Go-On 757 Wireless Headphones User's Manual
Picture illustration
Transmitter
1. Reception Led
2. Power Led
3. Microphone
4. Transmission channel switch
5. Microphone audio output
6. 3.5mm audio in
7. 12V DC input jack
Headphone
8. Power Led
9. Power switch
10. Battery Compartment
11. Tuning Led
12. Tuning knob
13. Volume control
14. Audio in (For use in wired mode)
Installation
1. Transmitter – Connect the AC adapter with the transmitter. Connect the microphone cable between
the PC and the transmitter if you would like to have internet chat.
2. Receiver (Headphone) - Install the batteries into the headphone (2 x AAA).
Advertisement
Table of Contents
Related Manuals for Go-On 757
Summary of Contents for Go-On 757
- Page 1 Go-On 757 Wireless Headphones User’s Manual Picture illustration Transmitter 1. Reception Led 2. Power Led 3. Microphone 4. Transmission channel switch 5. Microphone audio output 6. 3.5mm audio in 7. 12V DC input jack Headphone 8. Power Led 9. Power switch 10.
- Page 2 Operation 1. Connect the audio source with the transmitter. You will see the Led light on when the signal is under transmission. 2. Turn on the headphone to receive the signals. Adjust the tuning knob (12) to get the best reception. 3.
