- Page 1 DATA PROJECTOR User’s Manual KG-PS232Xh/232X KG-PV131X/131S IMPORTANT • DLP® (Digital Light Processing) and DLP® chip are registered trademarks of Texas Instruments Incorporated (U.S.A.). • VGA and XGA are trademarks or registered trademarks of International Business Machines Corporation (U.S.A.). • S-VGA is a registered trademark of Video Electronics Standards Association.
-
Page 2: Important Safety Information
FCC Rules. Precautions Thank you for your purchase of this TAXAN data projector. Please read this User’s Manual to the end so that you will be able to use this product properly. - Page 3 Consult the dealer or an experienced radio/TV technician for help. DOC Compliance Notice This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Hg: Lamp in This Product Contains Mercury. Dispose of Lamp According to Local, State or Federal Law. KG-PS232Xh/232X | KG-PV131X/131S User’s Manual...
- Page 4 Important safety information Important Safeguards These safety instructions are to ensure the long life of the unit and to prevent fire and shock. Please read them carefully and heed all warnings. Installation • For best results, use the unit in a darkened room. •...
-
Page 5: Ways Of Viewing This Manual
See Page E-12 ➜ This introduces operating information from the illustrations of the menu screens. I would like to look up operating information about this product using keywords “Finding Information with Keywords” See Page E-14 ➜ KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 6: Table Of Contents
Turn off the power after projection is finished ......................E-38 Regular Operation .................................E-39 Selection of Input Signal ..........................................E-39 Automatic Adjustment ............................................E-39 Auto Focus ....................................E-40 KG-PS232Xh/232X only Auto Keystone ..............................................E-40 Temporarily Blanking/Muting the Video/Audio ................................E-40 Pausing the Video ...............................................E-41 Projection Mode Selection ..........................................E-41 Eco Mode ......................................E-42... -
Page 7: Table Of Contents
When an indicator is lit or flashing ..........................E-83 At a time such as this… ...............................E-84 Maintenance Cleaning ..................................E-86 Replacing the Lamp Cartridge ...........................E-87 Major Specifications Specifications List ................................E-90 Table of Supported Frequency ...........................E-94 Cabinet Dimensions ..............................E-95 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 8: Helpful Hints
I would like to use the projector in a simple manner. This product is equipped with an auto focus function and an auto keystone Technical Point KG-PS232Xh/232X correction function. (Only the have the auto focus function.) When shipped from the factory, both of these functions are ON. - Page 9 See “Set Password” for information about setting the password. See Page E- mischief and unauthorized use. When a password has been set, upon starting the projector a password entry screen will be displayed. Use of the projector will not be possible unless the password is entered. KG-PS232Xh/232X | KG-PV131X/131S User’s Manual...
-
Page 10: Finding Information With The Remote Control
FOCUS button AUTO FOCUS button This button operates the focus manu- This button adjusts the focus auto- ally. matically. KG-PS232Xh/232X only KG-PS232Xh/232X only See Page E-42. See Page E-40. KEYSTONE buttons AUTO KEYSTONE button These buttons operate the keystone This button corrects the keystone dis- correction manually. -
Page 11: Finding Information With The Projector Control Panel
This projector can manually or automatically correct the distortion in the vertical direction. See “Using the Menu” for details. See Page E-46. See “Auto Keystone”, and “Keystone” for details. See Pages E-53 and 54. E-11 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 12: Finding Information From The Operations Screen
Finding Information with the Remote Control and the Projector Control Panel Finding Information from the Operations Screen This section describes menu viewing and operation. Please see the various explanatory pages about menu functions and adjustment/setting methods. To use the remote control, direct it towards the remote control infrared sensor of the projector and operate it. -
Page 13: Menu Item List
E-62 Chroma E-72 E-73 Input Computer1 E-74 Computer2 E-74 Video E-74 S-Video E-74 Admin Set Password E-75 Version E-78 Lamp Timer E-79 Lamp Timer Reset E-80 Initialize E-81 Startup Screen E-81 Background Color E-82 E-13 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 14: Finding Information With Keywords
Finding Information with the Remote Control and the Projector Control Panel Finding Information with Keywords Keyword Page Keyword Page Advanced Menu E-50 E-34 Initial Setting Aspect Ratio E-66 E-81 Initialize E-39 AUTO Input source E-39, 51 E-40 AUTO FOCUS E-43 KEYSTONE Auto Focus function E-40, 53... -
Page 15: Check Before Use
“WARNING” Handling the cables supplied with this product, will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm. Wash hands after handling. E-15 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... - Page 16 Check before Use Check the Accessories Soft Case [1] Item Insertion This case will hold the projector, the accessories, and the Close the lens shutter of the projector and place the user’s manual. projector in the case with the lens facing upward. Place the accessories in the storage pocket.
