Summary of Contents for Altusen KL1100
- Page 1 Dual Rail LCD PS/2 - USB Console KL1100 User Manual www.aten.com...
-
Page 2: Fcc Information
KL1100 User Manual FCC Information This is an FCC Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 3: User Information
KL1100 User Manual User Information Online Registration Be sure to register your product at our online support center: International http://support.aten.com North America ATEN TECH http://www.aten-usa.com/product_registration ATEN NJ http://support.aten.com Telephone Support For telephone support, call this number: International 886-2-8692-6959 North America... -
Page 4: Package Contents
Copyright © 2008 ATEN® International Co., Ltd. Manual Part No. PAPE-0275-1AXG Manual Date:2008-07-22 Altusen and the Altusen logo are registered trademarks of ATEN International Co., Ltd. All rights reserved. All other brand names and trademarks are the registered property of their respective owners. -
Page 5: Table Of Contents
KL1100 User Manual Contents FCC Information ..........ii SJ/T 11364-2006. - Page 6 KL1100 Models........
-
Page 7: About This Manual
KL1100 User Manual About This Manual This User Manual is provided to help you get the most from your KL1100 system. It covers all aspects of installation, configuration and operation. An overview of the information found in the manual is provided below. -
Page 8: Conventions
KL1100 User Manual Conventions This manual uses the following conventions: Indicates text that you should key in. Monospaced Indicates keys you should press. For example, [Enter] means to press the Enter key. If keys need to be chorded, they appear together in the same bracket with a plus sign between them: [Ctrl+Alt]. -
Page 9: Chapter 1 Introduction
Introduction Overview The KL1100 is a series of KVM Console modules featuring an integrated 17" or 19" LCD panel, a full keyboard, and a touch pad in a 1U rack-mountable sliding housing with AC or DC based input power sources. -
Page 10: Features
Standard 105-key keyboard; Sun keyboard emulation Dual rail design allows LCD monitor and keyboard/touch pad modules to operate independently Compatible with all ATEN KVM Switches and most other KVM switches Adjustable depth to fit within the rack Firmware upgradeable Supports Microsoft Intellimouse (5 keys) Supports Logitech and Microsoft wireless mice Console lock –... -
Page 11: Requirements
USB or PS/2 keyboard and mouse If you install an external console and wish to extend the distance between it and the KL1100, CS Custom extender cables are available in various lengths. Contact your dealer for details. Cables... -
Page 12: Operating Systems
KL1100 User Manual Operating Systems Supported operating systems are shown in the table, below. Version Windows NT and higher Linux RedHat 7.1 and higher SuSE 9.0 and higher Mandriva (Mandrake) 9.0 and higher UNIX 4.3 and higher FreeBSD 4.2 and higher... -
Page 13: Components
Chapter 1. Introduction Components Front View Component Description Upper Handle Pull to slide the LCD module out; push to slide the module in. See Opening the Console, page 15, for details on sliding the console in and out. LCD Module See LCD Module, page 7. -
Page 14: Keyboard Module
Reset Button Pressing and holding this button while powering on the unit causes the KL1100 to revert to the original factory installed firmware version – allowing you to recover from a failed firmware upgrade. -
Page 15: Lcd Module
LCD monitor is off to indicate that only the monitor is off – not the KVM switch itself.) Firmware The Firmware Upgrade Cable that transfers the firmware upgrade data from the administrator's computer to the KL1100 Upgrade Port plugs into this RJ-11 connector. Firmware During normal operation and while performing a firmware upgrade, this switch should be in the NORMAL position. -
Page 16: Rear View (Ac Power)
KVM console. The external console's keyboard, monitor, and mouse cables plug in here. KVM Port The cable linking the KL1100 to a computer or switch plugs in Section here. Note: The shape of this SPHD connector has been... -
Page 17: Rear View (Dc Power)
KVM console. The external console's keyboard, monitor, and mouse cables plug in here. KVM Port The cable linking the KL1100 to a computer or switch plugs in Section here. Note: The shape of this SPHD connector has been... - Page 18 KL1100 User Manual This Page Intentionally Left Blank...
-
Page 19: Chapter 2. Hardware Setup
You must unplug the power cords of any computers that have the Keyboard Power On function. 3. Packing material has been inserted to protect the KL1100 during shipping. Slide the LCD module out (see Opening the Console, page 15), until the packing material is visible. -
Page 20: Standard Rack Mounting
KL1100 User Manual Standard Rack Mounting A standard rack mounting kit can be purchased separately for your KL1100. The kit enables the KL1100 to be mounted in rack with a depth of 42–77 cm. L Brackets Side Mountng Brackets Note: 1. It takes two people to mount the switch: one to hold it in place, the other to screw it in. - Page 21 Chapter 2. Hardware Setup To rack mount the KL1100, do the following: 1. While one person positions the KL1100 in the rack and holds it in place, the second person loosely screws the front brackets to the rack. 2. While the first person still holds the KL1100 in place, the second person...
