VMB070 – USER GUIDE

Advertisement

Table of Contents
loading

Related Manuals for Vizio VMB070

Summary of Contents for Vizio VMB070

  • Page 1 VMB070 – USER GUIDE...
  • Page 2 Welcome! Congratulations on your new VIZIO VMB070 7" LED LCD Portable TV. To get the most out of your new VIZIO product, read these instructions before using your product and retain them for future reference. For assistance, call 1-877-MYVIZIO (1-877-849-4623), or contact us at www.VIZIO.com/support.

  • Page 3: Important Safety Instructions

    Important Safety Instructions Your DTV is designed and manufactured to operate within defined design limits. Misuse may result in electric shock or fire. To prevent your DTV from being damaged, the following instructions should be observed for the installation, use, and maintenance of your DTV. Read the following safety instructions before operating your DTV. Keep these instructions in a safe place for future reference.

  • Page 4: Television Antenna Connection Protection

    • Do not attempt to repair or service your DTV yourself. Opening or removing the back cover may expose you to high voltages, electric shock, and other hazards. If repair is required, contact your dealer and refer all servicing to qualified service personnel. • Keep your DTV away from moisture. Do not expose your DTV to rain or moisture. If water penetrates into your DTV, unplug the power cord and contact your dealer. Continuous use in this case may result in fire or electric shock. • Do not use your DTV if any abnormality occurs. If any smoke or odor becomes apparent, unplug the power cord and contact your dealer immediately. Do not try to repair your DTV yourself. • Avoid using dropped or damaged appliances. If your DTV is dropped and the housing is damaged, the internal components may function abnormally. Unplug the power cord immediately and contact your dealer for repair. Continued use of your DTV may cause fire or electric shock.

  • Page 5: Dtv Transition Advisory

    Power Lines Do not locate the antenna near overhead light or power circuits, or where it could fall into such power lines or circuits. Remember, the screen of the coaxial cable is intended to be connected to earth in the building installation. DTV Transition Advisory The nationwide switch to digital television broadcasting will be complete on June 12, 2009, but your local television stations may switch sooner.

  • Page 6: Package Contents

    Package Contents Your VIZIO product has been carefully packed in a cardboard carton designed to protect it from damage. When you have opened the package, check that all of the contents are included and are in good condition. Remote Control 7”...

  • Page 7: Chapter 1: Controls And Connections

    Chapter 1: Controls and Connections Before setting up your TV, take a few moments to familiarize yourself with the various controls and connections. This will make the setup much faster and your experience with the TV much more enjoyable! RF Adapter Port USB Port Composite AV Port On/Off Switch...
  • Page 8 Headphone Port Power Adapter Port Left Side Detail Headphone Port Connect headphones, earbuds, or external speakers. Power Adapter Port Connect the Power Adapter. Power/Standby Kickstand Back/Top Detail Power/Standby Turn the DTV on or off. If the DTV is being powered by the battery, then the On/Off Switch (see Right Side Detail) must be in the ON position for this button to work.
  • Page 9 Using the Touch-Sensitive Controls The touch-sensitive controls are located below the screen. When the DTV is on, the controls light up. Menu Channel Up/Down Volume Up/Down Touch-Sensitive Controls To use the touch-sensitive controls, place the tip of your finger on one of the lit control symbols. Do not push on the controls forcefully—make complete contact with your finger and the DTV will respond. The touch-sensitive controls will not function properly if you try to use them while wearing gloves.

  • Page 10: Using The Remote Control

    Using the Remote Control Your new TV includes a remote that allows you to control the TV from a distance. To use the remote, point it at the DTV screen and press a button. • There should be no obstacles between the remote control and the TV screen. • The effective range of the remote control is approximately 30 feet.
  • Page 11 Remote Control Buttons Power/Standby Turn the DTV on or off. If the DTV is being powered by the battery, then the On/Off Switch (see Right Side Detail) must be in the ON position for this button to work. Info Display channel information, time, and battery status. Arrow Use the Arrow buttons to navigate the on-screen menu and channel guides.
  • Page 12 • Use only a quality battery. • Inserting the battery incorrectly may result in cracking or leakage that may cause a fire or result in injury. • Dispose of old or dead batteries in accordance with local hazardous waste regulations. • Keep batteries away from children and pets.