-
Page 17: Names Of The Projector Parts And Their Functions
Adjusts the projection angle. See Page E-36. Rear adjusters Adjust the projection angle. See Page E-36. Lamp cover See “Replacing the Lamp Cartridge” for information about how to replace the lamp. See Page E-87. E-17 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... - Page 18 Check before Use Names of the Projector Parts and their Functions AC IN connector See Page E-33 Built-in Security Slot This is compatible with the Micro- Saver® security system manufactured by Kensington Computer Products Ventilation slots Group. (See below) Remote control sensor AUDIO IN connector See Page E-30 VIDEO IN connector...
-
Page 19: Names Of The Remote Control Parts And Their Functions
Check before Use Names of the Remote Control Parts and their Functions Two types of remote control are available for this product. Here, the description will be based on the remote control for model KG-PS232Xh/232X. KG-PV131X/131S * The remote control for model does not include some of the buttons. -
Page 20: Preparing The Remote Control
Check before Use Preparing the Remote Control Installing the Batteries (and Battery Replacement) The projector and the batteries are packaged separately. Insert the batteries in the remote control before use. When it is time to replace the batteries, do so using the same procedure. Open the cover of the battery Insert the batteries so that + Close the cover of the battery... -
Page 21: Basic Operation
“Using YCbCr Connectors or YPbPr Connectors” on Page E-29. ing YCbCr connectors such as DVD players, etc. • A commercially-available component cable is required to make connection with equipment having YPbPr connectors such as high definition video equipment, etc. E-21 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... - Page 22 Basic Operation The Procedure from Projection to Turning Off the Power Turn On the Power Press the POWER/STANDBY button of the remote control or the projector and turn on the power. The indicator of the POWER/STANDBY button will change from the orange color of the standby mode to (flashing) blue.
-
Page 23: Properly Adjusting The Projected Image To The Screen
“Projection Mode selection” See Page E-41. • Advanced Menu: Allows more detailed video settings to be made such as age, and Color. “Advanced Menu” See Page E-63. Continued on next page E-23 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... - Page 24 Basic Operation The Procedure from Projection to Turning Off the Power Technical Point Turn Off the Power after Projection is Finished What is the Quick-off function? The projector is equipped with a Quick-off function. Even After projection is finished, press the POWER/STANDBY button to turn off the when the power cable is unplugged soon after turning off power.
-
Page 25: Placement
250" 5.08 × 3.81 16.67 × 12.50 8.49 – 9.82 27.85 – 32.22 4.20 13.78 0.39 1.28 300" 6.10 × 4.57 20.00 × 15.00 10.20 – 11.79 33.46 – 38.68 5.04 16.54 0.47 1.54 E-25 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 26: Connecting Personal Computers And Video Equipment
• Setting the output frequency of the personal maximum displayable resolution is 1024 × 768 dots (XGA). computer to 60 Hz will result in the display of the clearest video. KG-PS232Xh/232X KG-PV131X • An appropriate resolution for the is 1024 ×... - Page 27 Fn + F3 Panasonic Fn + F3 SHARP Fn + F5 SONY Fn + F7 SOTEC Fn + F3–F5 TOSHIBA Fn + F5 Note: The content of the table is current as of December, 2007. E-27 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual...
-
Page 28: Connections With Typical Video Equipment
Basic Operation Connecting Personal Computers and Video Equipment Connections with Typical Video Equipment Technical Point This product can project the video from a wide variety of video equipment includ- ing video decks, television, and video cameras, etc. What is a RCA Connector, and a S-Connector? Using RCA Jacks Several types of connectors are used as video connectors... - Page 29 Cr (Pr) is described as Y/Cb/Cr. Connectors that can be used for video formats above NTSC may be described as Component cable (Commercially-available) (Mini Y/Pb/Pr. D-Sub 15-pin/RCA 3-pin) Green Blue Component Component Green Blue Component cable (Commercially-available) (Mini D-Sub 15-pin/RCA 3-pin) E-29 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual...
