- Page 1 Putron Electronics RGBHV Matrix Switchers System User Manual MRG Series ---RGBHV/Stereo Audio Matrix Switcher Please read this manual carefully before using this product.
- Page 2 Notice： This RGBHV Matrix Switchers User Manual takes example of the Matrix model MRG1616A. It can be used as user’s manual of other RGBHV matrix switcher models. This manual is only an instruction for operators, not for any maintenance usage.
-
Page 3: Safety Operation Guide
RGBHV/Stereo Audio Matrix Switcher Safety Operation Guide In order to ensure the credibility use of the product and the user’s safety, please comply with the following items during installation and maintenance: The system must be earthed properly. Please do not use two blades plugs and ensure the alternating power supply ranged from 100v to 240v and from 50Hz to 60Hz. -
Page 4: Table Of Contents
RGBHV/Stereo Audio Matrix Switcher Contents 1. INTRODUCTION ..........................1 1.1 About MRG Matrix Switcher System ..................1 1.2 MRG Matrix Switcher Models ....................1 2. PACKING OF THE PRODUCT ......................2 3. INSTALLATION ..........................3 4. FRONT VIEW AND REAR VIEW OF THE PRODUCT ............... 4 4.1 Front View of the MRG82A、MRG84A、MRG88A .............. -
Page 5: Introduction
MRG series Matrix switcher is a high-performance professional computer and audio signal switcher that can be used for cross switching of multi computer and audio signal. Independent RGBHV component and balance/unbalance I/O terminals make each component signal transmit and switch separately; this design can reduce attenuation of signal transmission to minimum and output the image and audio signal in high-fidelity quality. -
Page 6: Packing Of The Product
RGBHV/Stereo Audio Matrix Switcher RS232 Specifications Video Inputs Video Outputs Audio Inputs Audio Outputs Interface Models MRG168 × × √ MRG168A √ MRG1616 × × √ MRG1616A √ MRG248 × × √ MRG248A √ MRG2416 × × √ MRG2416A √... -
Page 7: Installation
RGBHV/Stereo Audio Matrix Switcher RS-232 Communication Cord Power Supply Cord CD with Application SWITCHER 2.0 3. Installation MRG matrix switchers adopt metal shell and can be stacked with other device. Moreover, they are rack-mountable enclosure and can be installed in the standard 19 inches case. -
Page 8: Front View And Rear View Of The Product
RGBHV/Stereo Audio Matrix Switcher 4. Front View and Rear View of the Product 4.1 Front View of the MRG82A、MRG84A、MRG88A 4.2 Rear View of the MRG82A、MRG84A、MRG88A www.putron.com Putron Electronics Limited... -
Page 9: Front View Of The Mrg164A、Mrg168A
RGBHV/Stereo Audio Matrix Switcher 4.3 Front View of the MRG164A、MRG168A 4.4 Rear View of the MRG164A、MRG168A www.putron.com Putron Electronics Limited... -
Page 10: Front View Of The Mrg1616A
RGBHV/Stereo Audio Matrix Switcher 4.5 Front View of the MRG1616A 4.6 Rear View of the MRG1616A www.putron.com Putron Electronics Limited... -
Page 11: External Connection
RGBHV/Stereo Audio Matrix Switcher Some more models: MRV 24 channels series MRV 32 channels series MRV 48 channels series MRV 64 channels series MRV 96 channels series MRV128 channels series Please contact us for more information: info@putron.com or visit website: www.putron.com... -
Page 12: Connection With Control Systems
BNC connector R(red)、G（green） 、B（blue） 、H（horizontal） 、V（vertical）carefully. Attention: Please make sure the RGBHV connectors from the source and to the destination should be in the same order, otherwise it world cause color loss or no output signal at all. - Page 13 RGBHV/Stereo Audio Matrix Switcher Audio signal connection: “AUDIO INPUT”, “AUDIO OUTPUTS” audio network interface in RGBHV matrix switchers can be connected to the audio signal and amplify of the DVD player. Audio connection is little complicated than video. It has two kinds of connection: balanced and unbalanced.
-
Page 14: Operation Of The Control Panel
RGBHV/Stereo Audio Matrix Switcher 6. Operation of the Control Panel 6.1 Front Panel Description “AV” AV synchronal button: To transfer video and audio signal synchronously by the switcher Example: To transfer both the video and the audio signals from input channel No.3 to output channel No.4. -
Page 15: Usage Of The Remote Controller
RGBHV/Stereo Audio Matrix Switcher 3,Press the button for the first output channel number “3” 4, Press the button for the second output channel number “4” Then, switching OK ! audio/video switching from “1” to “3” and “4” 7. Usage of the Remote Controller With the infrared remote controller, the matrix switcher could be control remotely. -
Page 16: Communication Protocol And Command Codes
RGBHV/Stereo Audio Matrix Switcher 8. Communication Protocol and Command Codes With this command system, the RS232 software is able to control and operate the MRG Matrix with remotely. Communication protocol: Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none... - Page 17 RGBHV/Stereo Audio Matrix Switcher Save[Y]. Save the present operation to the preset command [Y]. [Y] ranges from 0 to 9. Recall[Y]. Recall the preset command [Y]. Clear[Y]. Clear the preset command [Y]. Note: 1. [x1], [x2], [x3] and [x4] are the symbols of input or output channels ranged according to the model of the matrix switcher.
-
Page 18: Technical Specifications
5nS(±1nS) delay 200 ns (Max) Switching speed RGBHV，RGBS， RGsB， RsGsBs， HDTV， Component video，S-video， Composite video Signal type Input video BNC female Connector 1V p-p Y component video、S-video，composite video； 0.7V p-p RGB；0.3V p-p R-Y & B-Y Signal strength component video、... - Page 19 RGBHV/Stereo Audio Matrix Switcher Models Matrix MRG8 Series Matrix MRG16 Series Matrix MRG64、48 Series Specifications Maximum/Minimum Analog signals: 0.5V ~ 2.0V p-p level 75 Ω Impedance -30dB@5MHz Echo loss 15mV Max error in DC offset Output video BNC female Connector Maximum/Minimum 2.0V p-p...
-
Page 20: Troubleshooting & Maintenance
When there is a color losing or no video signal output, it may be the unmatched RGBHV connector order between the input and output end. - Page 21 RGBHV/Stereo Audio Matrix Switcher signal input, it may be the input connection cord broken or the connectors loosen. Check with oscilloscope or multimeter if there is any signal at the output end. If there is no signal output, it may be the output connection cord broken or the connectors loosen.
