ON” or not when you block the sensor with finger.
