OPERATING INSTRUCTIONS USER MANUAL EVANS CUSTOM AMPLIFIERS, Inc. 2734 Woodbury Drive BURLINGTON, NC 27217 Phone/Fax (336) 270-5700 Web www.EvansAmps.com 04/01/2013... - Page 2 Through the years, the electronic design has been refined with new technology being embraced at every opportunity. Whether you play jazz guitar, steel guitar, finger style, rhythm or lead guitar, fiddle or keyboard, Evans will give you a tonal quality that is beyond compare.
-
Page 3: Operating Instructions
OPERATING INSTRUCTIONS Evans amplifiers are designed to reproduce the true sound of your instrument. You will find the controls easy to adjust by using the following outline to get you started. You may use the entire span of the control if necessary. For instance, there is no rule that says you must have the Reverb control at 6 or Bass at 3. -
Page 4: General Setup
PREAMP OUT: This is an unbalanced line out signal for driving a mixer board or an additional power amplifier. Lev el is independent of MASTER control. EXTERNAL SPEAKER: The output is used for driving an external 8 ohm speaker. For the AH200, the combined load of speakers should not be less than 4 ohms. - Page 5 Buzz Evans’ secret reverb setting for tube response: Switch to Reverb + Flange with Dwell CW just past center detent. NOTE: Flange is achieved by splitting the audio signal into two paths and introducing a variable phase shift in one path before recombining the signal.
- Page 6 DPU200 and AH200 Digital Power Unit The DPU200 and AH200 contain a digital power amplifier providing a maximum output of 200 Watts into 4 ohms. In addition, there is a transformer to supply the 28Vac for the preamplifier. Power Module The output is bridged and not referenced to common or circuit ground.
- Page 7 WARRANTY Evans Custom Amplifiers warrants this product to be free from defects in material and workmanship for a period of three years from the date of delivery to the original consumer purchaser. Evans Custom Amplifiers will pay all labor and material expenses for all repairs covered by this warranty. The Buyer is responsible for arranging its transportation for repair, risk of transport and payment of any shipping charges.
