SRS Airbags & Seat Belt Pretensioners
Standard Equipment
•
Electronic frontal impact sensors (2) are mounted in the engine
compartment as illustrated on the following page.
•
Front seat belt pretensioners are mounted near the base of the B-pillar
•
A frontal dual stage airbag for the driver
wheel hub.
•
A frontal dual stage airbag for the front passenger
deploys through the top of the dashboard.
•
The SRS computer is mounted on the floor pan underneath the center
console. It also contains an impact sensor.
•
Front electronic side impact sensors (2) are mounted near the base of the
B-pillars .
•
Rear electronic side impact sensors (2) are mounted near the base of the
C-pillars .
•
Front seat side impact airbags
•
Side curtain airbags are mounted along the outer edge inside the roof
rails.
•
A driver front knee airbag
of the dash.
NOTES:
The front seatback mounted side impact airbags and the side curtain
airbags may deploy independently of each other.
The driver knee airbag deploys simultaneously with the driver frontal
airbag. The seat belt pretensioners may also deploy when the frontal
airbags deploy.
The CAMRY hybrid is equipped with a standard front passenger occupant
classification system that may prohibit the deployment of the passenger
frontal airbag, seatback mounted side impact airbag, and seat belt
pretensioner. If the passenger occupant classification system prohibits
deployment during an SRS event, the passenger SRS will not re-arm nor
deploy.
is mounted in the steering
is integrated into and
are mounted in the seatbacks.
is mounted on the driver side lower portion
WARNING:
.
The SRS may remain powered for up to 90 seconds after the vehicle is
shut off or disabled. To prevent serious injury or death from
unintentional SRS deployment, avoid crushing, cutting or breaching the
SRS components.
Driver Knee Airbag, Frontal, Font Seatback Mounted Side, and Side
15
- -
Curtain Airbags
Driver Knee Airbag
