User's Manual
WALL CONTROL
Part SRV7000-451
Mt. Vernon Pellet Appliances (AE)
EDGE™ 60 Pellet Fireplace
NOTICE
DO NOT DISCARD THIS MANUAL
Read, understand and
•
follow these instruc-
tions for safe installa-
tion and operation.
TABLE OF CONTENTS
7014-101F
Leave this manual with
•
party responsible for use
and operation.
CONTACT INFORMATION:
Hearth & Home Technologies
1445 North Highway, Colville, WA 99114
Division of HNI INDUSTRIES
Please contact your Quadra-Fire dealer with any questions or
concerns. For the number of your nearest Quadra-Fire dealer log
on to www.quadrafire.com
D. Main Menu
1. Set Comfort Level (Temperature) .......3
. Auto/Manual/Off ..................................4
2
3. Fuel Type ............................................4
4. Programming ......................................5
5. Set Day/Time ......................................4
6. User Settings ......................................6-7
E. Quick Start Guide ............................................8-9
F. Service Information .........................................10
G. Error Codes .....................................................10
H. Battery Back-up (Optional) ............................10
I. Troubleshooting Guide ....................................11
R
Portland
Tested and
O-T L
Oregon USA
Listed by
C
US
OMNI-Test Laboratories, Inc.
April 1, 2009
