Sony Ipela SNC-CH120 Specification

SNC-CH120
Network HD Camera --- E Series
High-Quality 720p HD Security Camera
Excellent 720p HD picture quality,
supporting H.264 at 30 fps
1.3 Megapixel (1280 x 1024) maximum
resolution
Three codecs (H.264, MPEG-4, JPEG) and
a dual streaming capability
The Exmor™ CMOS sensor incorporated to
deliver high image quality and low noise
Key Features
• Easy Focus function for easy installation.
• Optical Day/Night function to switch to Day or Night
mode depending on the light level.
• Recording software (RealShot Manager Lite) is bundled
to start recording and monitoring instantly.
• Stream Squared function allows simultaneous streaming
of two 4:3 aspect ratio videos in user selectable SD
resolutions. User can select the entire image or a portion
of the image from the original field of view and resize to
SD resolution or lower for each stream. With this feature,
the SNC-CH120 can replace two SD cameras installed in
the same line of view.
Example
(Simulated Images)
1st Streaming
VGA video of a whole
Dual
Streaming
2nd Streaming
VGA video of a cropped area
• DEPA™ Intelligent Video Analytics
system can be set up with a DEPA-
enabled recorder.
• Analog monitor output (phono jack).
• Powered by PoE (Power over Ethernet)
for simple installation.
• ONVIF™ (Open Network Video Interface
Forum) software that ensures greater
interoperability and more flexibility in
building multiple-vendor systems.