-
Page 30: Connections With The Audio Jacks
Basic Operation Connecting Personal Computers and Video Equipment Connections with the AUDIO Jacks Note • Connect to the projector’s AUDIO IN jacks using a commercially-available audio cable. Use a commercially-available audio conversion adapter to make the con- Audio will not be output when there is no projec- nection when the audio connectors of the equipment to be connected are RCA tion. -
Page 31: Connections With The Monitor Out Connector
Thank you for your understanding in advance. Image projected to the screen Image projected to the screen RGB signal cable RGB connector of the display (Mini D-Sub 15-pin) E-31 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 32: Connections With The Rs-232C Connector
Basic Operation Connecting Personal Computers and Video Equipment Connections with the RS-232C Connector Note • Connect the RS-232C connector of the control equipment with the RS-232C connector of the projector using a commercially-available serial cable (of the The connection might not work depending on the D-Sub 9-pin straight type). -
Page 33: Turning On The Power
Turn the lens shutter clockwise. Projection will be possible when the lens shutter activate Blanking/Muting of the video/audio. This is a conve- has stopped with a click sound. nient function that temporarily makes the video go blank. Continued on next page E-33 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 34: Turning On The Power For The First Time After Purchase
Auto Focus setting : Sets the auto focus function KG-PS232Xh/232X only or Off. To use the auto focus function, align the cursor with and press the ENTER button. (The factory default setting is On.) When you will not be using the auto focus function, align the cursor with and press the ENTER button. - Page 35 KG-PS232Xh/232X only • Change of Auto Keystone setting “Auto Keystone” See Page E-53 • Change of Startup Screen setting “Startup Screen” See Page E-81 • Change of Background Color setting “Background Color” See Page E-82 E-35 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual...
-
Page 36: Properly Adjusting The Projected Image To The Screen
Turn the zoom ring and adjust the size of the projected image. Adjust so that the desired image size is obtained. When the size does not match by adjusting the zoom ring, move the projector back or forward. KG-PS232Xh/232X KG-PV131X/131S Zoom ring Technical Point Adjusting the Projected Image to the Screen The projector is equipped with an Auto Keystone function. -
Page 37: Adjusting The Focus
This function will not operate when the screen has been moved. Note Change the projection method when the projector is installed suspended from the ceiling, or is in a rear projection setup. See “Vertical Flip / Horizontal Flip” on Page E-68. E-37 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 38: Turn Off The Power After Projection Is Finished
Basic Operation Turn off the power after projection is finished Technical Point Turning Off the Projector Power The projector is equipped with a Quick-off function. Even Press the POWER/STANDBY button of the remote control or the projector. when the power cord is unplugged soon after turning off the power, the internal power supply will power the rotation •... -
Page 39: Regular Operation
When the display position is shifted, there are vertical stripes on the screen or other instances of a poor projection even though automatic adjustment has been performed, adjust the video manually. See “Image” for details. See Pages E-63 to 65. E-39 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 40: Auto Focus Kg-Ps232Xh/232X Only
Basic Operation Regular Operation Auto Focus KG-PS232Xh/232X only KG-PS232Xh/232X only • A press of the AUTO FOCUS button activates the Auto Focus function, and adjusts the focus automatically. Auto Focus setting is On, the focus will be adjusted automati- •... -
Page 41: Pausing The Video
This is an optimum setting when projecting a movie. Video S-Video Blackboard This is an optimum setting when projecting onto a blackboard. Custom Color Advanced Menu. A setting that will apply the value that was set with under the E-41 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 42: Eco Mode Kg-Ps232Xh/232X Only
Basic Operation Regular Operation Eco Mode KG-PS232Xh/232X only KG-PS232Xh/232X only Note This function can limit the power consumption of the projector to permit the lamp to be used longer. By limiting the power consumption, the brightness Please note that frequent switching of the Eco will drop;... -
Page 43: Manual Adjustment Of Keystone
The display will close automatically when there has not been an operation in about 10 seconds. * Adjustment of the volume will not be possible unless video is being pro- jected. E-43 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 44: Enlargement Of The Video And Image Movement
Basic Operation Regular Operation Enlargement of the Video and Image Movement This function digitally enlarges projected images and video. • Press the D-ZOOM button of the remote control (▶), and enlarge the video. A press of the D-ZOOM button will display the zoom adjustment display. Each press of ▶... - Page 45 The display will close automatically when there has not been an operation in about 10 seconds. * When finished with the enlargement operation, be sure to return the value Zoom to 100. E-45 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual...