-
Page 22: Connecting Up
Console. The ports are color coded and marked with an icon for easy identification. 4. Connect the KL1100 to a power source. For AC power models, plug the power cord into the LCD Console's power socket and into a power source. -
Page 23: Chapter 3. Operation
Chapter 3 Operation Opening the Console The KL1100's console consists of two modules: an LCD display module located under the top cover; and a keyboard / touch pad module below the LCD module. The modules can either slide together, or independently. This allows you to have the LCD display available for viewing while the keyboard / touch pad module is conveniently out of the way when not in use. - Page 24 KL1100 User Manual (Continued from previous page.) 2. Pull the top panel all the way out until it clicks into place. 3. Rotate the top panel all the way back to expose the LCD screen.
-
Page 25: Opening Together
Chapter 3. Operation 4. Reach underneath and pull the keyboard module all the way out until it clicks into place. Opening Together Refer to the diagrams in the Opening Separately section as you do the following: 1. Pull the release catch and pull the top and bottom panels out until the keyboard module clicks into place. -
Page 26: Operating Precautions
KL1100 User Manual Operating Precautions The maximum load bearing capacity of the keyboard module is 30kg. Failure to heed the information below can result in damage to the keyboard module. RIGHT Rest your hands and arms lightly on the keyboard module as you work. -
Page 27: Closing The Console
Chapter 3. Operation Closing the Console 1. Pull the release catches located on either side of the keyboard toward you to release the keyboard module, then slide the module slightly in. 2. Let go of the catches. Using the front handle, push the keyboard module all the way in. - Page 28 KL1100 User Manual (Continued from previous page.) 3. Rotate the LCD module all the way down, then pull the rear catches to release the LCD module. 4. Using the front handle, push the module all the way in.
-
Page 29: Hot Plugging
KL1100. Powering Off and Restarting If it becomes necessary to Power Off the KL1100 (to upgrade the firmware, for example), simply turn off the power to the unit using the rear panel power switch. -
Page 30: Lcd Osd Configuration
KL1100 User Manual LCD OSD Configuration The LCD Buttons The LCD OSD allows you to set up and configure the LCD display. Four buttons are used to perform the configuration, as described in the table, below: Button Function MENU When you have not entered the LCD OSD Menu function, pressing this button invokes the Menu function, and brings up the Main Menu. -
Page 31: Lcd Adjustment Settings
Chapter 3. Operation LCD Adjustment Settings An explanation of the LCD OSD adjustment settings is given in the table below: Setting Explanation Brightness Adjusts the background black level of the screen image. Contrast Adjusts the foreground white level of the screen image. Phase If pixel jitter or horizontal line noise is visible on the display, your LCD may have the wrong phase setting. -
Page 32: Console Selection
Note: 1. Press the keys in sequence - one key at a time. First [Ctrl], then [Alt], then [Shift], etc. 2. Console selections are not saved. If the KL1100 is powered off, it reverts to the default setting of both consoles enabled when it is powered on again. -
Page 33: Chapter 4. Firmware Upgrade
Before You Begin To prepare for the firmware upgrade, do the following: 1. From a computer that is not part of your KL1100 installation go to ATEN’s Internet support site and choose the model name that relates to your device to get a list of available Firmware Upgrade Packages. -
Page 34: Firmware Upgrade Mode
Firmware Upgrade Recovery Switch (see page 7) must be set to the Normal position. 1. Turn off the power to the KL1100 using the power switch located on the back side of the console. 2. Slide the firmware switch to RECOVER (see page 7). -
Page 35: Performing The Upgrade
Performing the Upgrade Starting the Upgrade: 1. With the KL1100 in Firmware Upgrade Mode, run the downloaded Firmware Upgrade Package file from your computer - either by double clicking the file icon, or by opening a command line and keying in the full path and filename. - Page 36 KL1100 User Manual (Continued from previous page.) 3. Click Next. The Firmware Upgrade Utility main screen appears: The Utility inspects your installation. All the devices capable of being upgraded by the package are listed in the Device List panel. 4. Click Next to perform the upgrade.
-
Page 37: Upgrade Succeeded
Chapter 4. Firmware Upgrade Upgrade Succeeded: After the upgrade has completed, a screen appears to inform you that the procedure was successful: Click Finish to close the Firmware Upgrade Utility. -
Page 38: Upgrade Failed
KL1100 User Manual Upgrade Failed: If the upgrade failed to complete successfully the Upgrade Failed screen appears: Click Cancel to close the Firmware Upgrade Utility. See the next section, Firmware Upgrade Recovery, for how to proceed. -
Page 39: Firmware Upgrade Recovery
1. Slide the Firmware Upgrade Recovery Switch (see page 7) to the Recover position. 2. Power off and restart the KL1100 according to the instructions given in the Powering Off and Restarting section (see page 21). 3. Slide the Firmware Upgrade Recovery Switch back to the Normal position. - Page 40 KL1100 User Manual This Page Intentionally Left Blank...
