Summary of Contents for SONIQ Qlink QLB10MH
- Page 3 Index . Notice before using 2. Package List 3. Product Introduction 4. Charging the Headset 5. Power On/ Off 6. Pairing the Headset (or any Bluetooth Device) 7. Wearing the Headset 8. Answering calls 9. Refusing calls 0. Ending calls . Voice Dialing 2. Redialing 3. Transferring calls 4. Maintaining calls 5. Ending Call and answering Call 2 6. Triple Phone Conversation 7. Adjusting the Volume 8. Safety Instruction 19. Specifications 20. Excluding Problems 2. Storage of the Headset 22. Q & A 23. Declaration of Conformity...
- Page 4 1. Notice before using Thank you for purchasing our Bluetooth Headset QLB0MH. First of all, please check to find everything in your package and carefully study the user guide to know the function details. QLB0MH is developed by the innovative Bluetooth wireless technology, enabled to connect the Bluetooth mobile phone de- signed with Audio Gateway PDA, desktop and notebook with the USB Bluetooth Dongle plugged-in, etc. Before using it, please confirm your mobile phone complies with Bluetooth V./ V.2/ V2.0 and supports the Bluetooth Headset or Hands- free Profile.
- Page 5 3. Product Introduction Function (Answering/ Ending/ On/ Off) Button 3 LED (Indicator) Light Receiver (Speaker) Microphone Power Interface adapter (charging) Decrease Volume key (-) Increase Volume key (+) 2 Note: ● For first time use, make sure to fully recharge the Headset bat- tery.
- Page 6 4. Charging the Headset QLB0MH comes with a Lithium Polymer battery built-in. . Plug the travel charger into the power socket. 2. Plug the end of the travel charger into the power interface adapter of the Headset. 3. While charging, the indicator will turn red; when charging is completed, the red indicator will shut off or flashes red. Note: Charging time is around 90~20 minutes. ● For first time use, make sure to fully recharge the Headset up to 4 hours. After a long time of not using it (around one month), while recharging, it takes a while for the indicator to turn red. ● While charging, please do not use the Headset. ● Please use the original charger to recharge the Headset. ● When the indicator flashes the red light, it means the battery is low, please recharge the Headset right away. ● Please recharge the Headset within the temperature range of -10 ℃ (+14℉) +45℃ (+113℉). 5. Power On/ Off . Press and hold the function button for 2~3 seconds, the power will turn on after the indicator flashes the blue light 3 times. 2. To turn the power off, press and hold the function button for 2~3 seconds until you see the red indicator flash 3 times.
- Page 7 Note: ● While turning the Headset on, you will hear the “Du Du” sound from the receiver. The blue indicator light will flash 5 times, then 2 times, and after repeating this for 5 times, the indicator will flash the blue light every 3 seconds to come into a standby mode. ● While the Headset is turned on, it will automatically search for the paired device. Under “ON” mode and within the effective range of 10 meters from the Headset, the indicator will flash the blue light to indicate that it entered the connecting mode. ● When turning the headset off, you will hear one “Bi” sound fol- lowed by two “Du” sounds, then the indicator will shut off after flashing the red light for a few times. 6. Pairing the Headset (or any Bluetooth Device) You must pair the Headset with your Bluetooth phone or any Bluetooth device before you use the Headset for the first time. . Ensure the Headset is off.
- Page 8 Bluetooth device, it will find QLB10MH. 5. Please choose and confirm QLB10MH. 6. Key in the Headset Password “0000” and press YES. If the pairing is successful, the indicator turns to flash the blue light only. For some mobile phones, after pairing you may have to select and confirm QLB10MH again to start the connection. (Please read your mobile phone manual carefully to take the right steps.) 7. The Headset is in the standby mode, you can start to receive and make call. Note: ● If the pairing is not successful, the Headset will return to the standby mode, please repeat the pairing process to try the pair- ing again. ● While pairing, it is better to keep the distance between the mo- bile phone and Headset around 0 cm to m and make sure no metal objects are between. ● While pairing the Headset with other Bluetooth device, when the device asks for the Password, please key-in “0000”. For more details, please check the manual of your Bluetooth device to proceed the operation.
- Page 9 - One of the devices is re-switched on. 7. Wearing the Headset According to your preference, adjust the headset on your left or right ear. 8. Answering the calls . While there is a call coming, wait until you hear the ringing from your Headset receiver to press the function button to answer the call. 2. If the mobile phone is ringing first, wait until the Headset is ringing, then press the function button. 3. While answering the calls, the blue indicator light flashes 4 times each second.