-
Page 46: Using The Menu
Using the Menu Menu Operation Method The menu operation method will be introduced so that you can more conveniently use the projector. • Please see the various explanatory pages about the adjustment/setting methods of the various settings. • Direct the remote control toward the infrared sensor of the projector and operate it. •... -
Page 47: Using Menu Operations
* Selecting will switch the display to the operation method is the same as for Simple Menu. Select the Item Name Press the cursor buttons (▲▼) and select the item name. Continued on next page E-47 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... - Page 48 Using the Menu Menu Operation Method Making Adjustments and Settings Press the cursor buttons (◀▶) and the ENTER button and make the adjustment or setting. Close the Menu Screen Press the MENU button and close the menu screen. To Select another Menu Item when an Item Name Is Selected Press the cursor buttons (▲▼) and select the menu name.
-
Page 49: List Of Items Allowing Adjustment Or Setting Of Each Input Signal
○ Still Image E-57 ○ ○ ○ ○ Zoom E-58 ○ ○ ○ ○ Timer Display E-60 ○ ○ ○ ○ Volume E-61 ○ ○ ○ ○ Select language E-62 ○ ○ ○ ○ E-49 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... - Page 50 Using the Menu List of Items Allowing Adjustment or Setting of Each Input Signal The adjustment or setting that can be performed will differ depending on the input signal. See the table below for details. Advanced Menu COMPUTER IN Menu Name Item VIDEO IN S-VIDEO IN...
-
Page 51: Simple Menu / Source
Align the cursor with the item name and switch the function with the cursor buttons (◀▶). Manual selection This selects the input signal manually. • Select the desired input source and press the ENTER button to finalize. E-51 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 52: Simple Menu / Settings
Using the Menu Simple Menu / Settings This performs simple settings when projecting images or video. Source Settings Tools Projection Mode This projector has preset “Projection Modes” to suit the application. Projection Mode • Align the cursor with the item name and select the de- sired projection mode with the cursor buttons (◀▶). -
Page 53: Auto Focus Kg-Ps232Xh/232X Only
This projector can manually or automatically correct the distortion in the vertical direction. E-53 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 54: Keystone
Using the Menu Simple Menu / Settings This performs simple settings when projecting images or video. Source Settings Tools Keystone Keystone distortion will occur when the angle of the projector is tilted (in the vertical direction) with respect to the screen. Keystone distortion can be cor- rected using this operation. -
Page 55: Auto Power Off
Auto Power Off will not operate. · The source input will be processed while the display appears; however, pressing an operation button other than the POWER/STANDBY button will close the display and cancel the function. E-55 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 56: Eco Mode Kg-Ps232Xh/232X Only
Source Settings Tools Eco Mode KG-PS232Xh/232X only KG-PS232Xh/232X only This function can limit the power consumption of the projector to permit the lamp to be used longer. By limiting the power consumption, the brightness will drop; however, the service life of the lamp will be longer than with normal use. -
Page 57: Simple Menu / Tools
A press of the ENTER button will activate the Still Image function and this will temporarily stop the projected images or video and close the menu screen. Still Image, a button with the exception of the POWER/STANDBY • To cancel button. E-57 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 58: Zoom
Using the Menu Simple Menu / Tools Useful functions for projection of images and video. Source Settings Tools Zoom This function digitally enlarges projected images and video. Zoom • Align the cursor with the item name and enlarge or reduce the im- age with the cursor buttons (◀▶). - Page 59 * When finished with the enlargement operation, be sure to return the value Zoom to 100. Note The zoom condition will not be stored. The zoom condition will be cancelled automatically upon turning off the power or interrupting the input signal. E-59 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual...