  • Page 13: Chapter 2: First-Time Setup

    Chapter 2: First-Time Setup Before you start using your TV, you will need to complete the first-time setup. To make this easy, VIZIO has included a Setup Wizard that helps you complete the process. The Setup Wizard automatically starts the first time you turn on the TV. To prepare the TV for first-time setup: 1. Connect the power adapter to the power port on the 2. Plug the power adapter into an electrical outlet.
  • Page 14 4. Remove the plastic tab from the remote. 5. Swing the paddle out. 6. Gently pull the paddle away from the body of the TV. 7. Swing the paddle up.
  • Page 15 8. Gently pull the antenna from the paddle until it is fully extended. 9. Place the DTV on a flat surface in an open area (for the best reception).
  • Page 16 Completing the First-Time Setup with the Setup Wizard 1. Press the Power/Standby button on the remote. The TV powers on and the Setup Wizard starts. 2. Use the Up/Down Arrow buttons to select your preferred language, then press Right Arrow. 3. Use the Up/Down Arrow buttons to select your time zone, then press Right Arrow.
  • Page 17 5. Wait until the channel scan is 100% complete, then press Right Arrow. 6. Press EXIT.

  • Page 18: Chapter 3: Connecting Your Devices To The Tv

    Chapter 3: Connecting Your Devices to the TV Your DTV can be easily connected to an external device: • DVD or Blu-Ray player • Video game console • Cable box • External antenna • Or other device To connect an external device to the TV, you must first verify that the external device has one of the following types of ports: RF Port Composite Ports Connecting a Device with an RF Port...
  • Page 19 2. Connect the other end of the coaxial cable to the RF port on the RF adapter. 3. Connect the RF adapter to the RF port on the side of the TV. If you are connecting a device that uses channel information, such as an external antenna or a cable TV connection (directly from the wall outlet), you may need to perform a channel scan.
  • Page 20 Connecting a Device with Composite Ports To connect a device with composite ports, use the included composite AV cable. 1. Connect the yellow, red, and white compsite connectors on the compsite AV cable to the corresponding yellow, red, and white compsite ports on your external device. 2.

  • Page 21: Chapter 4: Using The Tv As A Digital Photo Frame

    Chapter 4: Using the TV as a Digital Photo Frame Your TV can be used to display and share digital photos. For the TV to display your photos correctly: • You must load your photos on a USB storage device. • Your USB storage device must be formatted for FAT32. • The photos must be in JPG format. • The maximum file size of each photo must not exceed 4MB.
  • Page 22 4. Use the Up/Down Arrow buttons to select a JPG file, then press OK. 5. Use the Left/Right Arrows to view the next photo. 6. Press MENU to begin the slideshow. Do not disconnect the USB storage device while the TV is on.

  • Page 23: Chapter 5: Using The On-Screen Menu

    Chapter 5: Using the On-Screen Menu Your TV features an easy-to-use on-screen menu. To open the on-screen menu, press the MENU button on the remote. From this menu, you can: • Change the input source • Adjust the TV settings • Activate the sleep timer • Turn closed-captioning on or off • Display the digital channel guide While navigating the on-screen menu, you can press the BACK button at any time to return to the...

  • Page 24: Adjusting Tv Settings

    2. Use the Left/Right Arrow buttons on the remote (or the - / + controls on the TV) to highlight the Inputs icon and press OK. The Input Source menu is displayed. 3. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight the input source you wish to display and press OK.
  • Page 25 Changing the Screen Mode Your TV can display images in two different screen modes: Normal and Wide. To change the screen mode: 1. Press the MENU button on the remote (or the MENU control on the TV). The on-screen menu is displayed. 2.
  • Page 26 4. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight either Normal or Wide and press OK. • Normal screen mode preserves an original 4:3 aspect ratio. Since the 4:3 aspect ratio is not large enough to fill the TV’s screen, black bars are added to the left and right of the display image. •...
  • Page 27 3. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight Picture Settings and press OK. The Picture Settings menu is displayed. 4. Use the Left/Right Arrow buttons on the remote (or the - / + controls on the TV) to change the picture mode: • Standard mode sets the various picture settings to values that will produce the best picture in the most cases.

  • Page 28: Adjusting The Tuner Settings

    Adjusting the Tuner Settings The Tuner Settings Menu can be used to make adjustments when the TV is receiving channels from the Antenna or RF input. Changing the Tuner Mode If you are using a device that is connected to the RF input, such as an external antenna or cable TV connection, you must change the tuner mode. To change the tuner mode: 1.

  • Page 29: Scanning For Channels

    4. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight Tuner Mode and press OK. The Tuner Mode menu is displayed. 5. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight the correct tuner mode: • If you are using an external antenna, select Antenna and press OK. • If you are using a cable TV connection, select Cable and press OK.
  • Page 30 2. Use the Left/Right Arrow buttons on the remote (or the - / + controls on the TV) to highlight the Settings icon and press OK. The TV Settings menu is displayed. 3. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight Tuner Settings and press OK.
  • Page 31 Skipping Channels After a channel scan is completed, you may find that some channels are too weak to watch comfortably. There may also be some channels you do not want to view. You can remove these channels from the TV’s memory with the Skip Channel feature. Channels that have been removed with the Skip Channel feature can still be viewed if the channel is entered using the Number Pad.
  • Page 32 4. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight Skip Channel and press OK. The Skip Channel menu is displayed. 5. For each channel you wish to remove, use the Up/ Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight the channel and press OK. An X appears to the right of each channel you select.
  • Page 33 Changing the Audio Language Some digital free-to-air and cable channels broadcast programs in more than one language. The TV’s Digital MTS (Multichannel Television Sound) feature allows you to listen to audio in your preferred language. Not all programs are broadcast in multiple languages. The Digital MTS feature only works when the program being viewed is being broadcast in the language you select.
  • Page 34 4. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight Digital MTS and press OK. The Digital MTS menu is displayed. 5. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight your preferred language (English, French, or Spanish) and press 6. Press EXIT to close the on-screen menu.