- Page 10 4. If the mobile phone is ringing and your Headset is off, turn on your Headset first, then press the function button to answer the call. 5. If your mobile phone has the function of automatically re- ceiving calls and you already set it up, while the call is com- ing, your Headset can receive the call automatically without pressing the function button. Note: ● The headset is with the function of passing the same ringing sound as the mobile phone if the mobile phone is with this func- tion, such as Nokia. 9. Refusing calls Wait to hear the ringing from your receiver, then press and hold the function button for 2~3 seconds until you hear the “Du” sound to refuse the calls.
- Page 11 2. Under the standby or connecting mode, press the function button of the Headset and follow the mobile phone instruc- tions to proceed with the voice dialing. Note: ● The activation of the voice dialing function will depend on the design of your mobile phone. ● The working range of the Bluetooth Headset is 5 meters indoors and 5~0 meters outdoors. 12. Redialing . If your mobile phone supports the redialing function, you can use this function with your Headset too. 2. Under the standby or connecting mode, press the function button of the Headset for 2~3 seconds until you hear the “Du” sound to redial the last call. 13. Transferring calls . When you are answering the call with the Headset, press the increase (+) volume key for 2~3 seconds until you hear one “Du” sound, then the call will be transferred to your mobile phone. 2. When you are answering the call with the mobile phone, press the function button of the mobile phone to transfer the call to your Headset. For some mobile phones, the phone LCD will...
-
Page 12: Maintaining Calls
Note: ● To activate this function, your mobile phone must support the Handsfree mode. For more details, please check the manual of your mobile phone. 14. Maintaining calls . When you are answering the call with the Headset, press the decrease (-) volume key for 2~3 seconds until you hear one “Du” sound, then the call will be maintained. If there is an interrupting call coming, the Headset will answer it automati- cally. 2. Press the decrease (-) volume key for 2~3 seconds until you hear one “Du” sound to end the maintaining call function. Also do this to renew the call. Note: ● To activate this function, please make sure the assigned tele- communications agent provides this service. ● To activate this function, please refer to the instructions of your mobile phones manual to make sure your phone program sup- ports this function. 15. Holding Call 1 and answering Call 2 While you are answering Call from your Headset, and having the interrupting call, you will hear the notifying “Du Du” sound. - Page 13 Press and hold the decrease (-) volume button for 2~3 seconds until you hear one “Du” sound followed by the music, Call 1 will be hold and the interrupting call (Call 2) will be answered automatically. Note: ● To activate this function, please make sure the assigned tele- communications agent provides this service. ● To activate this function, please refer to the instructions of your mobile phones manual to make sure your phone program sup- ports this function. 16. Triple phone conversation . While you are answering Call from your Headset and hav- ing the interrupting call, you will hear the notifying “Du Du” sound. Press the decrease (-) volume key for 2~3 seconds until you hear the “Du” sound, Call 1 will be maintained and the interrupting call (Call 2) will be answered automatically. 2. To proceed the triple phone conversation while you are an- swering the interrupting call (Call 2), press the increase (+) volume key for 2~3 seconds until you hear the “Du” sound, the maintained Call will be renewed, then the three ends...
-
Page 14: Safety Instruction
Note: ● To activate this function, you must make sure the assigned tele- communications agent supports this service. ● To activate this function, please refer to the instructions of your mobile phones manual to make sure your phone program sup- ports this function. ● When the triple phone conversation is on board, it can not return to the mode of having only Call or Call 2. ● When the triple phone conversation has not been activated, you can press the decrease (-) volume key for 2~3 seconds to easily transfer the calls between Call and Call 2. ● If Call 1 is maintained and Call 2 is on line, quickly press the function button to end Call 2 and renew Call . 17. Adjusting the Volume During a call, you may adjust the Headset’s volume. . To increase the volume, press the increase (+) volume key. 2. To decrease the volume, press the decrease (-) volume key. Note: ● You will hear the “Du Du” sound while adjusting the volume up to the loudest or lowest. 18. Safety instruction . Read the Headset manual carefully and use the headset cor- rectly by following the instructions. -
Page 15: Specification
2. Keep the Headset away from children, avoid children from swallowing it accidentally. 3. Do not use the cleaning liquid or spray to clean the Headset. 4. Do not clean the Headset while charging it. 5. Do not disassemble the Headset. If you encounter a problem, contact the retailer shop. ● Urgent handling -If you enconter a problem, turn the Headset off first. -If the inside components breakdown, please contact the repairing center to ask for immediate support and service. 19. Specification Product Model No. QLB0MH Standard Convention/ Signal Output Bluetooth V2.0 + EDR, Class II Frequency Band 2.4GHz ~ 2.4835GHz, ISM Band Talk/ Standby Time Up to 8 hours / Up to 250 hours Supporting Profile Headset & Handsfree Connection Peer to Peer... -