-
Page 60: Timer Display
Using the Menu Simple Menu / Tools Useful functions for projection of images and video. Source Settings Tools Timer Display This function can provide a timer display on the screen for the timing of pre- sentations. By displaying a timer on the projection screen, the remaining time can be checked in an instant while giving the presentation. -
Page 61: Volume
Volume This is the volume adjustment of the speaker that is built into the projector. Volume • Align the cursor with the item name and adjust the volume with the cursor buttons (◀▶). E-61 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 62: Select Language
Using the Menu Simple Menu / Tools Useful functions for projection of images and video. Source Settings Tools Select Language This sets the language that is displayed in the menu displays and in the vari- ous message displays, etc. • Align the cursor with the Select Language item name and press the EN-... -
Page 63: Advanced Menu / Image
(◀▶). Item Name ◀ ▶ Brightness Darker Lighter Image becomes less Image becomes more Contrast dense dense Image becomes more Sharpness Image becomes softer distinct Sharpness Video/S-Video can be used only with input. E-63 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 64: Frequency Compensation
Using the Menu Advanced Menu / Image This permits fine video settings to be made. (Operate while the image that you would like to adjust or set is being projected.) Image View Color Input Admin Frequency Compensation This performs an adjustment when light and dark vertical bands appear on the screen. -
Page 65: Phase Control
On the other hand, setting Definition will result in a sharp image, and fine lines will appear distinct. E-65 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 66: Advanced Menu / View
Using the Menu Advanced Menu / View This permits fine video settings to be made. (Operate while the image that you would like to adjust or set is being projected.) Image View Color Input Admin Select Aspect Ratio This sets the aspect ratio of the input image. Select Aspect Ratio •... - Page 67 Zoom: Projects so as to fill the screen at 16:9, or only the 4:3 portion inside letterbox. (The protruding portion will be cut.) Select Aspect Ratio Auto Wide Zoom 4:3 Screen 16:9 Screen E-67 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual...
-
Page 68: Horizontal Position / Vertical Position
Using the Menu Advanced Menu / View This permits fine video settings to be made. (Operate while the image that you would like to adjust or set is being projected.) Image View Color Input Admin Horizontal Position / Vertical Position Adjusts the position when the screen picture is shifted vertically or horizontal- ly. -
Page 69: Advanced Menu / Color
Real: Performs a correction with emphasis on brightness. Note When is set in Custom Mode, the Gamma Correc- tion, Color Temperature, and White Level items will be displayed in gray, and selection and adjustment will not be possible. E-69 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 70: Color Temperature
Using the Menu Advanced Menu / Color This permits fine video settings to be made. (Operate while the image that you would like to adjust or set is being projected.) Image View Color Input Admin Color Temperature The screen is affected by illumination and other colors of external light. This function adjusts the white color which is the basic color of the video equipment, and raises the reproducibility of the color. -
Page 71: White Balance
Press “W” on the keyboard during the slideshow display and the screen will become white. (Press another key and the screen will return to the original condition.) Similarly, pressing “B” on the keyboard will result in the screen turning black. E-71 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 72: Color Space
Using the Menu Advanced Menu / Color This permits fine video settings to be made. (Operate while the image that you would like to adjust or set is being projected.) Image View Color Input Admin Color Space This function can adjust the color tone when the image is projected with a reddish or greenish quality at the time of a component signal input. -
Page 73: Hue
This function can adjust the hue of the projected image. • Align the cursor with the item name and adjust with the cursor but- tons (◀▶). ◀: Reddish ▶: Greenish can be used only with component signal/Video/S-Video input. E-73 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 74: Advanced Menu / Input
Using the Menu Advanced Menu / Input This function is used in setting the input signals of the input connectors. Image View Color Input Admin Usually, this should be set to Auto. See Page E-51. Only when identification is not possible with Auto, should the Input setting be made. -
Page 75: Advanced Menu / Admin
* Use the supplied security sheet and security la- • Make the setting using the cursor buttons (▲▼◀▶) of the remote control bels. or the projector control panel. Be sure to enter 4 digits. Continued on next page E-75 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... - Page 76 Using the Menu Advanced Menu / Admin This function can be used to make a security password setting or perform a check/reset of the lamp timer, etc. Image View Color Input Admin Example: Set password ◀▼▼▲ ∗ 1. A press of cursor button “◀” will result in an asterisk “ ”...
- Page 77 Continue by pressing the “▼” “▼” “▲” cursor buttons and asterisks “ ” will be placed in all 4 digit spaces. If the password matches, the display will disappear and the projector will enter a usable state. Continued on next page E-77 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual...