  • Page 35: Using The Parental Controls

    Using the Parental Controls The TV’s parental controls allow you to prevent the TV from displaying certain channels or programs without a password. To access the parental controls: 1. Press the MENU button on the remote (or the MENU control on the TV). The on-screen menu is displayed. 2.
  • Page 36 Enabling or Disabling Program Ratings To manage program content according to its rating, you must enable the Program Rating feature. To enable program ratings: 1. Press the MENU button on the remote (or the MENU control on the TV). The on-screen menu is displayed. 2.
  • Page 37 5. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight Rating Enable. 6. Use the Left/Right Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV): • To enable program ratings, change the setting to On. • To disable program ratings, change the setting to Off.
  • Page 38 Locking and Unlocking Channels When a channel is locked, it will be inaccessible. Locking a channel is a good way to prevent children from viewing inappropriate material. To lock or unlock a channel: 1. Press the MENU button on the remote (or the MENU control on the TV).
  • Page 39 5. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight Channel Locks and press OK. The Channel Locks menu is displayed. 6. For each channel you wish to lock or unlock, use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight the channel and press OK.
  • Page 40 Blocking and Unblocking TV Program Content by Rating A channel may sometimes broadcast programs that are meant for children, and at other times broadcast programs that are meant for mature audiences. You may not want to block the channel completely using a channel lock, but you may wish to block certain programs from being viewed. When this is the case, you can use the TV’s Rating Block feature to block content based on its rating.
  • Page 41 4. Enter your passcode. (If you have not yet changed the passcode, enter the default: 0000.) The Parental Controls menu is displayed. 5. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the DTV) to highlight TV and press OK. The TV menu is displayed with a list of rating types.
  • Page 42 Blocking and Unblocking Movies by Rating A channel may sometimes broadcast movies that are meant to be viewed by children, and at other times broadcast movies meant to be viewed by mature viewers. You may not want to block the channel completely using a channel lock, but you may wish to block certain movies from being viewed.
  • Page 43 4. Enter your passcode. (If you have not yet changed the passcode, enter the default: 0000.) The Parental Controls menu is displayed. 5. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight Movie and press OK. The Movie menu is displayed with a list of rating types.
  • Page 44 Blocking and Unblocking Unrated Content Not all content is rated. You may want to block unrated content, as it may or may not be appropriate for all audiences. To block or unblock unrated content: 1. Press the MENU button on the remote (or the MENU control on the TV).
  • Page 45 5. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight Block Unrated Shows. 6. Use the Left/Right Arrow buttons on the remote (or the - / + controls on the TV): • To block unrated content, change the setting to On. Unrated content cannot be viewed. • To unblock unrated content, change the setting to Off.
  • Page 46 3. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight Parental Controls and press OK. 4. Enter your passcode. (If you have not yet changed the passcode, enter the default: 0000.) The Parental Controls menu is displayed. 5. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight Change PIN.
  • Page 47 Resetting Content Locks to the Default Settings To reset the content locks to the factory-default settings: 1. Press the MENU button on the remote (or the MENU control on the TV). The on-screen menu is displayed. 2. Use the Left/Right Arrow buttons on the remote (or the - / + controls on the TV) to highlight the Settings icon and press OK.

  • Page 48: Changing The On-Screen Menu Language

    5. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight Reset Locks. The on-screen menu displays “LOCK SETTINGS back to the factory defaults?” 6. Use the Left/Right Arrow buttons on the remote (or the - / + controls on the TV) to highlight YES. Press OK.

  • Page 49: Setting The Time Zone

    3. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight Menu Language and press OK. The Menu Language menu is displayed. 4. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight your preferred language (English, French, or Spanish). Press OK. Setting the Time Zone To ensure the correct time is displayed when you press the INFO button, set the TV’s time zone. To set the time zone: 1.
  • Page 50 3. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight Time & Local Settings and press OK. 4. Use the Left/Right Arrow buttons on the remote (or the - / + controls on the TV) to select your time zone. Press the EXIT button on the remote. Resetting the TV to Default Settings All of the on-screen menu settings can be reset to the factory defaults.
  • Page 51 2. Use the Left/Right Arrow buttons on the remote (or the - / + controls on the TV) to highlight the Settings icon and press OK. The TV Settings menu is displayed. 3. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the DTV) to highlight Reset. Press OK.