Page 16: Excluding Problems
Data Encryption 28 bits encrypted Power Capacity Rechargeable Li-Polymer Power Supply 5V DC, 00~240V AC adapter Operation Temperature -0 ~ 55 ℃ Facility Saving Temperature -20 ~ 60 ℃ Operation Moisture 0% ~ 90% (non-concrete status) Weight 4.4 g (battery included) Size 66x44x48.5 mm Safety Regulation CE, BQB 20. Excluding Problems 1. The Headset flashes the red indicator light: The battery is low, please recharge your Headset. 2. If after recharging for 20 minutes, the Headset does not turn on: For initial use, the power will be on after charging the Headset at least for 40 minutes. It is suggested to fully re- charge the Headset if you use it for the first time. 3. Does not show the recharging sign: When the battery is com- pletely exhausted or the Headset has not been used for a long time, when charging, the red indicator light will be lit after a... - Page 17 few minutes. 4. You hear no sound coming from the Headset: - Make sure the Headset has been paired with the other Blue- tooth device. - Make sure the Headset is on. - Make sure the distance between the Headset and the paired Bluetooth device is within 0 meters. - Make sure your mobile phone has a good signal. - Some Bluetooth mobile phones support only one Headset, if you pair it with more than one Headset, it may cause the other Headsets being cut off. 21. Storage of the Headset - Using the non-original accessories, it may debase the product’s function, cause the product damage, electrical conflict and the termination of the warranty. - Do not disassemble the Headset, it may damage the Headset accidentally or cause the warranty invalidation. - Put the Headset away from places full of dust. - Use clean and soft fabric to clean the Headset’s surface. - Put the Headset into your pocket while not using it. - Be aware not to let Children play with the Headset, avoiding accidents from happening or damaging the product. - Avoid storing the Headset in high or extra low temperature. [Travel charger] - The travel charger is designed for indoor use, please do not...
- Page 18 use it outdoors. - Connect the travel charger with the correct power supply. - Avoid pulling the cable to take the travel charger off the sock- et, it may damage the travel charger. [Battery] - New battery: for first time use, please fully recharge the battery for 4 hours. - Only authorized and qualified personnel can do battery chang- ing. - Under the normal usage, the rechargeable battery can be used for the long time. - The battery must be recharged within temperatures of -0 ℃ to 45℃. - Using the Headset under room temperature enables the bat- tery to achieve its maximum capacity. - Under a chilly environment, it may cause the battery’s capac- ity to decrease. - Recharge the Headset at least once every two months, either you use it or not. 22. Q & A Q : Why does the fully-charged Headset under the “On” mode not work with the Bluetooth mobile phone? A : You must activate the Bluetooth function of your mobile phone and finish the pairing between your mobile phone and Head- set.
- Page 19 Q : Can QLB0MH work with any of the mobile phones? A : No, this Headset works only with Bluetooth mobile phones. Q : How far is the working distance between the Headset and the mobile phone? A : Since QLB10MH is certificated by BQB, compliable with Bluetooth V2.0 + EDR, Class II, the longest working distance is 0 meters. But, this working distance may be shortened by the interference existed in the surroundings and due to the insufficient Bluetooth function of the mobile phone. Q : Why does my Bluetooth mobile phone find many Bluetooth devices while searching for the new Bluetooth device? A : Most of the mobile phones are allowed to find more than one Bluetooth device within the working range. When the...
- Page 20 A : No. The paired devices remain paired regardless of turning the power off, reopening the devices or changing the battery. Q : Why is the voice from the Headset not clear? A : It may be the following two reasons: () Your location has a bad signal, please move to a location with a better signal. (2) The working range between the Headset and the mobile phone has been exceeded. Please make sure the Headset and mobile phone are within the working range of 0 meters and there is no obvious interference between. Q : What can I do if the voice from the Headset is not clear? A : Make sure your mobile phone is in a location with a better signal and increase the volume of the mobile phone or the Headset.
-
Page 21: Declaration Of Conformity
Q : Why could the voice dialing function of the Headset not be switched on? A : () Please re-record the voice tag. (2) Some mobile phones do not support the voice dialing func- tion. Please refer to the manual of your mobile phone. 23. Declaration of Conformity European CE 0678: QLB0MH has been manufactured in accordance with the Eu- ropean R& TTE directive. It complies with the European Low Voltage Directive 73/23/EEC and the European EMC Direc- tive 89/336/EEC. BQB Qualification: QLB10MH Bluetooth Headset, a BQB Qualified Bluetooth product is listed as qualified End Product in accordance to sec- tion 6.2.4 of the PRD.