-
Page 41: Appendix
Appendix Safety Instructions General Read all of these instructions. Save them for future reference. Follow all warnings and instructions marked on the device. Do not place the device on any unstable surface (cart, stand, table, etc.). If the device falls, serious damage will result. Do not use the device near water. - Page 42 KL1100 User Manual (Continued from previous page.) If an extension cord is used with this device make sure that the total of the ampere ratings of all products used on this cord does not exceed the extension cord ampere rating. Make sure that the total of all products plugged into the wall outlet does not exceed 15 amperes.
-
Page 43: Dc Power
Appendix DC Power The system relies on the protective devices in the building installation for protection against short-circuit, overcurrent, and earth (grounding) fault. Ensure that the protective devices in the building installation are properly rated to protect the system, and that they comply with national and local codes. -
Page 44: Rack Mounting
KL1100 User Manual Rack Mounting Before working on the rack, make sure that the stabilizers are secured to the rack, extended to the floor, and that the full weight of the rack rests on the floor. Install front and side stabilizers on a single rack or front stabilizers for joined multiple racks before working on the rack. -
Page 45: Technical Support
Online Technical Support http://support.aten.com Support Troubleshooting http://www.aten.com Documentation Software Updates Telephone Support 886-2-8692-6959 North America Email Support ATEN TECH support@aten-usa.com ATEN NJ sales@aten.com Online Technical Support ATEN TECH http://www.aten-usa.com/support Support ATEN NJ http://support.aten.com Troubleshooting ATEN TECH http://www.aten-usa.com Documentation ATEN NJ http://www.aten.com... -
Page 46: Specifications
KL1100 User Manual Specifications AC Power Models Function 17” LCD 19” LCD Computer Connections Console Selection Hotkey External Keyboard 1 x 6-pin Mini-DIN Female (Purple) Console Ports 1 x USB Type A Female (Black) Video 1 x HDB-15 Female (Blue) -
Page 47: Dc Power Models
Appendix DC Power Models Function 17” LCD 19” LCD Computer Connections Console Selection Hotkey External Keyboard 1 x 6-pin Mini-DIN Female (Purple) Console Ports 1 x USB Type A Female (Black) Video 1 x HDB-15 Female (Blue) Connectors Mouse 1 x 6-pin Mini-DIN Female (Green) 1 x USB Type A Female (Black) KVM Ports 1 x SPHD-18 Female (Yellow) -
Page 48: Optional Rack Mounting
12. While it takes two people to perform a standard installation, with an Easy- Installation, kit, one person can mount the KL1100. To install the Easy- Installation kit, do the following: 1. Remove the standard sliding L brackets (not shown) and the side mounting brackets from both sides of the KL1100. - Page 49 Appendix 2. Attach the left and right easy-installation mounting rails to the inside of the rack. The flange that supports the KL1100 will be to the inside. Rear Flange Slide Bar Front Flange Rear Attachment Sliding Bracket LEFT Support Flange...
- Page 50 (Continued from previous page.) 3. Slide the KL1100 onto the support flanges. Use the screws supplied with this package to loosely attach the front of the KL1100 to the front of the rack (only tighten the screws part way). Phillips I head M4L6 4.
- Page 51 Appendix 5. Slide the KL1100 open and closed a couple of times to be sure that it is properly aligned and operating smoothly. (See Opening the Console, page 15, for opening and closing procedures.) 6. After determining that the KL1100 is lined up and operating correctly,...
-
Page 52: Sun Keyboard Emulation
KL1100 User Manual Sun Keyboard Emulation The PC compatible (101/104 key) keyboard can emulate the functions of the Sun keyboard when the Control key [Ctrl] is used in conjunction with other keys. The corresponding functions are shown in the table below. -
Page 53: Troubleshooting
KVM cables that we have designed to work with this product can be connected. KL1100 Models There are four models in the KL1100 series. Options include integrated 17” or 19” LCD panels and AC or DC based input power sources. Model... -
Page 54: Limited Warranty
KL1100 User Manual Limited Warranty ALTUSEN warrants this product against defects in material or workmanship for a period of one (1) year from the date of purchase. If this product proves to be defective, contact ALTUSEN's support department for repair or replacement of your unit. ALTUSEN will not issue a refund. - Page 55 Index AC Power Models Keyboard Emulation, 44 Specifications, 38 KL1100 Front View, 5 Keyboard Module, 6 Closing the Console, 19 LCD Module, 7 Connecting Up, 14 Models, 45 Console Rear View (AC Power), 8 Closing, 19 Rear View (DC Power), 9...
- Page 56 KL1100 User Manual Safety Instructions Technical Support, 37 DC Power, 35 Telephone support, iii General, 33 Troubleshooting, 45 Rack Mounting, 36 SJ/T 11364-2006, ii Specifications, 38 User Notice, iii AC Power Models, 38 DC Power Models, 39 SPHD Connectors, 45...