-
Page 78: Version
Using the Menu Advanced Menu / Admin This function can be used to make a security password setting or perform a check/reset of the lamp timer, etc. Image View Color Input Admin Canceling a Password / Changing a Password An operation with the menu is required to cancel or change a password. Canceling a password 1. -
Page 79: Lamp Timer
10 seconds, then the power will be switched off by the projector. When this condition has been reached, even pressing the POWER/STANDBY button will not turn on the power. Replace the lamp with a new one. E-79 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 80: Lamp Timer Reset
Using the Menu Advanced Menu / Admin This function can be used to make a security password setting or perform a check/reset of the lamp timer, etc. Image View Color Input Admin Lamp Timer Reset This resets the lamp timer. Be sure to perform the lamp timer reset operation when the lamp is replaced. -
Page 81: Initialize
Startup Screen • Align the cursor with the item name and switch between Logo None with the cursor buttons (◀▶). Logo: The logo (TAXAN) is displayed. None: The logo is not displayed. E-81 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... -
Page 82: Background Color
Using the Menu Advanced Menu / Admin This function can be used to make a security password setting or perform a check/reset of the lamp timer, etc. Image View Color Input Admin Background Color This function can set the screen color when Blank/Mute or other operations are performed. -
Page 83: Troubleshooting
Check the exhaust vents, and the ventilation slots. If clogged, clean them. Wait about 60 minutes until the temperature of the projector drops. If after having performed the above matters, the problem persists, contact the dealer or a TAXAN customer service center. E-83... -
Page 84: At A Time Such As This
Troubleshooting At a time such as this… Check the following matters before requesting servicing. Reference Problem Check Page E-33 Power does not turn on • Is the power cord plugged into a power outlet? E-88, 89 • Is the lamp cover properly mounted? •... - Page 85 See “When an indicator is lit or flashing”. E-83 flashing red E-75, 76 Even when the power is turned • The password is set. Please enter the correct password. on, only the display of “Please enter the password” is shown. E-85 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual...
-
Page 86: Maintenance
Maintenance Cleaning • Be certain to disconnect the power plug from the power outlet before cleaning. • Do not apply insecticide or other volatile chemicals to the projector or lens. Also, do not allow rubber or vinyl prod- ucts or the like to remain in contact with the projector for a long period. This will cause deterioration or peeling of the coating, etc. -
Page 87: Replacing The Lamp Cartridge
Do not touch them as the pieces of glass may cause injury. If this happens, contact your dealer or the store the projector was purchased. E-87 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... - Page 88 Maintenance Replacing the Lamp Cartridge Unplug the power cable. Turn the projector upside-down. Lay down a soft cloth or other material, and place the projector on top of it to aid in lamp replacement. After replacement, return the projector to its original condi- tion.
- Page 89 Lamp Timer Reset, and then press the Select under ENTER button. There will be a change to the initialization verification display. Now press the ENTER button. See “Lamp Timer Reset” for details on Page E-80. E-89 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual...
-
Page 90: Major Specifications
Major Specifications Specifications List Model KG-PS232Xh Optical Method of projection : DLP® (single DLP® chip) DLP® chip 0.55 inches 1024 × 768 dots Lamp 230 W high pressure mercury lamp Projection lens : Manual zoom ( × 1.15), Auto focus F = 2.45 – 2.62, f = 18.7 – 21.5 mm Image size Minimum 31.3 inch (at projection distance of 1.20 m / 3.9 feet telephoto) - Page 91 Specifications and design are subject to change without notice. *1 ISO 21118 conformance: Indicates the average value of mass produced articles, and the lower limit values at the time of shipping are 80% of the indicated values. E-91 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual...
- Page 92 Major Specifications Specifications List Model KG-PV131X Optical Method of projection : DLP® (single DLP® chip) DLP® chip 0.55 inches 1024 × 768 dots Lamp 200 W high pressure mercury lamp Projection lens : Manual zoom ( × 1.15), Manual focus F = 2.45 – 2.62, f = 18.7 – 21.5 mm Image size Minimum 31.3 inch (at projection distance of 1.20 m / 3.9 feet telephoto) Maximum 300 inch (at projection distance of 10.20 m / 33.46 feet wide)
- Page 93 Specifications and design are subject to change without notice. *1 ISO 21118 conformance: Indicates the average value of mass produced articles, and the lower limit values at the time of shipping are 80% of the indicated values. E-93 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual...
-
Page 94: Table Of Supported Frequency
○ : Supported frequency — : Not supported frequency KG-PS232Xh/KG-PS232X/KG-PV131X The display resolution is 1024 × 768 dots. When displaying a signal with resolutions other than 1024 × 768 dots such as 1280 × 1024, sizes of characters or lines may be uneven. -
Page 95: Cabinet Dimensions
Major Specifications Cabinet Dimensions KG-PS232Xh/232X 260 (10.2) KG-PV131X/131S 260 (10.2) Unit: mm (inch) E-95 KG-PS232Xh/232X | KG-PV131X/131S User’s Manual... - Page 96 2008, KAGA COMPONENTS CO., LTD.
