I n s t r u c t I o n M a n u a l
HS10SUB

Introduction

Thank you for purchasing a SLS Subwoofer. When properly installed,
this subwoofer will provide you with years of outdoor entertainment
pleasure. To get the most out of your new subwoofer, please read
this manual thoroughly before you begin installation.

Box Contents

SLS Hardscape Subwoofer box contains:
(1) Hardscape Subwoofer
(2) Silicon Filled Wire Nuts

Subwoofer Location Selection

The SLS is designed to deliver a seamless, evenly dispersed sound
field in an 'open air' environment. An array of multiple Satellite
speakers and Subwoofers should be strategically placed to
minimize 'hot spots' and 'nulls' as you move around the outdoor
entertainment area
as a general guideline, (1) subwoofer will cover about 2000
square feet of listening area
Figure 1 Shows The SLS placed along the perimeter of the
entertainment area.
Select a central location for the subwoofer if using only one subwoofer
(see figure 1) if using multiple subwoofers, select locations that are
the same distance from the main listening area.
Subwoofer
Figure 1

Amplifier Power Planning

The maximum number of satellites and subwoofers that can be
used in a system will depend on the amplifier power available.
Before beginning an installation use the chart below to calculate
the amplifier power your installation will require. Multiple
amplifiers may be required in large installations.

Wattage Calculator

model qty. ch1 qty. ch2 x
LS47SAT
LS67SAT
LS10SUB
LS12SUB
HS10SUB
TOTAL MINIMUM WATTAGE

Amplifier Selection

For systems up to 500w per channel use the CROWN CDI 1000
For systems up to 800w per channel use the CROWN CDI 2000
For systems up to 1000w per channel use the CROWN CDI 4000
1
HS10SUB Subwoofer
Patent Pending
watts total ch1 total ch2
x 25
x 25
x 100
x 100
x 100
total
20%
head
room