  • Page 52: Running The Setup Wizard

    Running the Setup Wizard Though the Setup Wizard runs when you use the TV for the first time, you may want to run the Setup Wizard again to easily set up the TV in a new area. Any channels already in the TV’s memory will be replaced by the channels found by the Setup Wizard. To run the Setup Wizard: 1.
  • Page 53 4. Use the Up/Down Arrow buttons to select your preferred language, then press Right Arrow. 5. Use the Up/Down Arrow buttons to select your time zone, then press Right Arrow. 6. Use the Up/Down Arrow buttons to select Antenna, then press Right Arrow. The channel scan begins. 7.

  • Page 54: Using The Sleep Timer

    Using the Sleep Timer When activated, the TV’s sleep timer will turn the TV off after a set period of time. 1. Press the MENU button on the remote (or the MENU control on the TV). The on-screen menu is displayed. 2.
  • Page 55 Activating or Deactivating Closed Captions Your TV can display closed captions for programs that include them. Closed captions display a transcription of a program’s dialogue. If the program you are viewing is not being broadcast with closed captions, the TV will not display them.
  • Page 56 4. After highlighting the type of closed captions you wish to see, press OK. The Caption Channel menu is displayed. 5. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight the caption channel you wish to see, or highlight OFF to turn closed captions off. Press OK. Caption channels usually display different languages.
  • Page 57 2. Use the Left/Right Arrow buttons on the remote (or the - / + controls on the TV) to highlight the CC icon and press OK. The Closed Caption menu is displayed. 3. Use the Up/Down Arrow buttons on the remote (or the ˇ/ ˆ controls on the TV) to highlight Digital CC Style.

  • Page 58: Using The Digital Episode Guide

    Using the Digital Episode Guide Your TV features a digital episode guide. This guide displays program information broadcast by free-to-air digital television stations as well as the current time and date. To display the digital episode guide, press the GUIDE button on the remote.

  • Page 59: Appendix A: Troubleshooting And Technical Support

    Products are often returned due to a technical problem rather than due to a defect. If you are experiencing a problem when using your TV, try to fix the issue using this troubleshooting guide. If, after using this troubleshooting guide, you are still experiencing an issue with your TV, contact VIZIO’s Support Department. Quality customer support and service are integral parts of VIZIO’s commitment to service excellence. Address: 39 Tesla Web: www.VIZIO.com...
  • Page 60 The screen is black. • Make sure the ON/OFF switch is turned to ON, then press the Power button on the remote or TV. • Press the INPUT button on the remote control to select a different input source. • Ensure the TV’s battery is fully charged. See Getting Started for instructions on plugging the TV in.
  • Page 61 No photos are displayed when I connect my USB drive. • Ensure your USB thumb drive is formatted to FAT32. • Ensure each photo is JPG format (baseline) and is 4MB or smaller. • Extremely high-resolution photos may not display correctly. Resize large photos on a computer before displaying on the TV.

  • Page 62: Appendix B: Specifications

    Appendix B: Specifications Screen Size 7 inches Viewable Area 7 inches Dimensions 7.48” x 4.94” x 0.90” Weight TV Type Edge LED Refresh Rate 60 Hz Maximum Resolution 800 x 400 Dynamic Contrast Ratio Response Time 25 ms Brightness 250 nits HDMI Inputs 0 Component Video Inputs 0 Composite Inputs 1...

  • Page 63: Appendix C: Warranty

    Covers units purchased as new in United States and Puerto Rico Only VIZIO provides a warranty to the original purchaser of a new Product against defects in materials and workmanship for a period of one year of non-commercial usage and ninety (90) days of commercial use.
  • Page 64 ARE DISCOVERABLE OR LATENT, SHALL IN NO EVENT EXCEED THE PURCHASE PRICE OF THE PRODUCT. VIZIO SHALL NOT BE RESPONSIBLE FOR LOSS OF USE, LOSS OF INFORMATION OR DATA, COMMERCIAL LOSS, LOST REVENUE OR LOST PROFITS, OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE. THIS WARRANTY IS SUBJECT TO CHANGE WITHOUT NOTICE. CHECK WWW.VIZIO.COM FOR THE MOST CURRENT VERSION.

  • Page 65: Appendix D: Legal & Compliance

    Appendix D: Legal & Compliance FCC Class B Radio Interference Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 66 • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced technician for help. FCC warning Changes or modifications not expressly approved by the party responsible for compliance with the FCC Rules could void the user’s authority to operate this equipment. Manufactured under license from Dolby Laboratories.
