Draper DEHUMIDIFIER Instructions Manual

Hide thumbs

Table Of Contents

Quick Links

DEHUMIDIFIER

STOCK No. 64665

PART No. MD11

64666

ED18

• INSTRUCTIONS •

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO

ENSURE THE SAFE AND EFFECTIVE USE OF THIS TOOL.

03/2001

GENERAL INFORMATION

This manual has been compiled by Draper Tools and is an integrated part of this dehumidifier and should be kept with the machine.

We recommend that this manual is read before any operation of the machine, before performing any kind of adjustment to the machine,

and prior to any maintenance tasks. By following all the general safety instructions contained in this manual, it will ensure both the

dehumidifier and operator safety.

All the photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the machine.

Whilst every effort has been made to ensure accuracy of information contained in this manual, the Draper Tool policy of continuous

improvement determines the right to make modifications without prior warning.

Table of Contents

Need help?

Do you have a question about the DEHUMIDIFIER and is the answer not in the manual?

Questions and answers

Summary of Contents for Draper DEHUMIDIFIER

Page 1: General Information
GENERAL INFORMATION This manual has been compiled by Draper Tools and is an integrated part of this dehumidifier and should be kept with the machine. We recommend that this manual is read before any operation of the machine, before performing any kind of adjustment to the machine, and prior to any maintenance tasks.
Page 2: Table Of Contents
Operation & Use..................... 6 - 8 Trouble Shooting....................9 DECLARATION OF CONFORMITY Draper Tools Ltd. Hursley Road, Chandler’s Ford, Eastleigh, Hampshire. SO53 1YF. England. Declare under our sole responsibility that the product: Part Numbers: MD11 & ED18 Stock Numbers: 64665 & 64666 Description:- Dehumidifier To which this declaration relates is in conformity with the following directive(s).
Page 3: Specification/Guarantee
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms are not authorised. Your Draper guarantee is not effective unless you can produce upon request a dated receipt or invoice to verify your proof of purchase within the 12 month period.
Page 4: Power Supply
POWER SUPPLY CONNECTING THE DEHUMIDIFIER TO THE POWER SUPPLY: To eliminate the possibility of an electric shock your machine has been fitted with a BS approved, non rewireable moulded plug and cable which incorporates a fuse, the value of which is indicated on the pin face of the plug.
Page 5: Additional Safety Instructions
SAFETY INSTRUCTIONS FOR DEHUMIDIFIER Before moving the unit ensure all collected water has been drained from the tank. Close all doors and windows in the room to achieve maximum efficiency. Wash the air filter in warm water every two weeks to retain good air flow to the machine. Do NOT use alcohol, petroleum, benzine or water over 40ºC.
Page 6: Getting To Know Your Dehumidifier
GETTING TO KNOW YOUR DEHUMIDIFIERS MD11 SHOWN ✖✌ ✕✗✌ ✗✌ ✕✖✌ ✘✌ ✛✌ ✕✕✌ ✙✌ ✕✔✌ ✚✌ ✜✌ ✢✌ ✕✙✌ ✕✚✌ ✕✛✌ ✕✜✌ ✕✘✌ ✕✌ Fig.1. Fig.1. 1. Cord winder. 10. Front panel. 2. Top air outlet. 11. Air inlet. 3.
Page 7: Operation & Use
OPERATION AND USE MD11 CONTROLS (Fig.2) To switch the dehumidifier on rotate the switch ✪✌ in a ✫✌ clockwise direction until the required position is ✭✌ selected. When the unit has been activated the indicator ✫✌ will illuminate. Position settings ✬✌ are as follows:...
Page 8 OPERATION AND USE ADJUSTING THE AIR FLOW DIRECTION (Fig.4) The unit pulls in the air through the front grille and ✺✌ exits the air through the back panel grille. To alter the air flow from the back panel grille to the upper grille, open panel ✺✌.
Page 9 When the water tank is full the audible alarm will sound, the display will illuminate red and the dehumidifier will stop collecting water until the tank is emptied. To remove the tank ✼✌ lift the front edge slightly before pulling the tank outwards. Drain the tank and then replace.
Page 10: Trouble Shooting
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE The unit does not operate after the switch has 1. The water tank is not properly placed or the been activated. water tank is full. 2. The plug is not properly connected to the power. 3.
Page 11 NOTES - 1 0 -...
Page 12 ©Published by Draper Tools Ltd. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, mechanical photocopying, recording or otherwise without prior permission in writing from Draper Tools Ltd.

This manual is also suitable for:

64665 64666 Md11 Ed18
